Power-PRO TL is an electric, hydraulic ambulance stretcher, designed to help reduce
the risk of manual handling injury with powered lifting and features that make it easy to
manoeuvre and fit into small spaces.
2
7
1
Main Controls Main Controls Main Controls Main Controls
1. Foot end button to raise/lower or extend/retract frame
2. Corner poles for pushing and steering – button release
3. Red trigger buttons to telescope head and foot in/out (both ends)
4. Trigger handle to raise/lower back rest
5. Squeeze to release side rail
6. Loops to raise knee gatch
7. Release lever for knee gatch and shock position
8. Caster steer lock switch
9. Battery
10. Brakes (two or all four wheels)
*This Quick Start Guide is not intended to replace the manufacturer's Operations Manual or product training.
Always read the manual before use for full instructions and safety warnings. © Stryker 17 Jul 08
