Electrical Installation

4.5 Location of Terminals

4 4
5
13
1 Digital and analog inputs/outputs
2 Safe Torque Off (STO), LCP connection, B-option
3 Relay 1
4 Relay 2
5 Motor, mechanical brake, brake resistor
6 Mains
7 24 V DC back-up input
Illustration 4.7 Location of Terminals (Small Unit)
18
®
VLT Decentral Drive FCD 302
4 2
7 8
8 USB port
9 Standard bus/RS485
10 PROFIBUS
11 Ethernet port
12 Ethernet port
13 Protective earth (PE)
– –
Danfoss A/S © 11/2016 All rights reserved.
1 3
11
12
13 9
10
6
13
MG04F502
