Manual Operations Instructions; Other Controls - Stryker Power-LOAD User Setup Manual

Locate this Manual Operation instruction label (6390-001-499) on the inside door panel or wall of the vehicle patient
compartment where visible to users.
MANUAL OPERATIONS
To load Power-LOAD:
1. Ensure that Power-LOAD is located at the head end of the vehicle patient compartment with the lifting arms down.
2. Push the cot into the vehicle patient compartment until the cot locks into Power-LOAD.
3. Ensure that the cot is locked into Power-LOAD by firmly pulling on the foot end of the cot.
4. For additional loading instructions, see "Loading a Cot into a Vehicle Manually (Power-LOAD Power Loss or
System Error)" on page
To unload Power-LOAD:
Press and hold the release lever at the foot end of the Power-LOAD system and pull to remove the cot from the vehicle
patient compartment. For additional unloading instructions, "Unloading a Cot from a Vehicle Manually" on
Note: Without power, the lifting arms may not raise the cot. Operators must be ready to accept the entire weight of
the cot.
See "User Controls and LED Indicators" on
Note: If Power-LOAD will not be in use for a week or more, press the main power button to turn the unit off and avoid
draining the battery.
WARNING
Improper usage of the Power-LOAD system or any accessory can cause injury to the patient or operator. Operate
the Power-LOAD system and accessories only as described in the manuals.
For manual operations, the operator must support the foot end of the cot.
www.stryker.com

Manual Operations Instructions

L oad
Unload
61.
page 41 for button and LED locations and descriptions.
6390-009-001 REV B
Improper usage of the Power-LOAD system or
WA R NING :
any accessory can cause injury to the patient or
operator. Operate the Power-LOAD system and
accessories only as described in the manuals.
For Manual Operations, the operator must
support the foot end of the cot.
Other C ontrols
Return To Table of Contents
2 o f 2
page 62.
47
