Atmel STK521 test points

Table 2-6. STK521 test points.
Test Point
T1
T2
These are placed on both right and left side of the board for probes.
2.8

Extra functions

The STK521 includes a footprint for a ZIF QFN32 5x5 mm socket to evaluate QFN32 package. The
socket is not mounted but can be populated using the PN : QFN32(40)BT-0.5-02 from Enplas.
STK521 User Guide
Function
GND
GND
Description
GND test point
GND test point
