Mercedes benz ntg 5.0 with 7” or 8” display hdmi and camera interface2014-up

Advertisement

INTERFACE COMPONENTS
• AX-AM-MB92 interface
• AX-AM-MB92 harness
• 6-pin to 4-pin LVDS (video) cable
• LVDS extension cable
APPLICATIONS
MERCEDES
CLA Coupe (C117)
A Class (W176)
2015-up
CLS Coupe (W218)
B Class (W246)
2015-up
CLS Shooting Brake
C Class (W205)
2014-up
AxxessInterfaces.com
Mercedes Benz
HDMI and Camera Interface
*Visit AxxessInterfaces.com for up-to-date vehicle specific applications.
INTERFACE FEATURES
• Provides front and rear camera inputs to the factory display screen
• Provides an HDMI input to the factory display screen
• Micro "B" USB updatable
• 10-pin harness with RCA jacks
• 3.5mm extension cable
• USB dongle
2015-up
E Class (W212)
2014-up
GLA Class (X156)
GLC Class (X253)
(X218)
2014-up
GLE Class (C292)
(NTG 5.0 with 7" or 8" display)
2015-up
ML Class (W166)
2015-up
S Class (W22)
2015-up
V Class (W447)
2014-up
© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION
AX-AM-MB92
I N S TA L L AT I O N I N S T R U C T I O N S
TABLE OF CONTENTS
Connections to be made .......................................2
2014-up*
Configuring the AX-AM-MB92 ...............................3
Installing the AX-AM-MB92 ...................................4
User guide ..............................................................5
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.)
CAUTION!
2014-up
controls panels, and especially air bag indicator
lights must be connected before cycling the
2014-up
ignition. Also, do not remove the factory radio
2014-up
with the key in the on position, or while the
vehicle is running.
All accessories, switches, climate
REV. 4/17/18 INSTAX-AM-MB92
