XM C 400 0 Applic atio n Ki t
For XMC4000 Family
CP U_ 45 A - V3
CPU Board XMC4500 General Purpose
Boa rd Us er's Ma nu al
Revision 1.0, 2014-01-10
Mic rocon t rolle r
