- Page 1 ROCKETLINX ACS7106 Industrial PoE Plus Switch QUICK INSTALLATION GUIDE 2000572 Rev A | Release Date - April, 2013...
- Page 2 INTRODUCTION The RocketLinx ACS7106 is an industrial UL294 listed Power over Ethernet Plus (PoE+) switch with voltage boost technology. The ACS7106 provides power and Ethernet communications to PoE devices. The ACS7106 features four Fast Ethernet PoE Plus ports and two Gigabit uplink ports to ensure a high-bandwidth connection.
-
Page 3: Specifications
For example: PoE (IEEE 802.3af/802.3at compliant card readers, remote access panels, or cameras For UL294 installations, the power supply must be regulated and UL294 compliant 802.3af Cat 5 or higher cable 802.3at Cat 5e or higher cable See Comtrol’s website for detailed product specifications. - 2 -... -
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS Electrical Specifications Value • Four 10/100BASE-TX PoE Number of Ports • Two 10/100/1000BASE-TX Power Input 12-24VC Power Consumption • 700mA @ 12VDC (Without PD Loading) • 350mA @24VDC • 6.8A @ 12VDC Power Consumption • 4.8A @ 24VDC (With PD Loading) •... - Page 5 0 - 95% The product is UL listed for an operating temperature range of -40º to 55ºC. Comtrol has qualified and tested the product to operate at temperatures up to 60ºC. At 60ºC, the product can provide a maximum PoE output of 90W with an input voltage of 24VDC and 60W with an input voltage of 12VDC.
-
Page 6: Setting The Dip Switches
MOUNTING THE ACS7106 Make sure that you use appropriate screws when securing the ACS7106. In UL294 installations, #8 self-tapping screws can be used to mount the ACS7106. Use one or two screws on each side to mount the ACS7106. Example of ACS7106 Mounted to Panel/Wall mounting brackets GROUNDING THE ACS7106 The ACS7106 must be tied to earth ground to ensure... - Page 7 WIRING THE POWER INPUTS The power supply input range is 12-24VDC with a maximum power consumption of 8W without PoE PD loading. Wiring methods shall be compliant with National Wiring Positive Power Supplies Electrical Code/NFPA 70/ANSI. NOTE: Power should be disconnected from the power supply before connecting it to the switch.
-
Page 8: Connecting Ethernet Ports
CONNECTING ETHERNET PORTS Connect one end of an Ethernet cable into the Ethernet port of the ACS7106 and the other end to the attached networking device: • Ports 1-4 are Fast Ethernet (10/100BASE-TX) PoE that support IEEE 802.3af/802.3at (PoE+) • Ports 5-6 are Gigabit (10/100/100BASE-TX) Half and full-duplex connections are supported with auto-negotiated link speed and duplex mode. - Page 9 LEDs This table provides information about the LEDs on the ACS7106. LED Name LED On LED Blinking LED Off PWR - System Not applicable System not Green power ready ready Valid PoE Active PoE (P1 - P4) - output and applicable Green PoE PD is...
- Page 10 LEDs Power/Relay 10/100 PoE+ Ports Relay DIP switches Gigabit Uplink Ports...
- Page 11 ABOUT COMTROL For more than 30 years, Comtrol Corporation has been a manufacturer and provider of quality networking and industrial data communication products, specializing in industrial Ethernet and device connectivity. With representation across North America, EMEA, Asia and Latin America, Comtrol sells RocketLinx™ industrial grade Ethernet and Power over Ethernet switches, DeviceMaster®...
