Table of Content Regulatory Compliance ...................... 1 Precautions .......................... 2 Installation Guide ........................ 3 Methods for mounting ......................3 Preparations for the installation ..................... 4 Adjust camera and replace dome cover ................5 Insert miniSD card ........................ 6 Complete the installation ......................
For more information, please visit www.recyclethis.info or www.vista-cctv.com/weee/ CE Mark This apparatus is manufactured to comply with the radio interference. European representative for manufacture (EMC): Norbain Ltd., 210 Wharfedale Road, Winnersh Triangle, Workingham, Berks, RG41 5TP, UK.
Precautions Precautions • Safety - Should any liquid or solid object fall into the unit, unplug it and have it checked by a qualified person before operating again. - Unplug the unit from the wall outlet if it is not going to be used for several days. To disconnect the cord, pull it out by the plug , never by the cord itself.
Methods for mounting the enclosure A. Methods for mounting the enclosure Optional There are two ways to mount the dome enclosure: Locking Arms A: By using the base mounting holes (C2) B: By using the quick install adaptor (see fig B, optional) Note: Please note that Alarm/RS485 cable cannot be made through the pipe if method B is used.
Installation Guide D. Preparations for the installation (1) (2) Note Terminal Connector To remove the camera liner, hold along the lends opening (D3) and gently pull it away from the dome base. Push down to unlock (1) and insert the connector (2). Note This Alarm/ RS485 cable is non-factory part and not...
Installation Guide E. Adjust camera and replace dome cover Mounting Surface Push the camera liner up to the base until it clicks into place. E1: Power Input Connector E2: Video Output Connector E3: Notches (on both sides) E4: Camera liner E5: Dome cover...
Installation Guide F. Insert MiniSD Memory card Mounting Surface F1: First Detent F2: MiniSD Card Warning Before installing the card, Note make sure that it is formatted as This Alarm/ RS485 cable is FAT32 on a PC. non-factory part and not included with the product package.
Page 9
Installation Guide Remove the dome cover and the camera liner Gently turn the dome cover counter-clockwise to unlock and pull free of the dome base. Remove the camera liner by gently pulling it free of the two notches (D4) in the camera base (see section D on page 4).
Page 10
Installation Guide Connect the wiring Feed the pre-connected main lead (that feeds into the connections E3 and E4) through the appropriate point and connect it to your video out and power in cables. A service jack socket is also provided for temporary video connection when focusing the camera, using an optional service cable( VFD/VIRD/LEAD).
Camera Adjustment A : Focus adjuster B : Field of view adjuster C : DIP switches D : ALC adjustment E : V-PHASE adjustment ALC Adjustment This is factory set. It should not normally require adjustment. V-PHASE V-PHASE Adjustment - /+ It is only active when the camera is supplied with a 24VAC power source.
Specification Hi-Resolution Camera Specifications Type/ Format 2:1 Interlace Scanning Element H15.625KHz / V :50Hz 1/3” Interline CCD Image Picture Element Effective Picture Element 752(H) x 582(V) Approximate pixels 430K Resolution (TV lines) 0.65 Lux @ F1.2 Minimum Illumination 50dB S/N Ratio AGC EX Gain 30dB AGC Preset Gain...
OSD Menu DAY LIGHT SAVING MENU SYSTEM SETUP TIME SET LANGUAGE SETUP ENGLISH FRENCH DUTCH GERMAN SPANISH VIDEO OUTPUT BRIGHTNESS HIGH NORMAL VIDEO SETUP RESOLUTION 4 CIF/ 2 CIF/ CIF HIGH VIDEO QUALITY NORMAL FRAME RATE PAL: 25/ 12/ 8/ 6/ 5/ 1 PRE-RECORDING POST-RECORDING TIME AUDIO RECORDING...
OSD Menu Instruction 1. ACCESS TO OSD MENU Connect camera (VIDEO IN) and monitor (VIDEO OUT). Connect power cable and supply power. Press [MENU] button on remote controller to access to OSD menu. Please refer to “Precautions: Get to know the remote controller” on page 2 about how to use remote controller buttons. Password is ‘0000’...
Page 16
OSD Menu Instruction 3.2 VIDEO QUALITY (HIGH/ NORMAL/ LOW): Select a desired video level among High, NORMAL, and LOW. High Mode Normal Quality (4CIF) 1500kbps 500kbps 1000kbps 400kbps 1200kbps 800kbps Quality (2CIF) Quality (CIF) 1000kbps 600kbps 300kbps 3.3 FRAME RATE: Select a value for frame rate: PAL: Selectable among 25/ 12/ 8/ 6/ 5/ 1 3.4 PRE RECORDING (ON/OFF):...
Page 17
OSD Menu Instruction 4. EVENT SETUP 4.1 ALARM SETUP 4.1.1 ALARM INPUT (ON / OFF): Select “ON” if you want to use alarm input device. 4.1.2 INPUT TYPE: Select alarm input type between “NO” and “NC”. NO (NORMAL OPEN): In NORMAL-CLOSE mode, if an intruder cuts the cable line that connects the sensor to the encoder board, the sensor recording starts automatcially.
Page 18
Screen Mode 5.2 FILE INDEX RENEW (YES/ NO): The index file is automatically generated and stored in the miniDS card. If the index file does not match to the files actually stored in the miniSD card, user can synchronize the index file list and actual file list.
Screen Mode 1. Live screen mode In the live screen mode, information are given on the screen. These include the following: Date & Time 2008-07-29 10:55:22 Screen Message INITIALIZING... Screen Icon 2. Screen messages Screen messages include the following: Message Description INITIALIZING...
Search Mode 1. Search list Press [SEARCH] on remote controller and clicking “LIST” will display the search results. 2. Search factors There are four ways to search the recorded files. These include TIME, EVENT, BOTH (TIME & EVENT), and NONE. The following are descriptions of these four search factors. 2.1 Search mode--TIME: Enter the time period that you wish to search for.
Appendix Approximate Recording Time Table 4 CIF (704 x 460/ D1) Recording Time (PAL): SANDISK-SD/SDHC Memory Normal High/ Memory Usable memory 4 CIF/ 25fps 4 CIF/ 25 fps 4 CIF/ 25fps 512 MB 480 MB 33 min 47 min 1 hr 26 min 3 hr 1 GB 960 MB...
Page 22
Template Surface mount (In a wall or ceiling) Cable access Using Quick Install Adaptor: Create an aperture in The cables are threaded through the base knockout (shown in the mounting surface to a diameter of 1” (25mm) as C1 on page 3). It is threaded for use with the quick install indicated by “T5”.
