• Recommended separation distances between portable and mobile RF communication equipment
and the device.
The device is intended for use in an electromagnetic environment where radiated RF disturbances are
under control. User can help prevent electromagnetic interference by keeping the device at a minimum
distance from portable and mobile RF communications equipment (transmitters). Below table details the
maximum output power of transmitter:
Rated maximum Separation distance according to frequency of transmitter m
output power of
150 kHz to 80 MHz
transmitter W
d = 1.2
0.01 0.12
0.1 0.38
1 1.2
10 3.8
100 12
For transmitters rated at a maximum output power not listed above, the recommended separation
distance d in metres (m) can be estimated using the equation applicable to the frequency of the
transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
IB-WGNBPA-745_R3.indd 29-30
80 MHz to 800 MHz 800 MHz to 2.5 GHz
d = 1.2 d = 2.3
0.12 0.23
0.38 0.73
1.2 2.3
3.8 7.3
12 23
29
• Guidance and manufacturer's declaration – electromagnetic immunity
The device is intended for use in the electromagnetic environments listed below, and should only be
used in such environments:
Immunity IEC 60601 Compliance
test test level level
Conducted 3 Vrms 3 Vrms Portable and mobile RF communications equipment should
RF 150 kHz to be used no closer to any part of the device, including cables,
IEC 61000- 80 MHz 3 V/m than the recommended separation distance calculated from
4-6 the equation applicable to the frequency of the transmitter.
3 V/m Recommended separation distance
Radiated 80 MHz to
d = 1.2
RF 2.5 GHz
d = 1.2 80 MHz to 800 MHz
IEC 61000-
4-3 d = 2 .3 800 MHz to 2.5 GHz
where P is the maximum output power rating of the transmit-
ter in watts (W) according to the transmitter manufacturer
and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined
by an electromagnetic site survey, a should be less than the
compliance level in each frequency range.b
Interference may occur in the vicinity of equipment marked
with the following symbol:
NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and
land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an
electromagnetic site survey should be considered. If the measured field strength in the location in which
the device is used exceeds the applicable RF compliance level above, the device should be observed to
verify normal operation. If abnormal performance is observed, additional measures may be necessary,
such as reorienting or relocating the device.
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
Electromagnetic environment – guidance
30
