Summary of Contents for Ever SINLINE XL 1800
-
Page 2: Table Of Contents
COMMUNICATION BETWEEN THE UPS AND THE COMPUTER.............. 23 COMMUNICATION VIA RS232 OR USB ....................23 INSTALLATION AND CONFIGURATION OF THE POWERSOFT PERSONAL SOFTWARE ....23 EVER SNMP/HTTP NETWORK management card ..................26 CONFIGURING THE UPS'S PARAMETERS ....................27 ADDITIONAL REMARKS..........................27 UPS AND POWER GENERATORS....................... -
Page 3: Introduction
RS232 serial port or USB and optionally via the Ever management card. (Telnet, SNMP, HTTP). SINLINE XL series EVER UPS was designed so as to meet all your expectations for protection against power loss. The UPS was manufactured in Poland and its structure conforms with requirements of the CE symbol. -
Page 4: General Features Of The Ups
• Archiving and storage of data pertaining to the UPS’S OPERATION; • Calculation of currently available time of battery operation mode; • PowerSoft software to monitor the operating parameters of the back-up and shut down the system automatically. www.ever.eu 2010/01/27... -
Page 5: Elements Of The Sinline Xl Ups - Tower Model
5) LEDs indicating the load level Available battery capacity – maximum battery capacity obtainable at the current UPS load >95% The left column of green LEDs indicates the charge level of >80% batteries. >45% >20% www.ever.eu 2010/01/27... -
Page 6: Rear Panel
8. Mains circuit breaker After the circuit breaker is triggered, the reason for shorting should be removed and the breaker pressed back in to be activated. 9. Mains power cord 10. Stopper for the external battery module socket. www.ever.eu 2010/01/27... -
Page 7: Elements Of The Sinline Xl Ups - Rack Model
The upper line of green LEDs indicates the charge level of batteries. 6) LEDs indicating the load level The lower line of green LEDs indicates the percentage load level of the UPS in both the mains and battery operation mode. If the last >5% >30% >60% >85% www.ever.eu 2010/01/27... -
Page 8: Rear Panel
4) RS232 serial port for communication with a PC 5) Stopper for the upgrade card opening – internal upgrade card slot 6) Outlet sockets 7) Stopper for the external battery module socket. 8) Fan 9) Mains power cord www.ever.eu 2010/01/27... -
Page 9: Health And Safety Instructions
• The device must be plugged in to a three-lead sockets (two poles and earthing) – connecting the device to any other socket may result in electric shock; • The device receiving the current must be connected with an appropriate circuit protection (manual cut-out or circuit breaker); www.ever.eu 2010/01/27... -
Page 10: Installation
Please inspect the UPS upon receipt. Although the product is packed very carefully it could have sustained damage from shock during transport. Should you find any damages, please inform the carrier or seller immediately. WARNING! The device is delivered with its battery connected. www.ever.eu 2010/01/27... -
Page 11: Installation Of The Ups - Tower Model
900 mm or 1000 mm depth it is possible to order longer handles to adjust the product for installation in such a rack. To install the UPS take the following steps: www.ever.eu 2010/01/27... -
Page 12: The Battery Module
Replacement of cut-outs should be conducted only by a qualified representative of the technical support. WARNING! The given model of UPS may only be enhanced with battery modules recommended manufacturer (see: "Technical parameters"). www.ever.eu 2010/01/27... -
Page 13: Connecting The Module
4. Connect the UPS to the mains and then turn it on with the power switch on the front panel. 5. Configure the number of battery modules in the PowerSoft programme (in the case of no modules set the parameter to 0). 6. After the batteries are charged the UPS is ready for operation. www.ever.eu 2010/01/27... -
Page 14: Ever Management Card
SINLINE XL series UPS – Instruction Manual EVER MANAGEMENT CARD The Ever management card is an optional component that may be installed by the user. Installing the card renders the communication via RS232 and USB impossible. Installing themanagement card – Tower and Rack Models 1. -
Page 15: Installing Themanagement Card
(maximum distance – 1,5 m) and should be easily accessible. Do not use additional extension cords to connect the device to the mains. WARNING! The UPS is disconnected from the mains only when the power cord is removed from its socket. www.ever.eu 2010/01/27... -
Page 16: Input Installation
Fig. 8: Layout of terminals of a mains socket Fig. 9 presents the ways of correctly connecting the UPS to different types of mains (TN-S or TN-C-S) that vary with regard to the manner of earthing. Fig. 9: Input installation of the UPS www.ever.eu 2010/01/27... -
Page 17: Output Installation
Fig. 10. Fig. 10: Output installation of the UPS The arrangement of terminals of output sockets of the UPS is presented on Fig. 11. Fig. 11: Arrangement of terminals of output sockets www.ever.eu 2010/01/27... -
Page 18: First Start
• connect the UPS to the computer (if using USB), With all of the above actions complete the UPS is ready for operation. WARNING! Back-up's batteries reach their full capacity after approximately a month of mains operating mode. www.ever.eu 2010/01/27... -
Page 19: Description Of The Back-Up's Operation
UPS. The DPC system offers various modes of communication between the UPS and the computer via a communication port or a special slot for the Ever management card (HTTP, telnet, SNMP). -
Page 20: Mains Operation Mode
When operating in the back-up mode, if the batteries are discharged or the appropriate command from the control software is given, the UPS may switch to the battery stand-by mode. www.ever.eu 2010/01/27... -
Page 21: Stand-By Mode
The UPS remains in emergency mode until switched off by the user or until the batteries are completely discharged. Table 1 Error table ERROR TABLE Signalling Type of error Tower Rack UPS connected incorrectly Internal errors (a combination of lit LEDs indicates various errors) Information for the tech support www.ever.eu 2010/01/27... -
Page 22: Safeguards
This is signalled by slow blinking of the last LED (red) in the load indication column and an intermittent sound signal mirroring the rate of blinking. In addition, the layout of lit LEDs in the battery charge level column indicates the type of error. (see the Error Table) www.ever.eu 2010/01/27... -
Page 23: Communication Between The Ups And The Computer
To install PowerSoft on a computer with Windows (the list of operating systems compatible with the application is available at www.ever.eu) just run the software installer and follow the instructions onscreen. During the installation you will be asked to select the model of the UPS connected to the computer on which the software is being installed. - Page 24 Users working with the PowerSoft must have root privileges to install the software and use it. After installation the application may be found in the /usr/local/PowerSoft directory. To uninstall the application enter the following command: rpm –ev PowerSoftpersonal-x.x.x www.ever.eu 2010/01/27...
- Page 25 PowerSoft can regularly check for new software versions and notify the user when updates are available. By default the software checks for updates after the user logs in. This setting can be changed under the "Update configuration" tab in the system's program menu. www.ever.eu 2010/01/27...
-
Page 26: Ever Snmp/Http Network Management Card
In the case of Debian and FreeBSD systems we recommend uninstalling the old version and then installing the new version of the software. Commands which enable these operations are described in the instruction manual available at www.ever.eu. EVER SNMP/HTTP NETWORK management card... -
Page 27: Configuring The Ups's Parameters
In practice this means that even though mean power of the protected equipment does not exceed the power range accepted by the UPS, the equipment will cause the UPS to shut down. This happens because the powered equipment temporarily draws power that significantly exceeds the nominal power www.ever.eu 2010/01/27... -
Page 28: Ups And Power Generators
In order to protect the ETHERNET UTP line and connected devices, the SINLINE XL UPSs are equipped with an anti-overvoltage filter which safeguards the devices connected against overvoltages. If the filter is to safeguard the devices correctly they www.ever.eu 2010/01/27... -
Page 29: Storage, Maintenance And Transport
The UPS should be transported in the original packaging and in conditions conforming to the product's specification (see "Technical parameters"). If the packaging is missing or a non-original or incomplete packaging is used, EVER Sp. z o.o. shall not be liable for any mechanical damages that occur in transport. -
Page 30: Technical Parameters - Tower Model
If the altitude above sea level increases beyond the provided limit, the permitted load power of the batter back-up decreases. The User may modify the switching thresholds. Factory setting is provided in parentheses. After discharging the UPS with power 80% Pmax, charging the battery to 90% capacity. www.ever.eu 2010/01/27... -
Page 31: Technical Parameters - Rack Model
If the altitude above sea level increases beyond the provided limit, the permitted load power of the batter back-up decreases. The User may modify the switching thresholds. Factory setting is provided in parentheses. After discharging the UPS with power 80% Pmax, charging the battery to 90% capacity. www.ever.eu 2010/01/27... -
Page 32: Information Regarding Regulations And Warranty
Apart from the arrangements included in the warranty card EVER Sp. z o.o. shall not grant any guarantee or warranty, including warranty of merchantability or fitness for particular purpose.
