- Page 1 Instruction Manual Wireless Speaker Dock for iPhone and iPod with a lightning connector SSDKBT13 iPod and iPhone not included...
-
Page 2: Table Of Contents
Contents Contents ..........................2 Safety Warnings ........................3 Unpacking ..........................5 Product Overview .........................6 Front View ...............................6 Rear View .................................6 Top View ................................7 Remote Control ........................7 Remove the Plastic Strip from the Remote Control ............8 Battery Replacement for the Remote Control ..............8 Remote Control Operation Range ..................9 Connections ........................10 Using the AUX Connection ........................ -
Page 3: Safety Warnings
Safety Warnings Ventilation • Read all the instructions carefully before using the unit and keep them for future • To prevent the risk of electric shock or reference. fire hazard due to overheating, ensure • Retain the manual. If you pass the unit that curtains and other materials do not onto a third party make sure to include this obstruct the ventilation vents. - Page 4 • Please dispose of batteries correctly by following the guidance in this manual. • Do not expose the battery to direct sunlight or sources of excessive heat. Supervision • Children should be supervised to ensure that they do not play with the unit. •...
-
Page 5: Unpacking
Thank you Wireless Speaker Dock for purchasing your new Sandstrøm We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. You will also find some hints and tips to help you resolve any issues. Read all the safety instructions carefully before use and keep this instruction manual for future reference. -
Page 6: Product Overview
Product Overview Front View 1. Speakers 3. Status Indicator • Unlit when the unit is in STANDBY 2. Remote Control Sensor mode. Receives signal from the remote • Lights up red in iPod mode. control. • Lights up green in AUX mode. ®... -
Page 7: Top View
Top View MODE /MODE Button 1. iPod / iPhone Dock • Switches the unit between AUX, iPod, Button Bluetooth® and STANDBY modes. Decreases the volume. • Press and hold to pair with Bluetooth® device. Button Increases the volume. Remote Control Button Switches the unit between ON and STANDBY modes. -
Page 8: Remove The Plastic Strip From The Remote Control
Remove the Plastic Strip from the Remote Control Remove the plastic strip from the battery if the battery is being used for the first time. It is located at the bottom rear of the remote control. Battery Replacement for the Remote Control The remote control requires a CR2025, 3V Lithium battery. -
Page 9: Remote Control Operation Range
Handling the Remote Control • Take care of your fingernails when you slide and pull the battery release tab. • Do not drop the remote control. • Do not allow anything to impact the remote control. • Do not spill water or liquid on the remote control. •... -
Page 10: Connections
Connections Using the AUX Connection Use a 3.5mm to RCA stereo audio cable to connect the audio device’s audio output sockets to the unit’s AUX IN socket. Rear of the Unit Audio device AC INPUT ~ AUX IN 3.5mm to RCA stereo audio cable (not included) Use the 3.5mm to 3.5mm audio cable to connect the mobile device’s headphone socket to the unit’s AUX IN socket. -
Page 11: General Operation
General Operation Powering ON/OFF When you first connect the unit to the mains socket, the unit will be in STANDBY mode. • Press to switch the unit on. The status indicator will light up. • Press and hold for 2 seconds on the unit or press on the remote control to switch the unit back to standby mode. -
Page 12: Ipod / Iphone Operation
iPod / iPhone Operation iPod/iPhone Compatibility Your unit supports the following iPod/iPhone models: Type Support Model iPhone • iPhone 5 iPod • iPod touch 5 Generation • iPod nano 7 Generation Inserting the iPod/iPhone and Selecting iPod/iPhone Mode 1. While the unit is on, press MODE repeatedly on the unit or press iPod/ on the remote control to select iPod mode. -
Page 13: Bluetooth® Operation
4. “SSDKBT13” will appear on your Bluetooth device. 5. Select “SSDKBT13” and enter “0000” for password if necessary. 6. On successful pairing, the status indicator will flash slowly. • The operational range between the unit and the device is approximately 10 metres. -
Page 14: Maintenance
I cannot find • Ensure the unit is in pairing mode. ® ® “SSDKBT13” on • Ensure the Bluetooth function is activated on your Bluetooth ® my Bluetooth device. ®... -
Page 15: Specifications
Specifications Model SSDKBT13 Power Supply AC 100 -240V ~50/60Hz Power Consumption Standby Power Consumption < 0.5W Output Power 30W x 2 + 60W Net Weight 5.2kg Dimensions 330mm (W) x 140mm (D) x 190mm (H) Features and specifications are subject to change without prior notice. - Page 16 Other trademarks and trade names are those of their respective owners and all rights are acknowledged. All trademarks are the property of their respective owners and all rights are acknowledged. DSG Retail Ltd. (co. no. 504877) Maylands Avenue, Hemel Hempstead, , HP2 7TG, UK Herts. IB-SSDKBT13-130506V1...
