Tech Controllers ST-292 User Manual page 14

4
3
2
1
1. Current operation mode:
a. weekly
b. manual
c. day/night
2. Current temperature of the room
3. Parameters icons (see: table below)
4. Day of the week
5. Icon indicating economical temperature (according to weekly control or day/night
settings)
6. Icon indicating comfort temperature (according to weekly control or day/night settings)
7. Icon which indicates displaying current external temperature (no. 9 on the display),
active only with wireless controllers (ST-292v2, ST-292v4) or with external temperature
sensor.
8. Icon which indicates displaying current floor temperature (no. 9 on the display) – it is
necessary to connect the floor sensor and activate it in the controller menu.
9. External temperature alternately with floor temperature
10. Pre-set temperature of the room
11. Time
12. Battery level
13. Temperature information (depending on the current operation mode):
heating mode - the icon is flashing when the pre-set temperature of the room has
o
not been reached and it is steady when the pre-set temperature has been reached.
cooling mode – the icon is moving when the room temperature is above the pre-
o
set value and it is steady when the pre-set temperature has been reached.
5
13
6
7
8
12
14
TECH
9
3
10
11
