- Page 1 Colour LED Card For XMC1000 Family inLight_RGB_V3 Colour LED Card Board User's Manual Revision 1.0, 2013-03-08 Microcontroller...
- Page 2 Infineon Technologies components may be used in life-support devices or systems only with the express written approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure of that life-support device or system or to affect the safety or effectiveness of that device or system. Life support devices or systems are intended to be implanted in the human body or to support and/or maintain and sustain and/or protect human life.
- Page 3 Colour LED Card Revision History Page or Item Subjects (major changes since previous revision) Revision 1.0, 2013-03-08 Trademarks of Infineon Technologies AG AURIX™, C166™, CanPAK™, CIPOS™, CIPURSE™, EconoPACK™, CoolMOS™, CoolSET™, CORECONTROL™, CROSSAVE™, DAVE™, DI-POL™, EasyPIM™, EconoBRIDGE™, EconoDUAL™, EconoPIM™, EconoPACK™, EiceDRIVER™, eupec™, FCOS™, HITFET™, HybridPACK™, I²RF™, ISOFACE™,...
-
Page 4: Table Of Contents
inLight_RGB_V3 Colour LED Card Table of Contents Overview ............................. 7 Key Features ............................7 Block Diagram ............................7 Hardware Description ........................8 RGB LEDs ............................8 Digital Addressable Lighting Interface (DALI) ..................9 ... - Page 5 inLight_RGB_V3 Colour LED Card List of Figures Figure 1 Block Diagram of Colour LED Card in connection with XMC1200 CPU Card ........7 Figure 2 Colour LED Card ..........................8 Figure 3 9 channels from BCCU module to control the three RGB LED modules ..........9 ...
- Page 6 inLight_RGB_V3 Colour LED Card List of Tables Table 1 BCCU signal connection to the SAMTEC 2x30pins Connector ............9 Table 2 DALI signal connection to the SAMTEC 2x30pins connector ............10 Table 3 DMX512 signals connection to the SAMTEC 2x30pins connector ............ 11 ...
-
Page 7: Overview
Colour LED Card Introduction This document describes the features and hardware details of the Colour LED Card (inLight_RGB_v3) designed to work with Infineon‟s XMC1200 CPU Card. This board is part of Infineon‟s XMC1000’s LED Lighting Application Kit. Overview The Colour LED Card is an application expansion card of XMC1000 LED Lighting Application Kit. This application card along with a XMC1200 CPU Card demonstrates the LED lighting capabilities of XMC1200/XMC1300. -
Page 8: Hardware Description
inLight_RGB_V3 Colour LED Card Hardware Description The following sections give a detailed description of the hardware and how it can be used. Figure 2 Colour LED Card RGB LEDs The Colour LED Card supports individual control of three OSRAM RGB LEDs (LRTB-G6SF), namely LED1, LED2, LED3, on board.The forward voltage V is 2 ~ 3.2 V @ I =20mA. -
Page 9: Digital Addressable Lighting Interface (Dali)
inLight_RGB_V3 Colour LED Card Figure 3 9 channels from BCCU module to control the three RGB LED modules Table 1 shows the connection of the BCCU signals to the SAMTEC 2x30pins connector. Table 1 BCCU signal connection to the SAMTEC 2x30pins Connector Pin No. -
Page 10: Dmx512/ Remote Device Management (Rdm)
inLight_RGB_V3 Colour LED Card Figure 4 DALI PHY circuit Table 2 DALI signal connection to the SAMTEC 2x30pins connector Pin No. Signal Name Description DALI_RX DALI data received DALI_TX DALI data transmit DMX512/ Remote Device Management (RDM) The Colour LED Card supports DMX512 interface on board with RS-485 transceiver (MAX481CSA). The DMX512 connector X4 consists of a 120 ohms termination resistor between DATA+ and DATA- and a Ground pin. -
Page 11: 433Mhz Rf Receiver
inLight_RGB_V3 Colour LED Card Table 3 shows the connection of the DMX512 signals to the SAMTEC 2X30pins connector. Table 3 DMX512 signals connection to the SAMTEC 2x30pins connector Pin No. Signal Name Description DMX512_TX DMX512 data transmit out DMX512_RX DMX512 data receive in DMX512_DIR Transceiver direction control 433MHz RF Receiver... -
Page 12: Power
inLight_RGB_V3 Colour LED Card Figure 7 Ambient Light Sensing Circuit Table 5 shows the connection of the DMX512 signals to the SAMTEC 2X30pins connector. Table 5 Light sensing signals connection to the SAMTEC 2x30pins connector Pin No. Signal Name Description AMB_LT Light sensing output Power... -
Page 13: Figure 9 Samtec 2X30Pins Samtec Connector
inLight_RGB_V3 Colour LED Card Figure 9 SAMTEC 2x30pins SAMTEC connector Board User's Manual Revision 1.0, 2013-03-08... -
Page 14: Production Data
inLight_RGB_V3 Colour LED Card Production Data Schematics This chapter contains the schematics for the Colour LED Card: • SAMTEC Connector, Power, 9 channels LED driver, DALI interface, DMX512/RDM interface, 433MHz RF Receiver. Board User's Manual Revision 1.0, 2013-03-08... -
Page 15: Figure 10 Schematic Of Colour Led Card
inLight_RGB_V3 Colour LED Card Figure 10 Schematic of Colour LED Card Board User's Manual Revision 1.0, 2013-03-08... -
Page 16: Layout And Geometry
inLight_RGB_V3 Colour LED Card Layout and Geometry Figure 11 Colour LED Card layout and geometry Bill of Materials Table 7 Colour LED Card BOM Value Device Reference Designator HSEC8-130-01-L-RA HSEC8 socket, SAMTEC MKDS1/2-3,81 3.81mm pitch, 2 way, X2,X3,X4 Phoenix MB6S Bridge Rectifier, Fairchild 22uF/50V/10%/1210... - Page 17 inLight_RGB_V3 Colour LED Card Value Device Reference Designator 10nF/16V/10%/0603 Capacitor C19,C21 22nF/16V/10%/0603 Capacitor C7,C11 47nF/16V/10%/0603 Capacitor C10,C14,C23 330nF/10V/10%/0603 Capacitor BZX84C2V7/SOT23 Zener diode 2.7V, BAS16/TO236 Diode BCR421/SC74 LED driver, Infineon IC1,IC2,IC3,IC4,IC5,IC6,IC7,IC8,IC9 TDA7200/TSSOP28 ASK/FSK receiver, IC10 Infineon MAX481CSA/SO08 RS-485 transceiver, IC11 Maxim SFECF10M7EA00 10.7MHz BP filter, Murata...
- Page 18 . i n f i n e o n . c o m Published by Infineon Technologies AG...
- Page 19 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Infineon KIT_XMC1x_AK_LED_001...
