Camera Specifications
Image Sensor
1/4" Color
Video Format / Pixels
NTSC: 640(H) x 480 (V)
Horizontal Resolution
420 TVL
Internal; 2:1 Interlace
Sync. & Scan. Systems
S/N Ratio
> 48dB
Iris & Shutter Speed
AES; 1/30 ~ 1/625,000 sec.
Minimum Illumination
0 LUX (IR LEDs on)
Video Output
Comp. 1.0 Vpp @ 75ohm
Lens / Lens Mount
3.6 mm F1.8/ Fixed
FOV (diagonal)
64 Degrees
Termination
Video: BNC Female
Power: Barrel Female
IR / Night Vision Range
18 IR LED/40 ft. / 12 m
Power Requirement
12V DC ±10%
Power Consumption
170 mA or 2W max
Operating Temp.
14°F ~ 122°F
(-10°C ~ 50°C)
Weight (with stand)
0.6 lbs. / 0.26 kg
Dimensions
2.6" x 4.2"" x 5.2"
WxLxH
66 mm x 107 mm x 132 mm
(with stand)
Dimensions
INDOOR / OUTDOOR
COLOR CAMERA
with Night Vision
MODEL: DBB13TL SERIES
QUICK START GUIDE
English Version 1.0
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for FLIR DBB13TL-PK4
Summary of Contents for FLIR DBB13TL-PK4
-
Page 1: Camera Specifications
Camera Specifications INDOOR / OUTDOOR Image Sensor 1/4” Color COLOR CAMERA Video Format / Pixels NTSC: 640(H) x 480 (V) with Night Vision Horizontal Resolution 420 TVL Internal; 2:1 Interlace Sync. & Scan. Systems MODEL: DBB13TL SERIES S/N Ratio > 48dB Iris &... -
Page 2: Installing The Camera
4. Connect the included 12V DC Power Adaptor to the warranty. camera(s). * Model DBB13TL-PK4 is a 4-pack that includes four of the listed items. ** A "4-in-1" Power Adapter that provides power to four cameras may be AC Power Adapter substituted for four individual power adapters, depending on product configuration.
