Summary of Contents for Infineon Technologies XMC4500 Relax kit
- Page 1 E valu atio n B oar d For XMC4000 Family XM C 450 0 Rela x Ki t & XM C 450 0 Rela x Lit e Kit Kit Version 1 Boa rd Us er‘s Ma nu al Revision 1.2, 2014-01-13 Mic rocon t rolle r...
- Page 2 Infineon Technologies components may be used in life-support devices or systems only with the express written approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure of that life-support device or system or to affect the safety or effectiveness of that device or system. Life support devices or systems are intended to be implanted in the human body or to support and/or maintain and sustain and/or protect human life.
- Page 3 Correction of DAVE™3 trademark Revison 1.1, 2012-11-09 Revison 1.2, Notes have been added to Figure 5 (Pins of Pin Header X1 / X2 are partly used also for on- board circuits) 2014-01-13 Trademarks of Infineon Technologies AG AURIX™, C166™, CanPAK™, CIPOS™, CIPURSE™, EconoPACK™, CoolMOS™,...
-
Page 4: Table Of Contents
XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 Table of Contents Table of Contents Introduction ................................7 Overview ............................. 7 Key Features ............................7 Block Diagram ............................8 Hardware Description ........................9 Power Supply ............................. 11 Pin Header Connector ........................12 Production Data.......................... - Page 5 Block Diagram of the XMC4500 Relax/Relax Lite Kit-V1..............8 Figure 2 XMC4500 Relax Lite Kit-V1 ......................... 9 Figure 3 XMC4500 Relax Kit-V1 ........................10 Figure 4 Power Supply Concept ........................11 Figure 5 Signal mapping of the pin headers..................... 12 Mapping of communication peripherals to GPIOs and it’s corresponding functions ......
- Page 6 XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 List of Tables List of Tables Table 1 Features ............................... 7 Table 2 List of Material ............................ 18 Board Users Manual Revision 1.2, 2014-01-13...
-
Page 7: Introduction
Technologies AG. Overview The XMC4500 Relax Kit-V1 and the XMC4500 Relax Lite Kit-V1 are designed to evaluate the capabilities of the XMC4500 Microcontroller and the powerful, free of charge tool chain DAVE™. The XMC4500 Relax Kit extends the feature set with an Ethernet-enabled communication option, e.g. to run an embedded web server. You can store your own HTML web pages on a microSD Card or control the XMC4500 via the web browser on your PC. -
Page 8: Block Diagram
XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 Overview Block Diagram The block diagram in Figure 1 shows the main components of the XMC4500 Relax/Relax Lite Kit-V1 and their interconnections. There are following main building blocks: XMC4500 Microcontroller in a LQFP100 package ... -
Page 9: Hardware Description
XMC4500 Relax Lite Kit-V1 Hardware Description Hardware Description The following sections give a detailed description of the board hardware and how it can be used. Figure 2 shows the XMC4500 Relax Lite Kit-V1, Figure 3 shows the XMC4500 Relax Kit-V1. Evaluation Detachable Board... - Page 10 XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 Hardware Description Evaluation Detachable Board Debugger Ethernet RTC XTAL RJ45 & PHY Voltage Power Regulator Pin Header X1 Reset Button Pin Header X2 Cortex Debug Micro USB 12 MHz XTAL Debug (10Pin) qSPI Flash...
-
Page 11: Power Supply
Micro UBS plugs (X3, X100). Out of the box with the pre-programmed web server application and the on-board debugger in operation the XMC4500 Relax Kit-V1 typically draws about 250 mA. The XMC4500 Relax Lite Kit-V1 without the web server capabilities draws about 200 mA. This current can be delivered via the USB plug of a PC, which is specified to deliver up to 500 mA. -
Page 12: Pin Header Connector
XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 Hardware Description Pin Header Connector The pin headers X1 and X2 can be used to extend the evaluation board or to perform measurements on the XMC4500. Figure 5 shows the available GPIOs/signals at the pin headers. The pinning table is also printed onto the bottom side of the PCB. -
Page 13: Figure 6 Mapping Of Communication Peripherals To Gpios And It's Corresponding Functions
XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 Hardware Description UART UART-1 UART-2 UART-3 UART-4 P0.1 / U1C1.DOUT0 P1.5 / U0C0.DOUT0 P5.1 / U0C0.DOUT0 P0.5 / U1C0.DOUT0 P0.0 / U1C1.DX0D P1.4 / U0C0.DX0B P5.0 / U0C0.DX0D P0.4 / U1C0.DX0A I2C Master/Slave... -
Page 14: Production Data
XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 Production Data Production Data Schematics This chapter contains the schematics for the XMC4500 Relax/Relax Lite Kit-V1: Figure 7: CPU, Pin Headers, Buttons, LEDs, Reset Figure 8: On-board Debugger, Power Supply, Ethernet, Quad-SPI Memory, SD Card Slot, RTC Crystal Board Users Manual Revision 1.2, 2014-01-13... - Page 15 XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 Production Data Figure 7 CPU, Pin Headers, Buttons, LEDs, Reset Board Users Manual Revision 1.2, 2014-01-13...
- Page 16 XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 Production Data Figure 8 On-board Debugger, Power Supply, Ethernet, Quad-SPI Memory, SD Card Slot, RTC Crystal Board Users Manual Revision 1.2, 2014-01-13...
-
Page 17: Components Placement And Geometry
XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 Production Data Components Placement and Geometry ADJ_3 IC101 L200 C200 C202 50x 0.4mm X200 C203 C206 C201 JP500 JP501 drills, NPTH C210 IC200 R102 IC200 X100 C207 R204 R101 C205 L100 R203 X100... -
Page 18: List Of Material
XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 Production Data List of Material The list of material is valid for the XMC4500 Relax/Relax Lite Kit-V1. Table 2 List of Material Reference Qty Value Device Designator 2 2x4 Pin Header 0.1” TH... - Page 19 XMC4500 Relax Kit-V1 XMC4500 Relax Lite Kit-V1 Production Data Table 2 List of Material Reference Qty Value Device Designator 3 TMPS2-SMD Push Button SW1, SW2, SW3 1 7499010211A Ethernet RJ45 Plug, Würth X200 Microcontroller Cortex 2 XMC4500-F100F1024 M4F, Infineon IC1, IC100...
- Page 20 . i n f i n e o n . c o m Published by Infineon Technologies AG...
- Page 21 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Infineon KIT_XMC45_RELAX_V1...
