Function Key Features and
Settings
To configure the DTMF via Web interface
1. Click Function Keys → Line Key.
2. Select the desired Line Key and select DTMF in the Type.
3. Fill the value with the Desired DTMF number.
4. Click the
to save the configuration.
Prefix
If the key is configured as Prefix key, you can set the number prefix ( e.g. Before the
number plus 9), then you don't input 9, press the key and 9 will display on the LCD
interface.
To configure the Prefix via Phone interface
1. Press Menu →Features →Function Keys →Line Keys as Function Keys → Line
Key2(for example)
2. Press
and
key to select the Prefix in the Type field.
3. Enter the value with number that you want to set as prefix
4. Press
or Save soft key to save the configuration
To configure the Prefix via Web interface
1. Click Function Keys → Line Key.
133
