Features - Atmel STK521 User Manual

1.1

Features

Atmel AVR STK521 is a new member of the successful Atmel STK500 starter kit family
Supports the Atmel AT90PWM81, Atmel AT90PWM161
Supported by Atmel AVR Studio
Zero Insertion Force Socket for SOIC20 Package
Zero Insertion Force Socket for QFN32 Package (not populated)
High Voltage Parallel Programming
Serial Programming
6-pin Connector for On-chip Debugging using Atmel AVR JTAGICE mkII or Atmel AVR Dragon
emulators
Switches for Reset/GPIOs configuration, Xtal/GPIOs or power supply configuration
External power supply connector for standalone mode
Quick Reference to all Jumpers in the Silk-Screen of the PCB
STK521 User Guide
®
4.15 or above and Atmel AVR Studio 5.1
™
1-2
8194B–AVR–01/12
