Enabling the Event Alarm ..............................7 Mounting the RocketLinx ES8105/ES8105F ........................8 Connecting the Ethernet Ports............................8 Connecting the Fiber Port (RocketLinx ES8105F) ......................9 Testing the ES8105/ES8105F..............................11 Troubleshooting and Technical Support..........................13 Troubleshooting..................................13 Comtrol Support ................................13 Index ......................................15 RocketLinx ES8105/ES8105F User Guide: 2000558 Rev. B - 3...
Page 4
4 - RocketLinx ES8105/ES8105F User Guide: 2000558 Rev. B Table of Contents...
IP31 grade case design to meet the requirements of drop-water proof and is dust proof. The RocketLinx ES8105/ES8105F also provides one relay output for port error events, which is enabled/ disabled by the DIP switch. The RocketLinx ES8105/ES8105F has good immunity against unstable power source and can accept 18 to 27VAC or 18 to 32VDC power input.
Page 6
LED Off Port 1- 4 A network device is detected and (RocketLinx Yellow:100Mbps link established at 10Mbps. ES8105F) Fiber port #5 (RocketLinx 100Mbps Link 100Mbps Activity 100Mbps Link ES8105F) 6 - RocketLinx ES8105/ES8105F User Guide: 2000558 Rev. B LED Indicators...
Enabling the Event Alarm You can use this subsection to configure and enable the event alarm to alert maintenance engineers once a system event has occurred. The RocketLinx ES8105/ES8105F is equipped with one dry relay output for port link failure. Hardware Installation...
Disables the port link down alarm on the corresponding port. Mounting the RocketLinx ES8105/ES8105F You can mount the RocketLinx ES8105/ES8105F on a DIN rail or mounted to the wall. The DIN rail clip is already attached to the RocketLinx ES8105/ES8105F when packaged.
This is a Class 1 Laser/LED product. Do not stare into the Laser/LED beam. Caution A wrong connection will cause the fiber port not to work properly. Connecting the Fiber Port (RocketLinx ES8105F) RocketLinx ES8105/ES8105F User Guide: 2000558 Rev. B - 9...
Page 10
1000BASE-LX 1000 1310nm, 50/125um or 62.5/125um Multi-mode optical fiber cable 550m 1310nm, 9/125um Single-Mode optical fiber cable 1000BASE-LH 1000 1550nm,9/125um 70km Single-Mode optical fiber cable 10 - RocketLinx ES8105/ES8105F User Guide: 2000558 Rev. B Connecting the Fiber Port (RocketLinx ES8105F)
Note: Make sure that any connected network switches support MDI/MDIX functionality. If they do not, use an Ethernet crossover cable. Verify that the port status LED indicator is blinking green on the RocketLinx ES8105/ES8105F to see if the network connection was established successfully.
Page 12
192.168.11.102 –t command to see if it will respond. The PC host IP address must be in the same subnet address as the target device: 192.168.11.102. The parameter -t allows you to continually ping the network device, as shown in the figure below. 12 - RocketLinx ES8105/ES8105F User Guide: 2000558 Rev. B Testing the ES8105/ES8105F...
If the Power LED goes off when the power cord is plugged in, a power failure might have occurred. Check the power output connection to see if there is any error at the power source. If you still cannot solve the problem, contact Comtrol Technical Support for assistance.
Page 14
Troubleshooting and Technical Support 14 - RocketLinx ES8105/ES8105F User Guide: 2000558 Rev. B Comtrol Support...
10BASE-T cables Fast Ethernet Downloads Ethernet Fast Ethernet port cables hardware installation installation hardware Phone support technical support Web Site RocketLinx ES8105/ES8105F User Guide: 2000558 Rev. B - 15 Index...
Page 16
Index 16 - RocketLinx ES8105/ES8105F User Guide: 2000558 Rev. B Index...
