ST-292 User's manual

VII.b) Main screen view and description

The user operates the device using buttons. While one parameter is being edited, the remaining
icons are not displayed.
1
2
1. Display
2. EXIT - pressing this button in the main screen view activates weekly control mode or
day/night mode. After entering the menu, this button is used to confirm the settings and
return to the main screen view.
3. Minus button (
and decreases the pre-set temperature. After entering the menu, this button is used to
adjust parameters, enter the service code etc.
4. Plus button (
and increases the pre-set temperature. After entering the menu, this button is used to
adjust parameters, enter the service code etc.
5. MENU button – hold this button in order to enter the controller menu. While editing
parameters press this button to confirm the changes and move on to edit the next
parameter.
3
) – pressing this button in the main screen view activates manual mode
) – pressing this button in the main screen view activates manual mode
4
13
5
