Tech Controllers ST-292 User Manual page 20

TECH
Editing
weekdays
parameters
If the user wants to edit programs 7÷9, it is possible to edit the settings for each day separately.
Press MENU in order to select a day.
Editing
parameters for
Monday
Step 3 – assign comfort temperature or economical temperature to particular hours
An hour which is being edited is displayed on the controller screen. In order to assign comfort
temperature, press . In order to select economical temperature, press . The controller
automatically moves on to editing the next hour.
Edited hour
The parameters of the weekly program are displayed at the bottom of the screen: hours to which
comfort temperature has been assigned are displayed whereas hours to which economical
temperature has been assigned are not displayed.
Example:
The following screenshot presents daily settings of
program no. 7 for Monday
24⁰⁰-01⁵⁹- economical temperature
02⁰⁰-06⁵⁹- comfort temperature
07⁰⁰-14⁵⁹- economical temperature
15⁰⁰-21⁵⁹- comfort temperature
22⁰⁰-00⁵⁹- economical temperature
