These Power-LOAD LED indicators are located at the head
end of the Power-LOAD trolley.
The oil reservoir location is shown for your reference.
Ref Icon/Button Name
7
Battery
Power
8
Error
9
Oil
Reservoir
10
Not
USB Port Remove plate to access the USB port for input/output
Applicable
Return To Table of Contents
42
User Controls and LED Indicators
Description
If LED is solid green, the Power-LOAD system is on
and not charging.
If LED is flashing green, the battery is charging.
Note: The battery will only charge when the trolley
is locked at the head end of the vehicle patient
compartment.
If LED is solid amber, there is a Power-LOAD error.
Press the main power button twice to reset the unit.
If the LED remains solid amber, contact technical
support.
If LED is flashing amber, the Power-LOAD battery
power is low.
®
Add Mobil Mercon
001-293) here until full. To avoid the risk of a unit
malfunction or leak, do not overfill the reservoir with oil.
diagnostics. Service only by qualified personnel.
6390-009-001 REV B
7
8
10

Trolley Head End Label

V Synthetic Blend Oil (6500-
9
Type
Location
LED
Trolley
Head End
LED
Trolley
Head End
Not
Trolley
Applicable
Head End
Not
Trolley
Applicable
Head End
