Arrow CL72-A Owner's Manual & Assembly Instructions

Cl72-a
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
BK01
Model No.
709020509
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
7' x 2'
86 5/8" x 28 1/4"
2,1m x 0,6m 220,0cm x 71,8cm
CL72-A
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
15
95
1,4m
2
2,7m
3
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
Height
87 1/4"
28 1/2"
81 5/8"
221,6cm
72,4cm
207,3cm
Interior Dimensions
( Wall to Wall)
Width
Depth
Height Width Height
83 7/8"
25 1/2"
81"
213,0cm 64,8cm 205,7cm 127,6cm 175,3cm
Door
Opening
50 1/4"
69"

Advertisement

Table of Contents
loading

Related Manuals for Arrow CL72-A

Summary of Contents for Arrow CL72-A

  • Page 1 Owner's Manual & Assembly Instructions BK01 Model No. CL72-A CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ 709020509 SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
  • Page 2 We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct a foundation and anchoring system of your choice.

  • Page 3: Tools And Materials

    PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
  • Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
  • Page 6 10'x9' (3,0m x 2,6m), use 2 kits. Model No. AT101 Heavy-duty galvanized steel bars that Model No. AK100 fit all 10' (3,0m) wide Arrow buildings. New concrete anchor system permits They install quickly and easily to anchoring any size Arrow building help organize space and create directly to a concrete slab.
  • Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 9 Foundation BJ09 The Foundation For Your Building OPTION 1: Wood Platform If you decide to build your own foundation, be sure to select the appropriate materials. These are the recommended materials for your foundation: ● 2 x 4's (38mm x 89mm) Pressure Treated Lumber ● 5/8" (15,5mm) 4 x 8 (1220mm x 2440mm) Plywood-exterior grade ●...
  • Page 10 It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6mm) Wood Screws. There are 1/4" (6mm) Recommended for use with any suggested base.
  • Page 11 Hardware BK11 65923 65004 65941 65103 #8-32x3/8" (10mm) #8Ax5/16" (8mm) #6-32 Hex Nut (23) Bolt (68) #8-32 Hex Nut (68) Screw (154) 66645 66646 66714 66148 #6-32x3/4" (19mm) Washer (164) #6-32x7/16" (11mm) Cap Protector (14) Screw (7) (5 sheets of 40) Flat Hd Bolt (16) 66684 66462...

  • Page 12: Parts List

    Parts List BK12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 8984 Side Floor Frame 9429 Ramp 9430 Front/Rear Floor Frame 9431 Mid Wall Frame 9432 Side Wall Angle 9433 Roof Rafter 9434 Rear Wall Angle 9435 Horizontal Door Brace 9436...
  • Page 13 Assembly by Key No. BK13...
  • Page 14 ● Parts Needed For ● ● ● ● ● ● 9440 Door Header (one) Step 1 ● ● ● ● ● 9442 Starter Strip (one) Door Header Assembly BJ14 The door header reinforces the front wall and roof. It is made up of two pieces.

  • Page 15: Door Assembly

    ● ● ● ● ● 9435 Horizontal Door Brace (four) ● ● ● ● ● 9936 Right Door (one) Step 2 ● Parts Needed For ● ● ● ● ● ● 9937 Left Door (one) ● ● ● ● ● 66612 Astragal (one) Door Assembly ●...
  • Page 16 ● Parts Needed For ● ● ● ● ● ● 8984 Side Floor Frame (two) Step 3 ● ● ● ● ● 9429 Ramp (one) Floor Frame Assembly ● ● ● ● ● 9430 Front/Rear Floor Frame (two) BJ16 The floor frame at the front of building is made up of two pieces.

  • Page 17: Top View

    ● ● ● ● ● 9432 Side Wall Angle (two) ● Parts Needed For ● ● ● ● ● ● 9446 Right Front Corner Panel (one) Step 4 ● ● ● ● ● 9447 Left Front Corner Panel (one) Corners/Side Angles ●...
  • Page 18 ● Parts Needed For ● ● ● ● ● ● 9434 Rear Wall Angle (one) Step 5 ● ● ● ● ● Door Header Assembly (one) Frames BJ18 The main frame pieces give rigidity to the front and rear walls. Fasten the rear wall angle across the top of the rear wall using four screws.
  • Page 19 ● Parts Needed For ● ● ● ● ● ● 9441 Rear Header (one) Step 6 ● ● ● ● ● 9445 Wall Panel (two) Wall Panels/Rear Header BK19 Each wall panel has a crimped rib on one side. The crimped rib should go under the rib of the panel that follows it.
  • Page 20 ● Parts Needed For ● ● ● ● ● ● 9433 Roof Rafter (three) Step 7 ● ● ● ● ● 9448 Right Gable (one) Gables/Roof Rafters ● ● ● ● ● 9449 Left Gable (one) BJ20 Lift and fasten a right and left gable, under rear header, to the right and left hand wall with four screws.
  • Page 21 ● Parts Needed For ● ● ● ● ● ● 9452 Right Door Jamb (one) Step 8 ● ● ● ● ● 9453 Left Door Jamb (one) Door Jambs BK21 The door jambs reinforce the door opening and provide an attractive trim.
  • Page 22 ● ● ● ● ● 9436 Right Roof Trim (one) ● Parts Needed For ● ● ● ● ● ● 9437 Left Roof Trim (one) Step 9 ● ● ● ● ● 9438 Front Roof Trim (one) Roof Panel/Trim ● ● ● ● ● 9439 Peak Trim (one) ●...
  • Page 23 ● Parts Needed For ● ● ● ● ● ● 9431 Mid Wall Frame (one) Step 10 ● ● ● ● ● 9454 Shelf (four) Shelving/Mid Frame/Track ● ● ● ● ● 9522 Track Tool Holder (one) BK23 Tool Hooks slide along track Fasten the mid wall frame across Screw Driver Holder (1) to any desired position.

  • Page 24: Door Installation

    CL72-A BK24 ● Parts Needed For ● Step 11 ● ● ● ● ● Right Door Assembly (one) ● ● ● ● ● Left Door Assembly (one) Door Installation BK24 Position doors in corners of door opening as shown and fasten hinges with 7/16"...
