Trouble Shooting
Error message list for errors displayed on the status monitor during printing.
Error
Code
200
The door cover is open.
201
There is no tape.
202
A tape feed error is going on.
The remaining tape length is not enough to detect
203
the remaining length.
The color of the loaded ink ribbon does not tally
311
with the output color. Load[Rplc].
Unable to get the necessary ink ribbon information.
314
Check whether the ink ribbon is loaded properly or
the dedicated ink ribbon is loaded.
No remaining ribbon. Replace it with another ink
315
ribbon with the sufficient remaining length.
The ink ribbon is running out. (2 m or less)
The ribbon may run out while printing.
310
To continue, select a desired printing color from the
following list and click""Continue Print"".
The ribbon has not been loaded or a non-special
ribbon has been loaded. Check the ribbon.
301
For the special ribbon, ""SL-RXXXT"" is indicated
on the ribbon cassette. If ""T"" is not indicated, click
on ""Continue Print"" to print.
There is no print data corresponding to the set
ribbon color. Replace the ribbon. To continue as it
303
is, select a desired printing color from the following
list and click on ""Continue Print"".
There is no print data corresponding to the set
ribbon color. Replace the ribbon.
304
The remaining ribbon length is running out. (2 m or
shorter). The ribbon may run out while printing.
Unable to get the necessary ink ribbon information,
316
which may result in unsuccessful print.
To continue, click ""Continue print"".
The characteristics of the loaded ink ribbon is not
compatible with the output color, which may result
317
in unsuccessful output of the desired color.
To continue, click ""Continue Print"".
The characteristics of the loaded ink ribbon is not
compatible with the output color, which may result
318
in unsuccessful output of the desired color.
Besides, the ink ribbon is running out. (2 m or less)
The ribbon may run out while printing.
400
The door cover is open.
401
There is no tape.
402
There is no ribbon.
403
Cannot detect the leading end of the tape.
404
A tape feed error is going on.
405
The remaining tape length is not enough for printing.
BepopPC EX Software Installation
33
Error Message
Printer LED
Status
Close the door cover of the main body.
Red
Set new tape roll in the main body.
Red
Please insert a Max Brand tape that is ends with a N.
Red
Insert a tape role with enough length to print the
Red
data.
Please set the color ribbon that is specified by the
Green
Status Monitor.
Open the door cover, and check that the ink ribbon
Red
is properly inserted.
Insert an ink ribbon with enough remaining length.
Red
Please prepare a ribbon with enough length to print.
Green
Correctly insert the specialized ink ribbon.
Green
Please use the ink ribbon that is used in your layout.
Green
Use a ribbon that is used in your layout, and has
Green
enough remaining length to print.
Insert the specialized ink ribbon correctly continue
Green
with printing.
Process color ribbons are being used in a pure
color layout, or regular ribbons are being used for
Green
a process color layout. Please insert ribbons that
appropriate for the chosen layout.
Insert a ribbon that has enough length and is
Green
appropriate for the layout settings.
Close the door cover of the main body. \nIf the data
was being printed, click on the "Cancel Print" button
Red
and redo printing.
Set new tape in the main body. \nIf the data was
being printed, click on the ""Cancel Print"" button
Red
and redo printing.
Set new ribbon in the main body. \nIf the data was
being printed, click on the ""Cancel Print"" button
Red
and redo printing.
View help by pressing the [Remedy] button, take a
correct measurement of the tape. \nIf the data was
Red
being printed, click on the ""Cancel Print"" button
and redo printing.
After canceling the print using the status monitor, restart
the printer, insert Max Brand tape rolls. The correct
Red
sheet should have a N on the end of the product name.
After canceling the print using the status monitor,
restart the printer, insert a tape roll with enough
Red
length to finish the layout, and please reprint.
Solution Reference
Pg. 6
Pg. 7
Pg. 7
Pg. 7
Pg. 8
Pg. 8
Pg. 8
Pg. 8
Pg. 8
Pg. 8
Pg. 8
Pg. 8
Pg. 8
Pg. 8
Pg. 6
Pg. 7
Pg. 8
Pg. 7
Pg. 7
Pg.7
