LED-Signals

At the front blind of the Vectron POS Modular you see the type tag
and five diodes (LED). The latter show different operating- and error
modes.
„Power"-LED (green)
The „Power"-LED indicates whether the POS Modular is supplied
with operating voltage.
LED on ................................................ POS system has operating voltage
LED off ............................................... POS system has no operating voltage
„Warning"-LED (yellow)
The „Warning"-LED shows error messages of the POS Modular, which
do not impede the operation.
LED blinks ........................................ error message
LED off ............................................... no error message
„Network"-LED (green)
The „Network"-LED indicates if and how the POS Modular is active
in the ECR network.
LED on ................................................ POS system is logged on to the ECR
LED blinks ........................................ POS system is configured for ECR
LED blinks quickly ........................ POS system is logged on to the ECR
LED off: .............................................. POS system is not configured for ECR
and is switched on.
or is switched off.
network, but no network traffic.
network, but communication is not
established (network
unplugged, cable is cut etc.).
network and sends or receives data.
network.
