32-Bit
Microcontroller
TriBoard TC2X3
Hardware: TriBoard-TC2X3 V1.1
Hardware Manual
User's Manual
V 1.2 2014-10
M i c r o c o n t r o l l e r s

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TriBoard TC2X3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Infineon Technologies TriBoard TC2X3

Summary of Contents for Infineon Technologies TriBoard TC2X3

  • Page 1 32-Bit Microcontroller TriBoard TC2X3 Hardware: TriBoard-TC2X3 V1.1 Hardware Manual User’s Manual V 1.2 2014-10 M i c r o c o n t r o l l e r s...
  • Page 2 Infineon Technologies components may be used in life-support devices or systems only with the express written approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure of that life-support device or system or to affect the safety or effectiveness of that device or system. Life support devices or systems are intended to be implanted in the human body or to support and/or maintain and sustain and/or protect human life.
  • Page 3 32-Bit Microcontroller TriBoard TC2X3 Hardware: TriBoard-TC2X3 V1.1 User’s Manual V 1.2 2014-10 M i c r o c o n t r o l l e r s...
  • Page 4 Trademarks ® TriCore is a trademark of Infineon Technologies AG. We Listen to Your Comments Any information within this document that you feel is wrong, unclear or missing at all? Your feedback will help us to continuously improve the quality of this document.

  • Page 5: Table Of Contents

    TriBoard TC2X3 Hardware Manual Table of Contents Introduction ..........1-1 TriBoard Features .
  • Page 6 TriBoard TC2X3 Hardware Manual Schematic and Layout ........7-1 Schematic .
  • Page 7 TriBoard Block Schematic ....... . . 2-3 Figure 2-2 TriBoard TC2X3 V1.1 Placement......2-4 Figure 3-1 Resistors for power supply.
  • Page 8 TriBoard TC2X3 Hardware Manual User’s Manual V 1.2, 2014-10...
  • Page 9 TriBoard TC2X3 Hardware Manual List of Tables Table 4-1 User Startup Modes for TC233,TC223, TC213 ....4-1 Table 4-2 General optional resistors ....... . . 4-3 Table 4-3 Resistors for peripherals .
  • Page 10 TriBoard TC2X3 Hardware Manual User’s Manual V 1.2, 2014-10...
  • Page 11 TriBoard TC2X3 Hardware Manual User’s Manual V 1.2, 2014-10...

  • Page 12: Introduction

    TriBoard TC2X3 Hardware Manual Introduction Introduction We congratulate you on your purchase of the TriCore Evaluation Board. This kit is a versatile tool, providing quick access to the capabilities of TriCore's powerful architecture. Applications can be developed easily. The Evaluation Board is equipped with a variety of memories and peripherals for connection to the environment.
  • Page 13 TriBoard TC2X3 Hardware Manual Introduction User’s Manual V 1.2, 2014-10...

  • Page 14: Triboard Features

    TriBoard TC2X3 Hardware Manual TriBoard Features TriBoard Features Summary of Features – Infineon’s TC2X3 (TC233, TC223, TX213) Controller in TQFP-100 Package with 0,4mm pitch – FlexRay Transceivers – Safety device (optional) – High Speed CAN Transceivers – USB to UART bridge –...
  • Page 15 TriBoard TC2X3 Hardware Manual TriBoard Features – SPI eeprom (Atmel) – 8 general purpose LEDs – Reset switch – 4-pin Dip switch Zero Ohm Bridges Zero Ohm resistors give the flexibility to configure the systems functionality User’s Manual V 1.2, 2014-10...

  • Page 16: Block Diagram

    TriBoard TC2X3 Hardware Manual TriBoard Features Block Diagram XTAL CAN0 TxCAN0 RxCAN0 TC2X3 Transceiver CAN1 TxCAN1 RxCAN1 (TC233, TC223, TC213) OCDS1 Micro TriCore miniWiggler Transceiver Safety Device SAK-CIC61508 optional 8 LED’s Serial EEPROM POWER SUPPLY WITH (P11.8...11 and SUPERSONIC TL7368-3E P13.0...3)

  • Page 17: Placement

    U401 X403 ERAY-A SEND CAN0 SENC U202 ERAY-B JP202 CAN1 U201 X402 C202 JTAG SENB JP201 /PORST JP203 +3V3 +1V3 SENA RST_CIC S202 POWER U601 RESET_CIC X703 X702 +5,5V...+50V(+40V) Figure 2-2 TriBoard TC2X3 V1.1 Placement User’s Manual V 1.2, 2014-10...

  • Page 18: Triboard Information

    TriBoard TC2X3 Hardware Manual TriBoard Information TriBoard Information Power Supply The microcontroller needs 2 or 3 different supply voltages. This voltages are generated internally via Infineons Next generation microcontroller supply TLE 7368-3E (+5V; +3,3V; +1,3V) or via the microcontroller itself (+1,3V).

  • Page 19: Leds

    TriBoard TC2X3 Hardware Manual TriBoard Information Make sure that only one of the resistors R638 or R457 (all resistors are red marked in Figure 3-1) is assembled each time.. X801 X804 C404 R232 CB413 C405 L402 R414 R404 R250 R438...

  • Page 20: Clock

    TriBoard TC2X3 Hardware Manual TriBoard Information Clock On the board is a fixed crystal wiith 20MHz assembled. You can change this by replacing Y201 (soldered). USB Connector The USB connector is used for connection to a PC. Via the USB it is possible to power the board, using the ASCLIN0 as serial connection via USB and Debugging via DAS.

  • Page 21: Miniwiggler Jds

    TriBoard TC2X3 Hardware Manual TriBoard Information assemble R436 and R437 with 0R (red marked in Figure 3-2). Please note that in this case CAN0 is longer working. X801 X804 C404 R232 CB413 C405 L402 R414 R404 R250 R438 R419 CB411...

  • Page 22: Serial Eeprom

    TriBoard TC2X3 Hardware Manual TriBoard Information crimpconnector, flat cable and SUB-D 9 plug with crimpconnector to have a 1:1 adapter to SUB-D 9. The transceiver are connected directly to the TriCore device. For more information look in the user manual for TC2X3. Only usable with TC233.

  • Page 23: Other Peripherals

    TriBoard TC2X3 Hardware Manual TriBoard Information 3.10 Other peripherals For all other peripherals there are no special plugs on the board. The peripheral signals are available on the different connectors. See “Connector Pin Assignment” on Page 5-1. Note: - SLSO07 is used as chip select for the serial eeprom on board.
  • Page 24 TriBoard TC2X3 Hardware Manual TriBoard Information Important: When the resistors are removed then only the DAP connector on the board can be used. The on board wiggler and the OCDS1 connector couldn’t be use (are disconnected) in this case. X704...
  • Page 25 TriBoard TC2X3 Hardware Manual TriBoard Information User’s Manual V 1.2, 2014-10...

  • Page 26: Triboard Configuration

    TriBoard TC2X3 Hardware Manual TriBoard Configuration TriBoard Configuration HW Boot Configuration Figure 4-1 HW Configuration TC2X3 DIP-Switch The picture above shows the definition of the boot HW configuration switch. The meaning of the switches will be described in the following table (Table 4-1).
  • Page 27 TriBoard TC2X3 Hardware Manual TriBoard Configuration Table 4-1 User Startup Modes for TC233,TC223, TC213 Note: The shadowed line indicates the default setting. Note: ’x’ represents the don’t care state. Note: 2 to 4 are the Dip Switch numbers HWCFG[5...3] Type of Boot TC233, TC223, TC213...

  • Page 28: Assembly Options

    TriBoard TC2X3 Hardware Manual TriBoard Configuration Assembly Options Table 4-2 General optional resistors Component Description R202 Connect P20.2 (/TESTMODE) to GND (default: not assembled) R206 XTAL Rparallel (default: not assembled) R207 XTAL Rserial (default: assembled) R423 Connect P21.6 with miniWiggler JDS (default: not assembled) R424 Connect P21.6 with OCDS1 connector (default: not assembled)
  • Page 29 TriBoard TC2X3 Hardware Manual TriBoard Configuration Note: All resistors are red marked in the following figures X704 X701 R510 X403 Y401 CB401 R213 U401 R512 R513 R515 R518 R514 R516 R517 R402 R403 C402 R401 R231 CB402 R230 U407 U408...

  • Page 30: Table 4-3 Resistors For Peripherals

    TriBoard TC2X3 Hardware Manual TriBoard Configuration Table 4-3 Resistors for peripherals Component Description R333 Connect P33.7 with RXD of CAN0 transceiver (default: assembled) R339 Connect P14.1 with RXD of CAN1 transceiver (default: assembled) R302 Connect P33.5 (SLSO07) with /CS of Eeprom (default: assembled) R364 Connect P20.9 with RXD of LIN1 transceiver (default: assembled)
  • Page 31 TriBoard TC2X3 Hardware Manual TriBoard Configuration Note: All resistors are red marked in the following figures X704 X701 R510 X403 CB401 Y401 R213 U401 R512 R513 R514 R515 R516 R517 R518 R402 R403 C402 R401 R230 R231 CB402 U407 U408...

  • Page 32: Table 4-4 Resistors For Safety Device

    TriBoard TC2X3 Hardware Manual TriBoard Configuration Table 4-4 Resistors for safety device Component Description R251 Connect potentiometer to sensor input D (default: assembled) R247 Connect potentiometer to sensor input C (default: assembled) R239/R240 Voltage divider to adapt VDDP3 to VAREF of safety device...
  • Page 33 TriBoard TC2X3 Hardware Manual TriBoard Configuration Note: All resistors are red marked in the following figures X801 X804 C404 R232 CB413 C405 L402 R414 R404 R250 R438 R419 CB411 R251 R626 R440 R442 U405 Q403 R418 R420 R449 R457 R248...

  • Page 34: Connector Pin Assignment

    TriBoard TC2X3 Hardware Manual Connector Pin Assignment Connector Pin Assignment The TriBoard will be shipped with four male (plug) connectors on top layer and four female (socket) connectors on bottom layer. The default connectors are 80-pol. Board to Board connectors from Samtec: http://www.samtec.com...

  • Page 35: Tc2X3 Connector / Top View

    TriBoard TC2X3 Hardware Manual Connector Pin Assignment TC2X3 Connector / Top View BUS EXPA NSION (Xx01,Xx01) PERIPHERA LS (Xx02,Xx02) VCC_IN VCC_IN VCC_IN VCC_IN 9 10 9 10 11 12 11 12 13 14 TDI / P21.6 13 14 15 16...
  • Page 36 TriBoard TC2X3 Hardware Manual Connector Pin Assignment VA DC (Xx03, Xx03) PORTS (Xx04,Xx04) VSSM VSSM VSSM VSSM AN16 AN17 9 10 AN18 ERAY0_TX DA / P02.0 9 10 11 12 AN19 ERAY0_RX DA2 / P02.1 11 12 P14.4 13 14 AN20 ERAY0_TX DB / P02.2 13 14...

  • Page 37: Power Connector Pinout

    TriBoard TC2X3 Hardware Manual Connector Pin Assignment Power connector pinout +5,5V...50V(40V) Figure 5-3 Power connector pinout USB connector pinout Figure 5-4 USB connector Pinout Flexray Pinout Figure 5-5 Flexray Pinout (IDC10 User’s Manual V 1.2, 2014-10...

  • Page 38: Can Connector Pinout

    TriBoard TC2X3 Hardware Manual Connector Pin Assignment CAN connector pinout Figure 5-6 CAN connector pinout (IDC10) LIN connector pinout Figure 5-7 LIN connector pinout (IDC10) User’s Manual V 1.2, 2014-10...

  • Page 39: Ocds Connector Pinout

    TriBoard TC2X3 Hardware Manual Connector Pin Assignment OCDS connector pinout Figure 5-8 OCDS connector pinout (IDC16) DAP connector pinout Figure 5-9 DAP connector pinout (FTSH10) User’s Manual V 1.2, 2014-10...

  • Page 40: Signal Description

    TriBoard TC2X3 Hardware Manual Signal Description Signal Description For more information about the signals please see the user manuals for TC2X3 and/or the schematics of the board. Table 6-1 Power Signals Short Name Description VCC_IN Supply Input (5,5V...50V(40V)) Input voltage of power supply device...

  • Page 41: Table 6-4 Clock Signals

    TriBoard TC2X3 Hardware Manual Signal Description Table 6-4 Clock Signals Short Name Description XTAL1 Crystal Oscillator Input XTAL2 Crystal Oscillator Output XTAL1_CIC Crystal Oscillator Input safety device XTAL2_CIC Crystal Oscillator Output safety device Table 6-5 Debug Signals Short Name Description...

  • Page 42: Table 6-7 Safety Device Signals

    TriBoard TC2X3 Hardware Manual Signal Description Table 6-6 Peripheral Signals P33.7 CAN node 0 Receiver Input P14.0 CAN node 1 Transmitter Output P14.1 CAN node 1 Receiver Input P15.0 CAN node 2 Transmitter Output P15.1 CAN node 2 Receiver Input P20.10...
  • Page 43 TriBoard TC2X3 Hardware Manual Signal Description Table 6-7 Safety device Signals MRST_CIC Master Receive / Slave Transmit SAK-CIC61508 MTSR_CIC Master Transmit / Slave Receive SAK-CIC61508 /CS_CIC Slave Select Input SAK-CIC61508 SYSDISA System Disable Output A SYSDISB System Disable Output B...

  • Page 44: Schematic And Layout

    TriBoard TC2X3 Hardware Manual Schematic and Layout Schematic and Layout Schematic User’s Manual V 1.2, 2014-10...

  • Page 45: Figure 7-1 Schematic - Project

    TriBoard TC2X3 Hardware Manual Schematic and Layout Figure 7-1 Schematic - Project User’s Manual V 1.2, 2014-10...

  • Page 46: Figure 7-2 Schematic - Clock, Jtag And Cic61508

    TriBoard TC2X3 Hardware Manual Schematic and Layout Figure 7-2 Schematic - Clock, JTAG and CIC61508 User’s Manual V 1.2, 2014-10...

  • Page 47: Figure 7-3 Schematic - Flexray, Can And Eeprom

    TriBoard TC2X3 Hardware Manual Schematic and Layout Figure 7-3 Schematic - Flexray, CAN and Eeprom User’s Manual V 1.2, 2014-10...

  • Page 48: Figure 7-4 Schematic - Miniwiggler Jds, Dap And Etk

    TriBoard TC2X3 Hardware Manual Schematic and Layout Figure 7-4 Schematic - miniWiggler JDS, DAP and ETK User’s Manual V 1.2, 2014-10...

  • Page 49: Figure 7-5 Schematic - Ports, Config, Leds And Adc

    TriBoard TC2X3 Hardware Manual Schematic and Layout Figure 7-5 Schematic - Ports, Config, LEDs and ADC User’s Manual V 1.2, 2014-10...

  • Page 50: Figure 7-6 Schematic - Power Supply

    TriBoard TC2X3 Hardware Manual Schematic and Layout Figure 7-6 Schematic - Power Supply User’s Manual V 1.2, 2014-10...

  • Page 51: Figure 7-7 Schematic - Connectors (Plug)

    TriBoard TC2X3 Hardware Manual Schematic and Layout Figure 7-7 Schematic - Connectors (Plug) User’s Manual V 1.2, 2014-10...

  • Page 52: Figure 7-8 Schematic - Connectors (Socket)

    TriBoard TC2X3 Hardware Manual Schematic and Layout Figure 7-8 Schematic - Connectors (Socket) User’s Manual V 1.2, 2014-10...

  • Page 53: Layout

    TriBoard TC2X3 Hardware Manual Schematic and Layout Layout Figure 7-9 Component Plot Top Layer User’s Manual 7-10 V 1.2, 2014-10...

  • Page 54: Figure 7-10 Component Plot Bottom Layer

    TriBoard TC2X3 Hardware Manual Schematic and Layout R239 R240 CB205 C205 C206 R255 Y202 C212 CB206 R252 CB606 CB603 R629 C619 CB602 CB504 R524 R525 R501 R339 CB317 Q604 CB318 R337 R343 R605 U305 U304 R338 R344 R436 R334 R341 R340...

  • Page 55: Layout With Dimensioning

    TriBoard TC2X3 Hardware Manual Schematic and Layout Layout with Dimensioning The following dimensions should be used for development of extension boards. Note: these pictures from TriBoard TC1798. Connectors X701/X801...X704/804 are on the same place. CAN0 CAN1 Figure 7-11 Dimensioning (mil) User’s Manual...

  • Page 56: Figure 7-12 Dimensioning (Mm)

    TriBoard TC2X3 Hardware Manual Schematic and Layout CAN0 CAN1 Figure 7-12 Dimensioning (mm) User’s Manual 7-13 V 1.2, 2014-10...
  • Page 57 TriBoard TC2X3 Hardware Manual Keyword Index LIN connector pinout 5-5 Location of general optional resistors on ACTIV LED 3-4 Bottom Side 4-4 Assembly Options 4-3 Location of general optional resistors on Top Side 4-4 Location of peripheral resistors on Bottom...
  • Page 58 Serial EEPROM 3-5 Serial Eeprom 3-5 Signal Description 6-1 status LED 3-6 Supply 3-1 Toggle LED’s 3-6 TriBoard TC2X3 V1.1 Placement 2-4 Type of Boot TC233, TC223, TC213 4-1 USB Connector 3-3 USB connector pinout 5-4 User’s Manual V 1.2, 2014-10...
  • Page 59 . i n f i n e o n . c o m Published by Infineon Technologies AG...
