Arrow BD88 Owner's Manual & Assembly Instructions

Hide thumbs

Advertisement

Table of Contents

Owner's Manual & Assembly Instructions
BY01
Model No.
709981207
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
8' x 8'
97 1/2" x 92 3/4"
2,4m x 2,3m 248cm x 236cm
BD88
NW88P-A
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
59
314
5,5m
2
8,9m
3
MO88
WM88
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
Height
99 3/4"
95 1/4"
67 7/8"
253cm
242cm
172cm
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Width
Depth
94 3/4"
90"
241cm
229cm
Door
Opening
Height Width Height
66 5/8" 43 1/2"
58"
169cm
110cm 147cm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BD88 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arrow BD88

Summary of Contents for Arrow BD88

  • Page 1 Owner's Manual & Assembly Instructions BY01 Model No. BD88 MO88 NW88P-A WM88 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ 709981207 SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
  • Page 2 Anchoring and foundation materials are not included with your building. We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct a foundation and anchoring system of your choice.

  • Page 3: Tools And Materials

    PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
  • Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
  • Page 6 For buildings ATTIC KIT / WORKBENCH KIT larger than 10'x9', use 2 kits. Heavy-duty galvanized steel bars that fit all 10' wide Arrow buildings. They Model No. AK100 install quickly and easily to help New concrete anchor system permits...
  • Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 9 OPTION 1: ARROW FLOOR FRAME KIT: (Order No. FB109-A or 68385-A) Arrow has the best base for your building in this simple foundation kit. It keeps stored items above the ground. This kit should be used with one of the following: A.
  • Page 10 It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia.
  • Page 11 #8Ax5/16" Screw (311) (Packed with Screws) 65109 67468 66646 #8-32 Acorn Nut (6) Peak Cap (2) 66045 Washer (360) (Packed with Screws) (Arrow Logo) Handle (2) (9 sheets of 40) 66029 66183 Plug (2) 66382 Roof Trim Cap 66769 (Packed with Screws) Lower Door Guide (4) (2 right &...

  • Page 12: Parts List

    Parts List BY12 Part Part Quantity Check Number Description in Carton List 6615 Rear Wall Angle 6617 Door Track Splice 10498 Horizontal Door Brace 6658 Gable Brace 7875 Roof Panel 7906 Right Gable 7907 Left Gable 8486 Ridge Cap 8466 Right Roof Panel 8467 Left Roof Panel...
  • Page 13 Parts List BY13 Part Part Quantity Check Number Description in Carton List 10488 Right Door 10488 Left Door 9363 Wall Panel 9900 Door Jamb 9924 Rear Wall Channel 9377 Rear Floor Frame 9378 Door Track 9379 Front Floor Frame 9380 Front Corner Panel 9384 Rear Corner Panel...
  • Page 14 ● ● ● ● ● 8941 Ramp (1) ● Parts Needed For ● ● ● ● ● ● 9379 Front Floor Frame (2) Step 1 ● ● ● ● ● 9377 Rear Floor Frame (2) Floor Frame Assemblies ● ● ● ● ● 9989 Side Floor Frame (4) BY14 The front floor frame is made up of 3 pieces.

  • Page 15: Frame Assemblies

    ● ● ● ● ● 6615 Rear Wall Angle (2) ● Parts Needed For ● ● ● ● ● ● 9924 Rear Wall Channel (2) Step 2 ● ● ● ● ● 9990 Side Wall Channel (4) Frame Assemblies ● ● ● ● ● 9991 Side Wall Angle (4) BY15 The main frame pieces reinforce the walls.
  • Page 16 ● Parts Needed For ● ● ● ● ● ● 10470 Roof Beam (4) Step 3 ● ● ● ● ● 10471 Roof Beam (8) Roof Beam Assemblies BY16 The roof beams join the 2 gables and 2" support the roof panels. The roof as- 10471 sembly is made up of 4 pieces over- lapped back to back at the center.
  • Page 17 ● Parts Needed For ● ● ● ● ● ● 6617 Door Track Splice (1) Step 4 ● ● ● ● ● 9378 Door Track (2) Door Track Assembly NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall.
  • Page 18 ● ● ● ● ● Front Floor Assembly (1) ● Parts Needed For ● Step 5 ● ● ● ● ● Side Floor Assembly (2) Floor Frame ● ● ● ● ● Rear Floor Assembly (1) BY18 RIGHT REAR 9989 STEP Assemble the four corners of the 9377...
  • Page 19 ● Parts Needed For ● Step 6 ● ● ● ● ● 9380 Front Wall Panel (2) Corners ● ● ● ● ● 9384 Rear Corner Panel (2) BY19 NOTE The remainder of the building assembly Wide Side requires many hours and more than one person.
  • Page 20 ● ● ● ● ● Door Track Assembly (1) ● ● ● ● ● Rear Wall Angle Assembly (1) ● Parts Needed For ● Step 7 ● ● ● ● ● Side Wall Angle Assemblies (2) Frames ● ● ● ● ● Rear Wall Channel Assembly (1) ●...
  • Page 21 ● Parts Needed For ● ● ● ● ● ● 8995 Wall Panel (2) Step 8 ● ● ● ● ● 9363 Wall Panel (2) Wall Panels ● ● ● ● ● 9364 Wall Panel (4) BY21 The wall panels come in two widths. STEP Each wall panel has a crimped rib on 9363 9363...
  • Page 22 ● Parts Needed For ● Step 9 ● ● ● ● ● 9900 Door Jamb (2) Door Jamb INSIDE OF BUILDING TOP VIEW (3) bolts Door Track Acorn Nut 9900 Bolt The door jambs reinforce the door Cross-Section Top View opening and provide an attractive Plug TOP VIEW...
  • Page 23 ● Parts Needed For ● ● ● ● ● ● 7906 Right Gable (2) Step 10 ● ● ● ● ● 7907 Left Gable (2) Gable Assemblies ● ● ● ● ● 7916 Roof Beam Bracket (4) The gables go on top of the front and rear walls to support the roof beams.
  • Page 24 ● ● ● ● ● Left Gable Assembly (2) ● Parts Needed For ● Step 11 ● ● ● ● ● Right Gable Assembly (2) Gables/Braces ● ● ● ● ● 6658 Gable Brace (2) BY 24 Lift and fasten a right and left gable, under angle at corner, to the rear wall angle with screws.
  • Page 25 ● Parts Needed For ● ● ● ● ● ● Main Roof Beam (1) Step 12 ● ● ● ● ● Outer Roof Beam (2) Roof Beams BY25 Fasten the main roof beam to the gable brace of the front gable. STEP Fasten the other end of the main roof beam to the gable brace of the...
  • Page 26 ● Parts Needed For ● Step 13 ● ● ● ● ● 8466 Right Roof Panel (1) Right Roof Panel STEP Installing the roof panels is best done with a step ladder. Begin installing 8466 8467 roof panels at the back right corner of the building.

  • Page 27: Roof Assembly

    ● ● ● ● ● 8466 Right Roof Panel (1) ● Parts Needed For ● ● ● ● ● ● 8467 Left Roof Panel (2) Step 14 ● ● ● ● ● 7875 Roof Panel (2) Roof Assembly ● ● ● ● ● 9978 Roof Panel (2) BY27 STEP Install a left roof panel at the left...
  • Page 28 ● ● ● ● ● 8840 Ridge Cap (1) ● Parts Needed For ● Step 15 ● ● ● ● ● 9978 Roof Panel (2) Ridge Caps & Panels ● ● ● ● ● 8486 Ridge Cap (1) BY28 Install the first ridge cap on the completed roof section using bolts and nuts.
  • Page 29 ● Parts Needed For ● ● ● ● ● ● 8485 Left Side Roof Trim (2) Step 16 ● ● ● ● ● 8836 Right Side Roof Trim (2) Roof Trim Attach the right and left side roof trim to the lower end of the roof pan- els on each side of the building using screws at each panel overlap.

  • Page 30: Door Assembly

    ● ● ● ● ● 10488 Right and Left Doors (2) ● Parts Needed For ● Step 17 ● ● ● ● ● 10498 Horizontal Door Brace (4) Door Assembly ● ● ● ● ● 9355 Vertical Door Brace (2) The steps on this page tell how to assemble the right door.
  • Page 31 ● Parts Needed For ● ● ● ● ● ● Right Door Assembly (1) Step 18 ● ● ● ● ● Left Door Assembly (1) Door Installation & Adjustment Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP...
  • Page 32 BD88 MO88 NW88P-A WM88 BY32 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.

This manual is also suitable for:

Mo88Wm88Nw88p-a
