Maintenance; Replacement Parts - Hayward WFL100 ColorLogic Owner's Manual

Step 1: Use a 1¼" socket bit to remove the Laminar Jet cap to access screens. Remove the
union on the bottom to access diffusers.
Step 2: Remove any debris that may have been captured during operation. Refer to the diagram
below for disassembly and maintenance. NOTE: O-rings should be re-lubricated as
needed.
ITEM PART NUMBER
1
2 GLXWFLLIDDKGRY
3
4
5
6
7 GLXWFLDISRPT
8 GLXWFLLDSCRWPK10
9 GLXWFLSCRNPK5
10 GLXWFLGASKET
11 GLXWFLVLVADPT
12
11
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

Maintenance

Replacement Parts

GLXWFLLIDGRY
GLXWFLJET
GLXWFLHOSE
GLXWFLOPTC
GLXWFLTUBE
GLXWFLTSPLT
DESCRIPTION
LIGHT GREY LID, DECK NICHE
DARK GREY LID, DECK NICHE
LAMINAR JET
WATER INLET ASSEMBLY
OPTIC BOTTOM SEAL PLATE
TUBING ASSEMBLY
DISRUPTOR ASSEMBLY
DECK NICHE LID SCREW, 10PK
SCREEN, 5PK
LAMINAR GASKET KIT
VALVE ADAPTER KIT
TOP SEAL PLATE
QTY
1
1
1
1
1
1
1
1
1
1
1
1
