  • Page 2: Table Of Contents

    ELEMENTS OF THE UPS - REAR PANEL ....................15 POWERLINE RT 1000 ..........................15 POWERLINE RT 2000 ..........................16 POWERLINE RT 3000 ..........................17 Battery module POWERLINE RT 1000 ......................18 Battery module POWERLINE RT 2000/3000 ....................19 HOW IT WORKS ............................20 MENU AND FUNCTIONS ..........................22 INSTALLATION ..............................

  • Page 3: Introduction

    This manual contains all relevant information to ensure correct and safe operation of the unit. Please read this manual carefully and thoroughly prior to using the EVER POWERLINE RT. This will help to operate the unit and correctly and safely. This EVER POWERLINE RT UPS system has been designed and engineered to provide the highest standard of protection against power failure.

  • Page 4: General Features Of The Ups Unit

    The POWERLINE RT UPS systems consist of the following functional blocks:  rectifier,  inverter,  battery set,  microprocessor-based control system with measurement circuits,  automated by-pass system (static BYPASS), Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...
  • Page 5 The UPS has a built-in battery charger that will be charging the battery if the network parameters are acceptable, except when the unit is in the back-up mode or in the battery test mode. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 6: Safety Instructions And Recommendations

    (battery packs). Dangerous voltage may be present at the output terminal(s), even if the unit has been disconnected from the mains. Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...
  • Page 7 CAUTION! There are no user-serviceable parts inside the UPS unit. CAUTION! The POWERLINE RT range of UPS units is not intended to work directly with medical equipment, life-supporting equipment or any other equipment that may have effect on health. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...
  • Page 8 The UPS unit must be completely dry before installation and operation. The acclimatization time should be at least 2 hours.  UPS units and battery packs must not be installed in humid environment. Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...
  • Page 9  To minimise the risk of fire, connections should only be made to circuits (electrical systems) whose rating is adequate for the connected loads, with properly selected overcurrent protection. Additionally, the breaker should feature at least a 3 mm insulating air gap. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...
  • Page 10 UPS unit.  All these instructions must be executed step by step. If any problems emerge when executing the instructions given in this document, please contact EVER service support (www.ever.eu).  Never disconnect the grounding at the UPS unit or at the terminals of the building's electrical system, as this will disable the UPS unit's protective grounding.
  • Page 11  Always make sure to check the date when recharging is due. Do not use the UPS unit if the deadline has passed and the batteries have not been recharged. In such cases always contact service support. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 12: Technical Description

    CAUTION! The appliance is heavy. Considerable care is required when it is being unpacked or moved. Exercise caution when moving or unpacking the device. Refrain from unpacking its individual elements until they are required for installation. Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...

  • Page 13: What's In The Box

    Instruction manual for POWERLINE RT 1-3 kVA UPS units What’s in the box? Check carefully the contents of the packaging. The packaging should contain: a) UPS POWERLINE RT 1000, 2000: - the UPS unit, - 2 sets of Tower supports for installing the unit vertically,...
  • Page 14 - 1 x cable RJ - RS232, - a CD with software, - a warranty card. e) Battery module POWERLINE RT 1000 & 2000/3000: - 1 battery module, - 1 power cord, - 1 battery module detection cable for automatic detection of the number of...

  • Page 15: Elements Of The Ups - Rear Panel

    10. Non-controlled output socket 10A 11. Controlled output sockets (group 1 and 2) 10A 12. Earthing clamp Fig. 2: View of the rear panel elements in POWERLINE RT 1000 UPS. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 16: Powerline Rt 2000

    9. Controlled output sockets (group 1 and 2) 10A 10. ROO/EPO terminals 11. USB port 12. Earthing clamp Fig. 3: View of the rear panel elements in POWERLINE RT 2000 UPS. Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...

  • Page 17: Powerline Rt 3000

    (group 1 and 2) 10A 11. Output socket 16A 12. ROO/EPO terminals 13. USB port 14. Earthing clamp Fig. 4: View of the rear panel elements in POWERLINE RT 3000 UPS. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 18: Battery Module Powerline Rt 1000

    2. RJ11 port – battery module detection 3. Battery module power supply socket 4. Fuse 70 A / 80 V DC Fig. 5: View of the rear panel elements in POWERLINE RT 1000 UPS battery module. Technical Support, tel.: +48 61 6500 400 www.ever.eu...

  • Page 19: Battery Module Powerline Rt 2000/3000

    3. Battery module power supply socket 4. Fuse 70 A / 80 V DC Fig. 6: View of the rear panel elements in POWERLINE RT 2000 / 3000 UPS battery module. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 20: How It Works

    4. LCD display 5. Exit - 6. Scroll - 7. Start / shut down key. Back-up mode LED (key with green backlight) 8. Confirmation key Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...
  • Page 21 Inverter short circuit (internal error) CHECK OUTPUT PHASE ERROR Inverted direction of phase cables detected. Check the layout of input connections CHECK AC INPUT OVERHEATING UPS elements' temperature too high REDUCE TEMP. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 22: Menu And Functions

    The time follows the format: DDDD:HH:MM:SS, where DDDD is the consecutive day of the device's work, HH – hours, MM – minutes, SS – seconds. The next screen is the next event. Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...
  • Page 23 Selection of battery charge level (75%, 50%, 25% or 0%) under which signal 4.13 ALARM SETTING "Battery low level" is generated. MENU 5. - INFORMATION Function Displays rated power of the UPS, software version and UPS working time. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 24: Installation

    UPS to the mains, e.g. by switching the electric system's overcurrent breakers. CAUTION! When connecting several battery modules in parallel, always observe the rule "same voltage, same type". Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...

  • Page 25: Mechanical Installation

    Fig. 8. Installation of the UPS vertically The UPS may be installed horizontally; the information can be found in the abridged manual, available in the product's packaging or at www.ever.eu. 2. Installation of UPS Plus with the external battery pack Assemble two sets of supports with the attached distance element and place the UPS between those supports as shown in Fig.

  • Page 26: Electrical System

    In extreme cases, different characteristics of the building’s and the UPS unit’s electrical protection systems may result in the former system being activated earlier. Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...

  • Page 27: Input Installation

    Fig. 11 shows correct methods of connecting the UPS to various types of mains (TN- S or TN-C-S) with different earthing systems (PE conductor connections). Fig. 11: UPS input installation www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 28: Output Installation

    CAUTION! Only TN-S configuration is allowed for the UPS output installation. Fig. 12: UPS output installation Fig. 13 shows POWERLINE RT UPS output socket pin configuration. Fig. 13: Output socket pin configuration Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...

  • Page 29: Power Connections

    7. "Daisy chain" the remaining battery packs with the supplied detection cables. 8. Switch circuits safeguards on all battery packs to ON. Once all external battery packs are connected, make all necessary connections between inputs and outputs as described below. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 30: Connecting The Ups To The Mains

    UPS unit's back-up mode LED will light up to indicate that the receiver is drawing power from the battery. The BACK-UP MODE message will be displayed on the LCD, along with estimated time of autonomous operation. Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...

  • Page 31: Ups Shut-Down Procedure

    UPS unit's settings. To switch the unit into the bypass mode go to menu 3 (CONTROL) and then to submenu SET BYPASS and select SWITCH TO BYPASS MODE or press the www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 32: Mains Mode

    If the UPS is operating as a frequency converter, the ECO mode and the bypass mode cannot be activated. CAUTION: The frequency conversion mode may be switched on / off only if the UPS is in stand-by mode. Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...

  • Page 33: Eco Mode

    LCD. When the UPS is in error mode there is a risk that receivers will lose power, because the output voltage will only be available from the bypass after an error occurs in the UPS. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 34: Additional Functions

    (ROO) or remotely switch the unit off without automatic restart option (EPO). g) Compatibility with power generators: the UPS can work with most of power generators available in the market. Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...

  • Page 35: Remote Emergency Power Off (Epo) / Remote On/Off (Roo)

    2 (by default, the UPS has the jumper installed) and then connect outputs 2 and 3 with a standard, zero voltage closed connector. The UPS switches off when the connector is opened. Closing the connector restarts the UPS and powers on the connected receivers. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 36: Communication With External Management/Control Systems

    The connector's configuration is shown in Fig. 15. Low battery charge level Mains parameters out of range Bypass mode SUM alarm Mains parameters corect Fig. 15: Configuration of the status communication connector Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...

  • Page 37: Usb Port

    IT systems. PowerSoft also enables (from the level of the central computer control unit) secure shutdown of other computers within a particular LAN network. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...
  • Page 38 The PowerSoft package is compatible with a wide range of operating systems, and this versatility should help to meet the operating requirements of a majority of small and medium enterprises (SMEs). Current software and installation procedures are available for downloading at www.ever.eu. Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...

  • Page 39: Operating Remarks

    The frequency of testing can be altered with the panel or the software. Select the TEST BATTERY EVERYDAY, EVERY WEEK, EVERY MONTH or DEACTIVATE in the submenu AUTOMATIC BATTERY TEST in the SETTINGS menu. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 40: Battery Replacement

    Dangerous voltage may be present between the battery terminals and the grounding point. The following precautions should be taken when working with batteries:  Remove jewelry, watches, rings and other metal items.  Only use tools with insulated handles. Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...
  • Page 41 In order to replace the internal batteries, manually switch the UPS into bypass mode (see "Bypass mode procedures") and follow the steps shown in Fig. 16 and Fig. 17: www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...
  • Page 42 Instruction manual for POWERLINE RT 1-3 kVA UPS units Fig.16: POWERLINE RT 1000 Fig.17: POWERLINE RT 2000/3000 Technical Support, tel.: +48 61 6500 400 www.ever.eu 2016-07-13 12:09...

  • Page 43: Battery Disposal

    This requirement applies both to the UPS unit itself and to all other accessories marked with this symbol. Such products should not be disposed of together with unsorted municipal waste. www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 44: Technical Parameters

    Instruction manual for POWERLINE RT 1-3 kVA UPS units TECHNICAL PARAMETERS Table 4. POWERLINE RT technical parameters. POWERLINE RT PARAMETERS \ TYPE POWERLINE RT 1000 POWERLINE RT 2000 POWERLINE RT 3000 Index T/PWRLRT-111K00/00 T/PWRLRT-112K00/00 T/PWRLRT-113K00/00 Output power (apparent / active)
  • Page 45 Instruction manual for POWERLINE RT 1-3 kVA UPS units POWERLINE RT PARAMETERS \ TYPE POWERLINE RT 1000 POWERLINE RT 2000 POWERLINE RT 3000 BATTERIES AND BACKUP TIMES Internal batteries 12 V / 9 Ah VRLA 12 V / 9 Ah VRLA...
  • Page 46 Instruction manual for POWERLINE RT 1-3 kVA UPS units Table 5. Technical parameters of battery packs for POWERLINE RT BATTERY MODULE BATTERY MODULE PARAMETER/MODEL POWERLINE RT 1000 POWERLINE RT 2000/3000 Rack / Tower Casing (The Rack Kit is optional) List of batteries...

  • Page 47: Trouble Shooting

    PC's interface; try selecting another serial No communication between the UPS another process or is damaged interface and the PC Reinstall / change the position of the cable Interferences in the data cable www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400 2016-07-13 12:09...

  • Page 48: Legal Regulations And Warranty

    EVER Sp. z o.o. shall not be liable for any direct, indirect, extraordinary, coincidental, or consequential losses resulting from the use of the UPS unit, even if the user has not been notified of the possibility of such losses being incurred.
