718000418
Owner's Manual
& Assembly Guide
Gloves must be worn
at all times to reduce
risk of injury!
1-800-851-1085
assist@arrowsheds.com
BUILDING DIMENSIONS
Approx.
Size
10' x 8'
74 Sq. Ft. 444 Cu. Ft.
3,0 m x 2,3 m
6,9 m
* See Inside for Detailed Safety Information.
or
Size rounded off to the nearest foot
Exterior Dimensions
Storage
(Roof Edge to Roof Edge)
Area
Width
123 1/4"
2
12,6 m 3
313,1 cm
Model No.
NP10867H8
Depth
Height
Width
95 1/4"
77 7/8"
118 1/4"
241,9 cm
197,8 cm
300,4 cm
www.arrowsheds.com
NP10867
SE10867EU
10' x 8'
Base
121" x 92 3/4"
Size
307,3 cm x 235,6 cm
For proper base construction see page 12
Interior Dimensions
(Wall to Wall)
Depth
Height
90"
76 5/8"
228,6 cm
194,6 cm
01FD
SE10867
Nominal Size
Door
Opening
Width
Height
55 1/2"
65"
141,0 cm
165,1 cm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NP10867 and is the answer not in the manual?

Questions and answers

Summary of Contents for Arrow NP10867

  • Page 1 01FD 718000418 Owner’s Manual & Assembly Guide www.arrowsheds.com SE10867 Model No. NP10867 Gloves must be worn at all times to reduce SE10867EU NP10867H8 risk of injury! 10’ x 8’ Nominal Size Customer Service: 1-800-851-1085 Base 121” x 92 3/4” assist@arrowsheds.com...
  • Page 2 SAFETY PRECAUTIONS... Safety precautions MUST be followed at all times throughout the construction of your building! Practice caution with the tools being used in the Care must be taken when handling various pieces assembly of this building. Be especially familiar with of your building since many contain sharp edges.
  • Page 3 ASSEMBLY TIPS & TOOLS Watch the Weather Closely: Be sure the day you choose to install your building is dry and calm. Do NOT attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Use Teamwork: Two or more people are required to assemble your building.
  • Page 4 FREQUENTLY ASKED QUESTIONS How long will it take to assemble the building? Assembly time depends on a variety of factors, including roof design, tools available, DIY skill and the pace at which you work. Guidelines for each shed assembly are approximate AFTER completion of the base, and assume two or more people working on the assembly.
  • Page 5 Arrow provides a base kit accessory that is an option for most building sizes. If you are building a wood deck/fl oor, an Arrow fl oor frame kit on top of your deck/fl oor assembles in minutes and provides a fl oor frame suitable for a 5/8”...
  • Page 6 What if the rear wall angle and channels are too large to fi t inside of the rear wall panels? Check the dimensions of wall assemblies. They should be slightly smaller than the fl oor frames. Lay the assemblies on top of the rear fl oor frame and pull them up to the top of the wall panels causing the corner panels to stand erect and not lean inward.
  • Page 7 HARDWARE LIST... 07BH Hardware Views by Key No. Part Part Qty. Description #2 Phillips #2 Phillips List 11/32 Hex. 65103 Hex Nut (#8-32) 65900A Black Screw (#10B x 1/2) (13 mm) 65923 Bolt (#8-32 x 3/8) (10 mm) 65004 Screw (#8AB x 5/16) (8 mm) #2 Phillips 66045 Door Handle...
  • Page 8 PARTS LIST... 08BH Selected End Views by Key No. Part No. Part Description Qty. List 3719 Door Handle Brace 6635 Gable Brace 9365 Front Wall Channel 10497 Horizontal Door Brace 5986 Rear Wall Angle 6000 Right Gable 6001 Left Gable 6403 Door Track Splice 6529...
  • Page 9 ASSEMBLY BY KEY NO. 09BH Walls Floor...
  • Page 10 ASSEMBLY BY KEY NO. 10BH Roof Doors...
  • Page 11 ASSEMBLY OVERVIEW 11BH Install Corners, Wall Angles, and Door Build the Floor Frame Track Attach Gables and Roof Beams Install Wall Panels, Wall Channels, and Door Jambs Install Roof Panels, Ridge Cap, Side Install Doors Trim, and Corner Cap Shed is now complete.
  • Page 12 OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.). If you choose this option Arrow has a simple kit available to provide a fl oor inside the shed to keep stored items off the ground. This kit can be used to support a plywood fl oor (wood not included) or be fi...
  • Page 13 Step 1: Floor Frames Washers are to be used on painted parts only. You will need for this page: Washers are not necessary on unpainted parts 8937 and there are not enough to use on every screw and bolt. Side Floor (QTY: 8) Frame 8937...
  • Page 14 Step 1: Continued You will need for this page: 8936 Rear Floor (QTY: 5) Frame 8936 Assemble the Rear Floor Frames. Overlap two (2) Rear Floor Frames as shown and secure with fi ve (5) bolts. Two (2) bolts must enter from bottom. Check that the fi...
  • Page 15 Step 1: Continued You will need for this page: 119 3/8” 303,2 cm 9367 8934 Finished Length Front Floor Ramp (QTY: 8) Frame Overlap Length 7 3/8” 18,7 cm 9367 Overlap the Ramp and two (2) Front Floor 8934 Frames so that four (4) holes align at each end as shown.
  • Page 16 Step 2: Wall Frames You will need for this page: 5986 9917 Rear Wall Rear Wall Angle (QTY: 2) Channel 5986 9917 5986 Overlap two (2) Rear Wall Channels so that three (3) holes align as shown. Insert a bolt 9917 and nut through the center hole.
  • Page 17 Step 2: Continued 17BH You will need for this page: 89 7/8” 228,3 cm 9922 8839 Finished Length Side Wall (QTY: 4) Side Wall Angle Channel Overlap Length 7 5/8” 19,4 cm Overlap two (2) Side Wall Channels so that three (3) holes align as shown.
  • Page 18 Step 3: Roof Beams You will need for this page: 10470 10470 BUILD TWO (2) BEAMS Roof Beam (QTY: 16) Overlap two (2) Roof Beams so that the bottom slots align as shown. Insert six (6) bolts and nuts as shown below. Insert two (2) bolts and nuts into slots on bottom of the Beam as shown.
  • Page 19 Step 3: Continued 91 7/8” 233,4 cm You will need for this page: 10470 Finished Length Roof Beam (QTY: 14) Overlap Length Overlap two (2) Roof Beams so that bottom slots 6” 15,2 cm align but DO NOT INSERT BOLTS. Next, overlap two (2) more Roof Beams to form a second Roof Beam Assembly.
  • Page 20 Step 4: Door Track You will need for this page: END VIEW 6403 9366 CORRECT INCORRECT Long Leg Track Splice (QTY: 4) Door Slide Door Track on top. (Painted) Insert screws into bottom side only. The Gables will fasten to the Door Track using the holes on the top side. Door Slide Align two (2) Door Tracks with the four (4) holes in the bottom of the Door Track Splice...
  • Page 21 Step 5: Frame Assembly You will need for this page: Assemblies from Step 1: • Front Floor Assembly (1) • Side Floor Assembly (2) • Rear Floor Assembly (1) (QTY: 8) (QTY: 2) Do NOT fasten your Floor Frames to your Base at this time. You will anchor your building after it is erected.
  • Page 22 Step 6: Corners 22BH You will need for this page: 6627 9374 8471 (QTY: 8) (QTY: 4) Corner Panel Wall Panel Wall Panel Place washers on all bolts and screws used on painted parts. Position Front and Rear Wall Panels so that they overlap the narrow side of the Corner Panels as shown.
  • Page 23 Step 6: Continued 23BH Be cautious when maneuvering You will need for this page: and placing Panels. Once Panels begin to go up it is important to be able to fi nish in a timely manner to reduce the possibility of wind (QTY: 18) damage to your building.
  • Page 24 Step 7: Wall Framing You will need for this page: Assemblies from Step 2 and Step 4: • Rear Wall Angle Assembly (1) • Side Wall Angle Assemblies (2) • Door Track Assembly (1) (QTY: 18) • Install one Side Wall Angle Assembly fi rst. •...
  • Page 25 Step 8: Wall Panels 25BH FASTEN TO WALL ANGLES You will need for this page: 6627 8200 [ NO HARDWARE NEEDED FOR THIS STEP ] Wall Panel Wall Panel Lay out all Panels in the positions shown below. Double check that you have the correct Panel in FASTEN TO WALL CHANNELS (STEP 10) each location.
  • Page 26 Step 8: Continued You will need for this page: (QTY: 80) (QTY: 17) Working one side at a time, lift the Panels into Use bolts to attach Wall Panels where Wall Angles overlap. place and secure top and bottom of Panels with screws.
  • Page 27: Acorn Nut

    Step 9: Door Jambs 27BH You will need for this page: 9370 Door Jamb (QTY: 8) (QTY: 4) Secure Door Jambs with two (2) screws in the top and bottom of each Panel as shown. Insert two (2) bolts and nuts into the back side of each Panel as shown below.
  • Page 28 Step 10: Wall Channels You will need for this page: 9365 Assemblies from Step 2: • Rear Wall Channel Assembly (1) • Side Wall Channel Assemblies (2) Front Chan. (QTY: 56) Install Rear Wall Channel by placing screws through all remaining holes in Wall Panels. Install Side Wall Channels by placing screws through all remaining holes in Wall Panels.
  • Page 29 Step 11: Gables 29BH You will need for this page: 6001 6000 5971 (QTY: 8) Left Gable Right Gable Bracket GABLES ARE STACKED TOGETHER DURING SHIPPING AND MAY BE MIS- TAKEN FOR ONE GABLE! SEPARATE GABLES BEFORE CONTINUING. Edge Trim (Plastic) Edge Trim MUST cover Gable edge.
  • Page 30 Step 11: Continued 30BH You will need for this page: 6635 (QTY: 8) (QTY: 3) Gable Brace Gable must fi t UNDER Side Wall Angle at corner. Working with one Gable at a time, attach the Rear Gables to the Rear Wall Angle with screws.
  • Page 31 Step 11: Continued 31BH You will need for this page: 6635 (QTY: 12) (QTY: 2) Gable Brace Track Sup. Working with one Gable at a time, Leave two (2) holes open on each side of attach the front Gables to the Door the Gable peak to attach Track Support.
  • Page 32: Weather Stripping

    Step 12: Roof Framing 32BH You will need for this page: Assemblies from Step 3: • Main Roof Beam Assembly (1) • Single Roof Beam Assemblies (2) (QTY: 12) Seal the gap between the Gables using the weather stripping tape as shown. Do this at both ends of the building before installing Roof Beams.
  • Page 33 Roof Install Prep Page 33BH Use the information on this page to complete steps 13 thru 15. If Roof Beam holes do not line up with Roof Panel holes, shift the building from left to right. If this does not help, your building may not be level. Shim the corners until holes line up.
  • Page 34 Step 13: Roof Corners 34BH You will need for this page: 8468 8469 Right End Left End (QTY: 8) (QTY: 20) Secure the fi rst End Panel to the Main Roof An Awl may be used to help Beam by placing a screw in hole #1 (from the align holes that are only slightly diagram below).
  • Page 35 Step 14: Roof Assembly 35BH You will need for this page: 7483 6529 Roof Panel Roof Panel (QTY: 32) (QTY: 4) FASTEN TO RIDGE CAP (NEXT TWO PAGES) Cut four (4) strips of weather stripping 2” (5,1 cm) long from the roll of weather stripping tape and put aside for later use.
  • Page 36 Step 14: Continued 36BH You will need for this page: 7483 8840 • Bolts under Ridge Cap pass thru slots where the End Roof Panel is (QTY: 16) Roof Panel Ridge Cap (QTY: 8) overlapped by the Panel next to it (labeled rib 2 below).
  • Page 37 Step 14: Continued 37BH You will need for this page: 8486 • Bolts under Ridge Cap pass thru slots where the End Roof Panel is overlapped by the Panel next to it (labeled rib 2 below). (QTY: 24) Ridge Cap (QTY: 8) •...
  • Page 38 Step 15: Roof Trim 38BH You will need for this page: 8485 8836 (QTY: 4) (QTY: 8) (QTY: 4) Left Trim Right Trim Trim Cap (L) Trim Cap (R) Slide Peak Cap legs under Ridge Cap and secure Peak Cap with two (2) bolts and nuts on each end.
  • Page 39: Door Handle Brace

    Step 15: Door Assembly 39AW You will need for this page: 10477 3719 6300 Door Handle Brace Vert. Brace (QTY: 3) (QTY: 2) Handle Do not fully tighten the bolts that hold on the Door Handle until the Vertical Door Brace is in place. Attach the Door Handle and Door Handle Brace to the Door with two (2) bolts and nuts as shown.
  • Page 40: Horizontal Door Brace

    Step 15: Continued 40AW You will need for this page: 10497 Horiz. Brace (QTY: 6) Door Guide Slide Horizontal Brace over Door edge and secure with one (1) bolt and nut in top and bottom. Secure the Door Guides and Lower Horizontal Door Brace as shown below.
  • Page 41: Door Track

    Step 16: Door Install 41AW You will need for this page: Assemblies from Step 16: • Right Door Assembly (1) • Left Door Assembly (1) (QTY: 8) Gable Door Slide From inside the building, place the bottom of the Door into the Front Floor Frame track at about the half- open position.
  • Page 42 The entire fl oor frame MUST be securely anchored once the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base.
  • Page 43 Keep the roof clear of leaves and snow. Heavy amounts of snow on the roof can damage the building making it unsafe to enter. In snow country, Roof Strenghtening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
  • Page 44 Fits all Arrow storage buildings. because the full line of accessories is not always available from all dealers, Arrow is offering them to you on a direct basis. SPECIAL NOTICE ON DELIVERY: Purchase Online at www.arrowsheds.com If your accessory is shipped via truck line a day time Purchase over the phone by calling 1-800-851-1085 phone number is required to arrange delivery.
