Owner's Manual & Assembly Instructions
SP01
Model No.
714740511
Storage Area: 129 Sq. Ft.
12,0 m
BUILDING DIMENSIONS
*Approx.
Base
Size
Size
10' x 14'
121" x 160 1/4"
3,0 m x 4,0 m
307,3 cm x 407,0 cm
CM1014-A1
697.68103-C1
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
769 Cu. Ft.
21,8 m
2
3
* Size rounded off to the nearest foot
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
123 1/4"
162 3/4"
313,1 cm
413,4 cm
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Height
Width
81 3/8"
118 1/4"
206,7 cm
300,4 cm
OB1014-C1
697.68104
Depth
Height
Width
157 1/2"
80 1/8"
55 1/2"
400,1 cm
203,5 cm
141,0 cm 152,4 cm
Door
Opening
Height
60"
Advertisement
Related Manuals for Arrow CM1014-A1
Summary of Contents for Arrow CM1014-A1
- Page 1 Owner's Manual & Assembly Instructions SP01 Model No. CM1014-A1 OB1014-C1 697.68103-C1 697.68104 Missing Parts, Questions on Assembly? Call: 1-800-851-1085 or assist@arrowsheds.com Do not return to dealer, they are not equipped to handle your requests. 714740511 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE Storage Area: 129 Sq.
- Page 2 We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct a base and anchoring system of your choice.
- Page 3 PLAN AHEAD..Be sure the day you select to install your building is dry and calm. Watch the Weather: Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Whenever possible, two or more people should work together to assemble Teamwork: your building.
- Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
- Page 5 Roof: amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation. Always keep the door tracks clear of dirt and other debris that prevent them from Doors: sliding easily.
- Page 6 10'x9' (3,0 m x 2,6 m), use 2 kits. Model No. AT101 Heavy-duty galvanized steel bars that Model No. AK100 fit all 10' (3,0 m) wide Arrow buildings. New concrete anchor system permits They install quickly and easily to anchoring any size Arrow building help organize space and create directly to a concrete slab.
- Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 9 A. To support a plywood deck B. To be filled with sand. We recommend the combined use of 1. an ARROW FLOOR FRAME KIT and 2. an ARROW ANCHORING KIT as an effective method of securing the building to the ground.
- Page 10 Below are recommended ways of anchoring. (Model No. AK4 or 60298) Anchoring into Wood/Post: Arrow Anchoring Kit: Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base. dia. holes provided in the frames for proper anchoring.
- Page 11 (Packed with Screws) 65109 67468 66646 #8-32 Acorn Nut (4) Peak Cap (2) 66045 Washer (481) (Packed with Screws) (Arrow Logo) Handle (2) (13 sheets of 40) 66183 6228 66382 Roof Trim Cap 66769 Track Support (2) Lower Door Guide (4) (2 right &...
-
Page 12: Table Of Contents
Parts List BZ12 ctr Assembly Part Part Quantity Check Key No. Number Description in Carton List 8576 Right Gable 8577 Left Gable 10497 Horizontal Door Brace 7743 Roof Panel 9984 Right Roof Panel 9983 Left Roof Panel 10475 Right and Left Doors 9369 Door Jamb 9373... - Page 13 Assembly by Key No. SP13 ctr...
-
Page 14: Side Floor Frame
● ● ● ● ● 8934 Ramp (1) ● Parts Needed For ● ● ● ● ● ● 9367 Front Floor Frame (2) Step 1 ● ● ● ● ● 8936 Rear Floor Frame (2) Floor Frame Assemblies ● ● ● ● ● 10387 Side Floor Frame (4) SO14ctr (13) 9367... - Page 15 ● ● ● ● ● 5986 Rear Wall Angle (2) ● Parts Needed For ● ● ● ● ● ● 10389 Rear Wall Channel (2) Step 2 ● ● ● ● ● 10388 Side Wall Channel (4) Frame Assemblies ● ● ● ● ● 10391 Side Wall Angle (4) SO15 ctr Rear Wall Channel 10389...
-
Page 16: Roof Panel
● Parts Needed For ● ● ● ● ● ● 10386 Roof Beam (8) Step 3 Roof Beam Assemblies SP16 ctr 10386 (30) 10386 The roof beams join the two gables Roof Beam 159 3/8" 404,8 cm and support the roof panels. The main roof beam is made up of four pieces overlapped back to back at the cen- ter. -
Page 17: Door Track Splice
● Parts Needed For ● ● ● ● ● ● 6403 Door Track Splice (1) Step 4 ● ● ● ● ● 9366 Door Track (2) Door Track Assembly A17 ctr NOTE: Door Track Splice (painted part) 6403 The door track assembly supports the sliding doors and reinforces the front wall. - Page 18 ● ● ● ● ● Front Floor Assembly (1) ● Parts Needed For ● Step 5 ● ● ● ● ● Side Floor Assembly (2) Floor Frame ● ● ● ● ● Rear Floor Assembly (1) SO18 ctr RIGHT REAR 10387 Assemble the four corners of the floor frame using two screws at each...
- Page 19 ● Parts Needed For ● ● ● ● ● ● 6515 Wall Panel (2) Step 6 ● ● ● ● ● 9373 Front Wall Panel (2) Corners ● ● ● ● ● 6020 Corner Panel (4) SO19 ctr Narrow Side 6020 (34) Wide Side...
-
Page 20: Side Wall Channel
● Parts Needed For ● Step 7 ● ● ● ● ● Rear Wall Channel Assembly (1) ● ● ● ● ● Side Wall Channel Assembly (2) Mid Frames SO20 ctr (20) The mid frame pieces give rigidity to the side and rear walls. Fasten the rear wall channel across the middle of the rear wall using screws. -
Page 21: Side Wall Angle
● ● ● ● ● Door Track Assembly (1) ● Parts Needed For ● Step 8 ● ● ● ● ● Rear Wall Angle Assembly (1) Top Frames ● ● ● ● ● Side Wall Angle Assembly (2) SO21 ctr (26) The top frame pieces give rigidity to the walls and provide a surface for... -
Page 22: Wall Panel
● Parts Needed For ● Step 9 ● ● ● ● ● 6515 Wall Panel (10) Wall Panels SO22 ctr STEP (144) (15) Crimped Rib STEP Each wall panel has a crimped rib on Underneath one side. The crimped rib should go under the rib of the panel that follows 6515 Detail Showing... - Page 23 ● Parts Needed For ● ● ● ● ● ● 9369 Door Jamb (2) Step 10 ● ● ● ● ● 9365 Front Wall Channel (2) Front Channel/Door Jamb SO23 ctr 9365 (18) STEP The door jambs reinforce the door opening and provide an attractive INSIDE OF trim.
- Page 24 ● Parts Needed For ● ● ● ● ● ● 8576 Right Gable (2) Step 11 ● ● ● ● ● 8577 Left Gable (2) Gable Assemblies ● ● ● ● ● 6635 Roof Beam Bracket (4) SR24 ctr The gables go on top of the front and rear walls to support the roof beams.
- Page 25 ● ● ● ● ● Left Gable Assemblies (2) ● Parts Needed For ● Step 12 ● ● ● ● ● Right Gable Assemblies (2) Gables/Braces ● ● ● ● ● 9009 Gable Brace (2) SR25 ctr (32) Lift and fasten a right and left gable, under angle at corner, to the door track with screws.
- Page 26 ● Parts Needed For ● ● ● ● ● ● Main Roof Beam (1) Step 13 ● ● ● ● ● Single Roof Beam (2) Roof Beam//Braces ● ● ● ● ● 9204 Roof Beam Brace (2) SR26 ctr (16) Wrap the weather stripping tape around the two joined edges of the left and right gables.
- Page 27 ● Parts Needed For ● Step 14 ● ● ● ● ● 9984 Right Roof Panel (1) Right Roof Panel SP27 ctr Locate the roof panels and find the right roof panel part number 9984. Position the right roof panel at the Installing the roof panels is best done back right corner and fasten to the with a step ladder.
- Page 28 ● Parts Needed For ● ● ● ● ● ● 9983 Left Roof Panel (1) Step 15 ● ● ● ● ● 7743 Roof Panel (2) Ridge Cap & Panels ● ● ● ● ● 6797 Ridge Cap (1) SP28 ctr Screws To Roof Beam (22)
- Page 29 ● Parts Needed For ● ● ● ● ● ● 7743 Roof Panel (4) Step 16 ● ● ● ● ● 6869 Ridge Cap (1) Ridge Cap & Panels SP29 ctr (32) Install two roof panels 7743 work- NOTE ing side to side. Continue weather If roof beam holes do not line up stripping the ridge.
- Page 30 ● ● ● ● ● 6797 Ridge Cap (1) ● Parts Needed For ● ● ● ● ● ● 7743 Roof Panel (2) Step 17 ● ● ● ● ● 9983 Left Roof Panel (1) Ridge Cap & Panels ● ● ● ● ● 9984 Right Roof Panel (1) SP30 ctr (22) (72)
- Page 31 ● Parts Needed For ● ● ● ● ● ● 6893 Left Side Roof Trim (2) Step 18 ● ● ● ● ● 6015 Side Roof Trim (2) Roof Trim ● ● ● ● ● 6892 Right Side Roof Trim (2) SP31 ctr (10) Attach the right, left and side roof...
- Page 32 ● ● ● ● ● 3719 Door Handle Brace (2) ● Parts Needed For ● ● ● ● ● ● 10475 Right and Left Doors (2) Step 19 ● ● ● ● ● 10497 Horizontal Door Brace (4) Door Assembly ●...
- Page 33 ● Parts Needed For ● ● ● ● ● ● Right Door Assembly (1) Step 20 ● ● ● ● ● Left Door Assembly (1) Door Installation & Adjustment SQ33 ctr Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the building) behind door jamb into the...
- Page 34 Anchoring and Floor Frame XA34 Anchoring Anchor your building at this time. Floor Frame If you have purchased a Floor Frame Kit you need to install it at this time.
- Page 35 SOME FACTS ABOUT RUST XA35 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
