Product Manual 26425
(Revision NEW)
Original Instructions
723PLUS Digital Control
Nile River Vessel Generator Control
Dredging International
8301-1146
Application Manual

Advertisement

Table of Contents
loading

Related Manuals for Woodward 723PLUS

Summary of Contents for Woodward 723PLUS

  • Page 1 Product Manual 26425 (Revision NEW) Original Instructions 723PLUS Digital Control Nile River Vessel Generator Control Dredging International 8301-1146 Application Manual...
  • Page 2 Revisions—Changes in this publication since the last revision are indicated by a black line alongside the text. Woodward reserves the right to update any portion of this publication at any time. Information provided by Woodward is believed to be correct and reliable. However, no responsibility is assumed by Woodward unless otherwise expressly undertaken.

  • Page 3: Table Of Contents

    Manual 26425 723PLUS Nile River Generator Control Contents ................  ARNINGS AND OTICES   ..........LECTROSTATIC ISCHARGE WARENESS 1. G ............1  HAPTER ENERAL NFORMATION   Introduction ......................1   System Compliance ..................... 1   General Safety Precautions ................. 1  ...

  • Page 4: Warnings And Notices

    Start-up On- and off-highway Mobile Applications: Unless Woodward's control functions as the supervisory control, customer should install a system totally independent of the prime mover control system that...

  • Page 5: Electrostatic Discharge Awareness

    Do not touch the components or conductors on a printed circuit board with your hands or with conductive devices. To prevent damage to electronic components caused by improper handling, read and observe the precautions in Woodward manual 82715 , Guide for Handling and Protection of Electronic Controls, Printed Circuit Boards, and Modules.
  • Page 6 723PLUS Nile River Generator Control Manual 26425 Woodward...

  • Page 7: Chapter 1. General Information

    Make sure personnel using or working on this equipment are correctly trained. This manual covers only equipment which is manufactured by Woodward and does not include operating instructions for the prime mover, or the driven devices or processes.

  • Page 8: Chapter 2. System Description

    2000 rpm. The speed sensor fault detection is overridden during shutdown and stays overridden for *10 seconds after Run is selected. Because the 723PLUS does not act as speed control unit, a double failure of the speed probes does not result in a major alarm. Each sensor can individual be setup, in case of failure, as minor alarm or major alarm.

  • Page 9: Droop / Kw Control

    For that reason, the droop amount in the 723PLUS is set default to 0%. In case the kW droop must be activated, the droop % must be set to the correct amount. In kW droop, the control uses the load sensor input to calculate the droop.

  • Page 10: Chapter 3. Tunables

    723PLUS Nile River Generator Control Manual 26425 Chapter 3. Tunables Introduction This chapter describes the parameters that can be tuned or monitored. Where applicable, the nominal setting for each tunable is listed (the nominal values are provided only as a guideline). The actual settings are obtained from the engine manufacturer or determined during commissioning and should be noted in the Actual column for future reference.

  • Page 11: Service Mode Tunables

    Manual 26425 723PLUS Nile River Generator Control Service Mode Tunables ** ALARMLOG ** This menu shows the active alarms and will only be visible in case of an alarm. The first alarm will be logged and can be traced back!
  • Page 12 723PLUS Nile River Generator Control Manual 26425 ** kW LIMITER ** This menu must be used to setup the kW Limiter. This is a four slope curve, based on speed, that sets the maximum kW setpoint! Additional an extra kW can be given to above mentioned curve. This also is a four slope, speed dependant curve again! Always request the correct info for these parameters from the engine OEM.
  • Page 13 Manual 26425 723PLUS Nile River Generator Control ** PORTSETTING ** This menu must be used to switch the J1 port from Handheld (2) into ServLink (1) mode. Reboot of 723 will activate the handheld programmer mode again. Description Range Nominal...

  • Page 14: Chapter 4. Hand-Held Programmer

    This is information relating to the application. Pressing the 'ID' key changes the display to show the Woodward logo with the country name ("Woodward (NL)") and application name of the system. Press ‘ID’ again for the software part number.

  • Page 15: Adjusting Setpoints

    Manual 26425 723PLUS Nile River Generator Control Debug Menus To access the Debug first press  (solid square) after which the  key should be pressed. To move between category menus use the  and  keys, once in the right category move through the GAP blocks by using the  and  keys.

  • Page 16: Figure 4-1. Hand-Held Programmer

    723PLUS Nile River Generator Control Manual 26425 (rabbit up) Increases the displayed set point value quickly (about 10 times faster than the turtle keys). (rabbit down) Decreases the displayed set point value quickly (about 10 times faster than the turtle keys).

  • Page 17: Chapter 5. Control Wiring Diagram

    Manual 26425 723PLUS Nile River Generator Control Chapter 5. Control Wiring Diagram This chapter contains the Control Wiring Diagram 9971-1259. Sheet one of the drawing contains notes and additional information. The following sheets identify the system cables and show their interconnections, and give the pin-out detail of each cable connector.
  • Page 18 723PLUS Nile River Generator Control Manual 26425 Woodward...
  • Page 19 Manual 26425 723PLUS Nile River Generator Control Woodward...
  • Page 20 723PLUS Nile River Generator Control Manual 26425 Woodward...
  • Page 21 Manual 26425 723PLUS Nile River Generator Control Woodward...
  • Page 22 723PLUS Nile River Generator Control Manual 26425 Woodward...
  • Page 23 Manual 26425 723PLUS Nile River Generator Control Woodward...

  • Page 24: Chapter 6. Functional Block Diagram

    723PLUS Nile River Generator Control Manual 26425 Chapter 6. Functional Block Diagram This chapter contains Functional Block Diagram 9971-1260. Woodward...
  • Page 25 Manual 26425 723PLUS Nile River Generator Control Woodward...
  • Page 26 723PLUS Nile River Generator Control Manual 26425 Woodward...

  • Page 27: Chapter 7. Product Support And Service Options

    A current list of Woodward Business Partners is available at www.woodward.com/directory. Product Service Options Depending on the type of product, the following options for servicing Woodward products may be available through your local Full-Service Distributor or the OEM or Packager of the equipment system.

  • Page 28: Returning Equipment For Repair

    To prevent damage to electronic components caused by improper handling, read and observe the precautions in Woodward manual 82715, Guide for Handling and Protection of Electronic Controls, Printed Circuit Boards, and Modules.

  • Page 29: Engineering Services

    Field Service engineering on-site support is available, depending on the product and location, from one of our Full-Service Distributors. The field engineers are experienced both on Woodward products as well as on much of the non-Woodward equipment with which our products interface.

  • Page 30: Technical Assistance

    Technical Assistance If you need to contact technical assistance, you will need to provide the following information. Please write it down here before contacting the Engine OEM, the Packager, a Woodward Business Partner, or the Woodward factory: General Your Name...

  • Page 31: 723Plus Hardware Manual

    723PLUS Hardware Manual 723PLUS hardware manual 02877 is attached after the end of this manual.
  • Page 32 Email and Website—www.woodward.com Woodward has company-owned plants, subsidiaries, and branches, as well as authorized distributors and other authorized service and sales facilities throughout the world. Complete address / phone / fax / email information for all locations is available on our website.
