Figure C.2: Attaching the U3-CLP to the IM805
Unit Case. Components
removed for simplification.
Figure C.3: Mounting to a Panel
Mounting Plate
#10 Hardware
U3-CLP
2 - # 10 Lock Washers
4 - # 10 Flat Washers
2 - 10 X 32 Nuts
I n s t a l l a t i o n
Using the photographs in Figure
C.2, place the clips on the unit
to be mounted as shown. The
clips must be oriented in a
fashion that places the smaller
retaining tab between the bot-
tom of the printed circuit board
and the aluminum channel case
(Figure C.2-B).
not interchangeable. They
can, however, be attached
to either vertical plate of the
aluminum channel case.
M o u n t i n g
The unit should be mounted in
accordance with Figure D.3 us-
ing the recommended hardware.
Ensure that mounting hardware
doesn't interfere with any circuitry
or wiring.
clips is 70°C. It may be nec-
essary to install a fan in your
enclosure or provide addi-
tional heat sinking to remain
below this temperature!
IM805 Operating Instructions Revision R032306
NOTE: The Mount-
ing Clips MUST be
placed on the side
for which they are
designed. They are
WARNING! The
maximum plate
temperature for all
the units that may
be used with these
67
