Vista VFD13C/HR Instruction Manual

Thank you for choosing this high quality camera, before attempting to connect or operate this product, please read
and follow these instructions
G

General

This is a Colour CCD video camera employs a 1/3" CCD (charge coupled device) solid-state imaging device which
provide high reliability. This mini dome camera is easily installed in most internal locations along with its very low
current consumption of 100mA the camera is not only simple to install but achieves an excellent reliability record.

Features

1. 480 TV lines of horizontal resolution and high quality picture.
2. Built in Auto Electronic Shutter.
3. Minimum illumination of 1 Lux/F2.0
4. Signal-to-noise ratio of 48dB.
5. Low current consumption of 100mA.
6. Long life and high reliability.

SPECIFICATION

Image sensor
Number of Pixel
Resolution
Min. Illumination
S/N Ratio
Electronic Shutter
White Balance
Video Output
Standard Board Lens
Lens Angle
Colour Rolling Suppress
Iris Mode
BLC
Gain Control
Power Source
Current Consumption
Dimension (mm)
Weight

WARNING:

TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE

INSTRUCTION MANUAL

VFD13C/HR Fixed Colour Dome
1/3" Colour Super HAD CCD
752(H) x 582(V) <PAL>
More than 48dB (AGC off)
1/60 (1/50) to 1/100,000 sec.
Auto white balance
1.0Vp-p composite, 75ΩΩ
480 TV lines
1 Lux / F2.0
F3.6mm / F2.0
92°
Yes
AES
ON
AUTO
DC12V+ 10%
100mA
87.5(Ø) x 83(H)
186g
