Summary of Contents for Ever W/PGRLTO-3310K0/00

  • Page 2: Table Of Contents

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual TABLE OF CONTENTS TABLE OF CONTENTS ..................................2 INTRODUCTION ....................................3 GENERAL FEATURES OF THE UPS UNIT ..........................4 SAFETY INSTRUCTIONS AND RECOMMENDATIONS......................7 TECHNICAL DESCRIPTION................................. 13 THE UPS UNIT DESIGN AND COMPONENTS ........................13 THE USER INTERFACE ................................
  • Page 3: Introduction

    This manual contains all relevant information to ensure correct and safe operation of the unit. Please read this manual carefully and thoroughly prior to using the EVER POWERLINE GREEN 33 LITE unit. This will help to operate the unit and correctly and safely.
  • Page 4: General Features Of The Ups Unit

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual GENERAL FEATURES OF THE UPS UNIT Alongside their excellent performance and reliability, the POWERLINE GREEN 33 LITE range of UPS units offers a number of other advantages which include:  On-line operation using real double conversion, with sinusoidal output voltage (with the highest quality VFI-SS-111 parameters).
  • Page 5 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual free outputs. It uses an integrated LCD operator’s control panel (with adjustable angle). All these are designed to allow a customised UPS remote control strategy.  Remote Emergency Power Off (Remote EPO) functionality which interrupts power supply from the UPS output to loads in extreme situations or in emergency (e.g.
  • Page 6 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Figure 1: Simplified block diagram of the UPS unit The rectifier transforms the alternating current voltage from the mains into direct current voltage. It also doubles as a battery charger. The DC voltage bus is the basic source of power for the inverter system which in turns generates sinusoidal AC voltage to be used to power the loads.
  • Page 7: Safety Instructions And Recommendations

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual SAFETY INSTRUCTIONS AND RECOMMENDATIONS A) General information CAUTION! Before starting the procedures described in this manual, please read the general safety instructions (including the instructions found in this document), health & safety information, environmental protection information and legal regulations that may apply.
  • Page 8 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual CAUTION! Opening the unit’s casing may result in electric shock. CAUTION! Do not touch any electrical connectors, terminals and internal metal elements unless power supply has been properly disconnected. CAUTION! All openings and spaces designed to provide access to the unit's electrical connections must remain covered (with applicable covers).
  • Page 9 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual CAUTION! The UPS may only be connected to a power system with indicated rated voltage, with a suitable grounding connection installed. The facility's electrical system to which the UPS unit is connected must be fitted with overload and short-circuit protection.
  • Page 10 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual  The electric system's grounding conductor leads the leakage current away from the receivers. The leakage currents of all loads connected to the UPS unit's output are totalized in the UPS unit's power lead. The summary leakage current may trigger protective devices (RCD) and result in disconnecting power to the loads.
  • Page 11 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual  WARNING: The unit described here is a C3 category UPS. This is a product designed for commercial and industrial applications, meeting the Second Environment levels. Additional precautions or restrictions to be observed during installation may be required to prevent the emission of interferences.
  • Page 12 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual  Disconnect the device from the mains before cleaning. Do not use liquid or sprayed cleaning agents.  UPS units may only be disassembled by suitably qualified service technicians. E) Transport and packaging requirements ...
  • Page 13: Technical Description

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual TECHNICAL DESCRIPTION THE UPS UNIT DESIGN AND COMPONENTS a) the 10-20 kVA model a) the 30-60 kVA model Figure 2: View of the rear panel. 1) EPO connector, 2) Communication connectors...
  • Page 14: The User Interface

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Figure 3: View of the connection terminals (on the rear panel, with the cover removed) 1) Protections and connections, main input lines (F4), 2) Connections, N neutral lines, 3) Connections, output lines, 4) PE protective cable connection point, 5) Tabs for connecting...
  • Page 15 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Figure 4: View of the user interface: The UPS unit also uses sound chimes for individual device states (see Table Table 1. Acoustic signal Action Acoustic signal NORMAL mode None HYBRID Mode Intermittent signal;...
  • Page 16 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Figure 5: Map of the LCD screens organised into the tree structure. Technical Service, tel.: +48 61 6500 400 www.ever.eu Type 01 2016-10-27 12:12...
  • Page 17: Screens

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual SCREENS SCREENSAVER The information page/screen starts to be displayed as a Description: screensaver after 5 minutes of inaction since the last button was pressed. It also turns off the LCD panel illumination.
  • Page 18: Main Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual i:PO SLAVE Slave unit in system i:PO UnitStopped UPS disconnected from the system There is no redundant units. The system i:PO RedundLost operates as parallel i:PO UnitNotActive UPS is not connected to the system...
  • Page 19: Measurements Sub-Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual The arrow to the left of the sub-menu name shows the actual position of the selection check mark. The arrow only appears once the screen has been confirmed by hitting key. To jump to the selected submenu or parameter, pressing the key.
  • Page 20 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual View of the screen: RECTIFIER 5/5 Description: The UPS unit’s input parameters Type: Readout Parameters: – summary input active power for rectifier – summary input apparent power for rectifier – rectifier input frequency (measured for the L1 line)
  • Page 21 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual View of the screen: BYPASS 5/5 Description: Input parameters for the BYPASS line Type: Readout Parameters: – BYPASS line input summary active power – BYPASS line input summary apparent power – BYPASS line frequency (measured for the L1 line) Percentage values - show the unit’s load levels...
  • Page 22 The algorithm to calculate predicted time offers the highest precision when the recommended types of batteries are used (for the list of recommended battery types, please see www.ever.eu). In case when batteries other than recommended are used, indications may become imprecise which means the actual available time of backup operation may differ from the indicated time (Tau).
  • Page 23 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual – battery charge level available (specified for the actual load) – predicted duration of autonomous operation View of the screen: BATTERY 2/2 Description: Battery parameters Type: Readout Parameters: – battery capacity level; the value is updated after batteries have been completely discharged.
  • Page 24: Control Sub-Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual View of the screen: CONTROL Sub-menu The Control sub+menu has been divided into four groups. Navigation within this menu is similar to the way shown earlier. The user may change the configuration of...
  • Page 25 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual and subsequent confirmation by pressing . Once accepted, the system takes the user one screen up in the screen tree structure. Accepting this parameter results in saving this parameter to the UPS unit’s memory.
  • Page 26 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual – temporary EPO input deactivation (1 min). TempDeactEPO – Manual overriding switching to the STANDBY mode (as per conditions set out in Table 5); UPS->STB switching after predefined time programmed in CONFIGURATION 2/4; STB Delay) –...
  • Page 27: Configuration Sub-Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual View of the screen: CONFIGURATION Sub-menu The CONFIGURATION sub-menu has been divided into seven groups. Navigation within this menu is similar to the way shown earlier. The user may change the UPS unit’s parameter settings provided the keypad has not been locked (locking the...
  • Page 28 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual CONFIGURATION 2/7 Description: Parameters of the UPS unit Type: Readout/Saving Parameters: – Setting the maximum (upper) voltage limit for the BYPASS UUppTresh line – Setting the minimum (lower) voltage limit for the BYPASS line ULowTresh –...
  • Page 29 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual View of the screen: CONFIGURATION 5/7 Description: Parameters of the UPS unit Type: Readout/Saving Parameters: – enter the capacity of the batteries used in the unit BatCapacity – Enter the number of battery blocks (total number of NbrOfStrings internal and external battery blocks).
  • Page 30: Alarms Sub-Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual disconnecting it is necessary to completely shutdown UPS. There is no possibility to logical add previously disconnected unit – Setting the required minimum number of units in the system. MinNmbrUnits This parameter defines whether a system is in redundant or parallel operation.
  • Page 31 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual ALARMS 1/3 Description: Alarms for the UPS unit Type: Readout Parameters: – Short circuit at UPS output (during inverter-based operation) Short circuit – Too high temperature in UPS internal components (rectifier) RecOverTemp –...
  • Page 32: Statistics Sub-Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual STATISTICS Sub-menu The STATISTICS sub-menu uses four screens. Navigation within this menu is similar to the way shown earlier. Screen selection is done by pressing the ▲▼ keys. To accept the selection, press .
  • Page 33: Panel Settings Sub-Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual – time duration of UPS operation in the NORMAL mode Normal – time duration of UPS operation in the BATTERY mode Battery View of the screen: STATISTICS 4/4 Description: Statistical data...
  • Page 34 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual – the level of brightness for the LCD display Backlight – the keypad lock indicator; the change is possible only by KeyLock using a suitable management software command. With the keypad locked it is not possible to enter any parameter modifications.
  • Page 35: Identification Sub-Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual IDENTIFICATION Sub-menu The IDENTIFICATION sub-menu uses three screens which display the information to identify the UPS unit. To exit the active screen, press the ESC key. IDENTIFICATION 1/3 Description: Device information - UPS unit...
  • Page 36: Events Sub-Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual View of the screen: EVENTS Sub-menu The EVENTS Sub-menu uses a single screen which displays information about the events that have occurred. The event register has a capacity to show up to 40 events.
  • Page 37: Service Sub-Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual i BypassOn / BypassOff i RecCommFailOn / RecCommFailOff i InvCommFailOn / InvCommFailOff i BypPSeqFailOn / BypPSeqFailOn Off i BypOutOfRangeOn / BypOutOfRangeOff i BatteryOpenOn / BatteryOpenOff i MainsOutOfRangeOn / MainsOutOfRangeOff i POBalacneOFROn / POBalacneOFROff...
  • Page 38 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Selecting the first field in the sub-menu (SCHEDULE PLANNER) offers the possibility of enabling or disabling the Schedule Planner without the need to delete individual tasks. Selecting the VIEW field allows listing and editing (if required) the previously entered items and tasks.
  • Page 39 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual – time of the start of the event; Time (Hour) – time of the start of the event; Minutes – switching on this parameter means that the task will be activated...
  • Page 40: The Relays Sub-Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual The RELAYS Sub-menu The unit is fitted with a total of four non-voltage outputs that can be programmed by the user. The actuators in this case are relays. The relay contacts have the following parameters: 1 A / 250 V AC).
  • Page 41: Input Sub-Menu

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual INPUT Sub-menu The EVER POWERLINE GREEN 33 LITE UPS unit is equipped with control inputs which make it possible to remotely assign specific (uniquely assigned) UPS unit functions. Individual functions assigned to subsequent contacts shown in Table Table 7.
  • Page 42: Modes Of Ups Operation

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual MODES OF UPS OPERATION Figure 6: Correlations between individual UPS modes of operation NORMAL Mode In order for the UPS power supply unit to be in the MAINS (NORMAL) mode, it must be first switched on by the logic system (from the user interface).
  • Page 43 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual HYBRID Mode (MIXED) In the HYBRID mode the UPS unit supplies power to the output using the inverter system (but only after power from the power lines with incorrect parameters has been suitably transformed – a wide voltage range – supplementing in this way the missing power from batteries).
  • Page 44 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual The UPS unit remains in this mode if the mains does not supply voltage meeting the correctness criteria for the electrical power network, and the UPS unit has been switched on by the logic system. After voltage with correct parameters becomes available, the UPS unit will switch automatically to the NORMAL mode (after the batteries have reached the minimum charge level).
  • Page 45: Protections And Safeguards

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual PROTECTIONS AND SAFEGUARDS Overload protection Overload (above 105%) is indicated by a continuous warning sound and a corresponding message on the display. If the overload reaches and stays at 105-130%, then the UPS unit will remain in the current mode for10 minutes before switching to BYPASS mode.
  • Page 46: Anti-Surge Protection

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Figure 7: Input protections. – input connections AC INPUT – individual input phase lines L1, L2, L3 – BYPASS phase lines BYPASS – main phase lines MAIN – optional equipment section...
  • Page 47 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Figure 8: Protection of the internal batteries. Always follow the instruction in the frame above the protection system as this instruction specifies the sequence that must be followed when switching on. Start by switching on the F1, then after waiting 10 secs switch on the F2.
  • Page 48: Thermal Protection

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Thermal protection The UPS unit has been equipped with thermal protection to protect the device against overheating. This thermal protection operates in two stages. If the internal temperature approaches the critical temperature level, acoustic warning signal starts to sound and a suitable warning message appears on the display.
  • Page 49: Ups Unit Installation

    (mains) mode. UNPACKING THE PRODUCT The UPS unit must be properly examined upon delivery or handover. Although ever care has been taken to ensure proper and safe packaging, the product may have suffered damage due to incorrect conditions in transit.
  • Page 50: Installing The Ups Unit

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual If the unit is supplied without batteries, all handling should also be done with the use of suitable hoisting equipment. In cases where the UPS unit is to be lifted by personnel, lifting should be done by at least 4 people.
  • Page 51 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Figure 10: Mounting brackets. Detailed information and instructions are included in a separate document with installation guidelines supplied with the product. www.ever.eu Technical Service, tel.: +48 61 6500 400 2016-10-27 12:12...
  • Page 52: Connecting The Ups To The Mains

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual CONNECTING THE UPS TO THE MAINS Connecting elements Figure 11: Connecting elements with protections. – input connections AC INPUT – individual input phase lines L1, L2, L3 – BYPASS phase lines BYPASS –...
  • Page 53 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual located below the connecting elements. Conduits, in which are wires should be clipped to the cover below. Always use the wire gauges as specified in the installation instructions. Conductor terminals should always be protected by suitable metal sleeves.
  • Page 54: Starting-Up The Ups Unit (Power Supply From The Main Line)

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Starting-up the UPS unit (power supply from the main line) After the UPS unit has been correctly connected, starting the unit is accomplished in the following sequence: 1. Check whether the F3 and F4 protections are in the OFF position. If they are not, move them to the OFF position.
  • Page 55: Switching Off And Disconnecting The Ups Unit

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual 4. Insert a suitable fuse into the F5 fuse holder clamp, and then close the holder clamp to close the circuit. 5. Place a suitable fuse into the fuse holder clamp on the battery pack...
  • Page 56: Battery Pack (Option)

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual 9. Close the F1, F2, F5 fuse holder clamps on the UPS unit and F1 and F2 clamps on the packs, if the fuses have been removed. Fuses should not be stored in the UPS unit if the unit has not been installed.
  • Page 57: Connecting The Battery Packs

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Connecting the battery packs CAUTION! Beware of a serious risk of electrocution! When carrying out any installation work always make sure that all the protections are in the disconnected state. 1. Switch OFF the UPS unit from the user interface (CONTROL 1/4; UPS Off).
  • Page 58: Disconnecting The Packs

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual The data indicated which relates directly to the number of connected batteries (associated with the entered information) will be updated automatically after the batteries have been successfully charged. Until that time the indications may differ from the actual state.
  • Page 59: Additional Functionalities Of The Ups Unit

    Control input and DC power supply ports The EVER POWERLINE GREEN 33 LITE power supply unit equipped with four control input ports and a DC power supply connection (non-stabilised 1 A / 12 V DC protected by a PTC resettable fuse) –...
  • Page 60: Programmable Outputs

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Figure 14: Control input and DC power supply ports. Programmable outputs The UPS unit is fitted with four sets (Fig. 15) of switchable volt-free contacts (relay contacts). Each set has the following terminals: NO (normally open), NC (normally closed) and COM (common).
  • Page 61: Reactive Power Compensation

    Figure 16: Protective cover for connector with volt-free contacts. REACTIVE POWER COMPENSATION One of the innovative solutions used in the EVER on-line UPS units is the incorporation of the Reactive Power Compensation functionality. Devices (loads) in electrical systems draw active (usable) power and, in many cases,...
  • Page 62: Hybrid Operation

    BATTERY operation c) hybrid operation Fig. 17. Flow of electricity (power balance) for individual modes of EVER UPS unit’s operation. Technical Service, tel.: +48 61 6500 400 www.ever.eu Type 01 2016-10-27 12:12...
  • Page 63 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual The EVER UPS power supply unit works with a wide range of input voltages and is also capable of operating in the hybrid mode (Fig. 17c). In order to meet the power...
  • Page 64: Parallel Systems

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual PARALLEL SYSTEMS The essential purpose of an uninterruptible power supply (UPS) is to provide emergency power to a load over a specific period of time when the input power source, typically mains power, shows irregularities or fails. It is also used to improve the mains power quality parameters.
  • Page 65 UPS supply units The number of redundant UPS unit may be higher than 1. This helps to increase the system reliability. EVER POWERLINE GREEN 33 LITE UPS power units allow combining up to 6 units within a single system.
  • Page 66: Installation Of The System

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual INSTALLATION OF THE SYSTEM CAUTION! Any installation work should be carried out only by suitably qualified service technicians, with professional licences required by law The electrical system on the premises must comply with the installation guidelines that are applicable to the UPS unit of the given output.
  • Page 67: Switching Off The System

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual 10. Close the F1 fuse holder clamps, and after waiting approximately 10 secs, also close the F2 fuse holder clamps. 11. Go to the user control panel and add individual SLAVE units to the system. To perform this operation, select (CONFIGURATION 7/7;...
  • Page 68 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Please note that as soon as a single UPS unit has been disconnected from the system, part of the supplied load that had been handled by the now disconnected UPS will be divided/distributed among the remaining UPS units.
  • Page 69 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual 2. Open F1, F2 and F5 fuse holder clamps (F5 applies only if an external battery pack is used). 3. For the duration of installation of the UPS unit make sure that any main line and BYPASS line protections in the switchgear in the room or the building have been disconnected.
  • Page 70: Communication With External Management/Control Systems

    The user has a choice of two communication protocols. They are EVER or MODBUS RTU protocols. For the communications using the EVER protocol, the RS232, RS485 and USB ports are used. Additionally, there is a facility to install an EVER SNMP/http management card.
  • Page 71: Ever Snmp/Http Network Management Card

    EVER SNMP/HTTP NETWORK MANAGEMENT CARD The EVER network management card is optional and can be installed by the user in service. This card is used to integrate the UPS unit with an Ethernet-type computer network. The network card is mounted in the special slot on the back wall of the UPS unit.
  • Page 72: Installing The Management Card

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Installing the management card 1. Switch OFF the UPS unit from the user interface (CONTROL 1/4; UPS Off). 2. Move the F3 and F4 protections into the OFF position. 3. Switch off the F1, F2, and F5 protections by opening the fuse holder clamps. The sequence in which the protections are switched off is not important.
  • Page 73: Communication Using The Modbus Protpcol

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual COMMUNICATION USING THE MODBUS PROTPCOL Alongside communication using the EVER protocol (using the RS232, RS485 or USB standard) or using an SNMP/HTTP network management card, the EVER POWERLINE GREEN 33 LITE range of UPS units are designed to allow communication using the MODBUS RTU protocol (using the RS232 or RS485 standards).
  • Page 74: Operating Instructions

    The algorithm to calculate expected battery operating time offers the highest precision when the recommended types of batteries are used (for the list of recommended battery types, please see www.ever.eu). In case when batteries other than recommended are used, indications may become imprecise which means the actual available time of backup operation may differ from the indicated time (Tau).
  • Page 75: Ups Operation With Power Generators

    The UPS power supply unit must be stored and transported in conditions which comply with the installation guidelines, as described in a separate document supplied with the product. In cases where this requirements has not been satisfied, EVER Sp. z o.o. shall not be liable for any mechanical damage sustained in transport.
  • Page 76 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual The area around the UPS unit should always be kept clean as part of preventive maintenance. If the dust levels in the environment around the UPS unit is high, always use a vacuum cleaner to clean the unit.
  • Page 77: Disposal

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual DISPOSAL The disposal / recycling of UPS units and/or batteries should be entrusted to a specialist waste contractor with suitable licence or authorization to engage in waste disposal / recycling. Appropriate disposal of waste electric and electronic equipment (WEEE) helps to...
  • Page 78: Technical Parameters

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual TECHNICAL PARAMETERS Table 9. Technical parameters POWERLINE GREEN 33 LITE PARAMETERS \ TYPE Model 10k Model 15k Model 20k Model 30k Model 40k Model 50k Model 60k W/PGRLTO W/PGRLTO W/PGRLTO W/PGRLTO...
  • Page 79 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual POWERLINE GREEN 33 LITE PARAMETERS \ TYPE Model 10k Model 15k Model 20k Model 30k Model 40k Model 50k Model 60k 10 kVA 15 kVA 20 kVA 30 kVA 40 kVA...
  • Page 80 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual POWERLINE GREEN 33 LITE PARAMETERS \ TYPE Model 10k Model 15k Model 20k Model 30k Model 40k Model 50k Model 60k 10 kVA 15 kVA 20 kVA 30 kVA 40 kVA...
  • Page 81: Legal Regulations And Warranty

    EVER Sp. z o.o. shall not be liable for any direct, indirect, extraordinary, coincidental, or consequential losses resulting from the use of the UPS unit, even if the user has not been notified of the possibility of such losses being incurred.
  • Page 82: Appendices

    EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual APPENDICES DESCRIPTION OF MODBUS REGISTERS 1. Command: 0x02 (read discrete inputs) Register Variable Description Signalling of the operating modes: 0 – Unknown operating mode 1 – NETWORK Mode ECO Mode BYPASS Mode...
  • Page 83 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual 55-63 Reserved Sound indication for unit’s operating states: 1 – active (factory/default setting) 0 – inactive Overriding switching to the BYPASS mode: 1 – overriding switching activated 0 – overriding switching inactive Switching on the operation as a UPS: 1 –...
  • Page 84 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Temperature1 Radiator temperature quoted with the resolution accuracy of one Celsius. Temperature2 Radiator temperature quoted with the resolution accuracy of one Celsius. Temperature3 Radiator temperature quoted with the resolution accuracy of one Celsius.
  • Page 85 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Apparent power drawn from the L3 line, mains supply via the bypass L3BypLineApparentPower system, quoted with the resolution accuracy of 100 VA. Input power factor for the L1 input line transmitted by the bypass line,...
  • Page 86 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Binary parameter, quoted in seconds and used to switch off the inverter operation with a given delay. This is to be configured to set the required DelayTimer delay value prior to setting the bit “Command to switch the UPS to the waiting mode”...
  • Page 87 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual KKMM Event9* NNDD GGSS KKMM Event10* NNDD GGSS KKMM Event11* NNDD GGSS KKMM Event12* NNDD GGSS KKMM Event13* NNDD GGSS KKMM Event14* NNDD GGSS KKMM Event15* NNDD GGSS KKMM Event16* NNDD...
  • Page 88 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual KKMM Event31* NNDD GGSS KKMM Event32* NNDD GGSS KKMM Event33* NNDD GGSS KKMM Event34* NNDD GGSS KKMM Event35* NNDD GGSS KKMM Event36* NNDD GGSS KKMM Event37* NNDD GGSS KKMM Event38* NNDD...
  • Page 89 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual GGMM AAKK Task19** GGMM AAKK Task20** GGMM AAKK Task21** GGMM AAKK Task22** GGMM AAKK Task23** GGMM AAKK Task24** GGMM AAKK Task25** GGMM AAKK Task26** GGMM AAKK Task27** GGMM AAKK Task28** GGMM...
  • Page 90 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Code Meaning MODE OF OPERATION 0x01 ---- 0x02 Mode of operation - Initialisation 0x03 Mode of operation – Stop 0x04 Mode of operation – Watch 0x05 Mode of operation – ECO 0x06 Mode of operation –...
  • Page 91 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual Code Meaning MESSAGES 0x30 Charging the batteries: Start 0x31 Charging the batteries: Stop 0x32 Overload: Start 0x33 Overload: Stop 0x34 Excessive rectifier temperature increase Start 0x35 Excessive rectifier temperature increase Stop...
  • Page 92 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual AA – task active flag, and code for the day of the week NAME MEANING 1: task active on this day 0x0100 SUNDAY 0: task inactive on this day 1: task active on this day...
  • Page 93 EVER POWERLINE GREEN 33 LITE UPS Range Operating Manual 4. Command 0x06 (write single register) Register Variable Description L1 phase output voltage for the UPS in the inverter-based mode, quoted with the L1PhaseOutputVoltage resolution accuracy of 1V L2 phase output voltage for the UPS in the inverter-based mode, quoted with the...
