- Page 1 User Manual PCL-730 32-ch Isolated Digital I/O ISA Cards...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
-
Page 3: Declaration Of Conformity
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information. -
Page 4: Safety Instructions
If one of the following situations arises, get the equipment checked by service personnel: The power cord or plug is damaged. Liquid has penetrated into the equipment. The equipment has been exposed to moisture. PCL-730 User Manual... - Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). Safety Precaution - Static Electricity DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.Safety Precaution - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage.
- Page 6 PCL-730 User Manual...
-
Page 7: Table Of Contents
Isolated Input ................14 3.3.2 Isolated Output................15 Appendix A Register Format .........17 Register Format ..................18 Table A.1: Register Assignment ..........18 Appendix B PC I/O Port Address Map ....19 PC I/O port address map ................ 20 PCL-730 User Manual... - Page 8 PCL-730 User Manual viii...
-
Page 9: Chapter 1 Overview
Chapter Overview... -
Page 10: Introduction
Introduction The PCL-730 offers 32 isolated digital I/O channels (16 DI and 16 DO) and 32 TTL digital I/O channels (16 DI and 16 DO) on a PC add-on card. Providing 2500 V iso- lation, each I/O channel corresponds to a bit in a PC I/O port, making the PCL-730 very easy to program. -
Page 11: Specifications
Connectors DB-37 connector for isolated DIO Two 20-pin flat-cable connectors for isolated DIO Two 20-pin flat-cable connectors for TTL DIO Power consumption +5 V: 330 mA typical, 500 mA maximum +12V: 80 mA typical, 105 mA maximum PCL-730 User Manual... -
Page 12: Daughterboards
PCLD-785B and PCLD-885 relay output boards These boards let you control relays through the PCL-730's 16-bit TTL digital output channels. PCLD-785B provides 24 SPDT relays, while the PCLD-885 provides 16 SPST power relays. -
Page 13: Chapter 2 Hardware Installation
Chapter Hardware Installation... -
Page 14: Installation
It should be free of marks and in perfect order on receipt. As you unpack the PCL-730, check it for signs of shipping damage (damaged box, scratches, dents, etc.). If it is damaged or fails to meet specifications, notify our ser- vice department or your local sales representative immediately. -
Page 15: Switch And Jumper Settings
Switch and Jumper Settings The PCL-730 card has one function switch and four jumper settings. The following sections tell how to configure the card. You may want to refer to the opposite page for help identifying card components. Table 2.1: Connectors, Jumpers, and Switches... -
Page 16: Base Address Selection (Sw1)
Hex 200 to Hex 3F0. Other devices in your system may, however, be using some of these addresses. We set the PCL-730 for a base address of Hex 300 at the factory. If you need to adjust it to some other address range, set switch SW1 as shown in the following... -
Page 17: Interrupt Triggering (Jp2)
Version control (JP4/JP5) Jumper JP4 controls the pin assignments for CN1 and CN6 while JP5 controls it for CN2 and CN6. Setting this jumper to A1 makes the card's pin assignments the same as the A1 version. PCL-730 User Manual... -
Page 18: Hardware Installation
Save the screw to secure the interface card retaining bracket. Carefully grasp the upper edge of the PCL-730 card. Align the hole in the retain- ing bracket with the hole on top of the expansion slot and align the gold striped edge connector with the expansion slot socket. -
Page 19: Chapter 3 Signal Connections
Chapter Signal Connections... -
Page 20: Overview
PCL-730 via the I/O connector. Connector Pin Assignments The PCL-730 has four on-board 20-pin flat-cable connectors (insulation displace- ment, mass termination) and a DB-37 connector accessible from the card bracket. See the figure on page 7 for the location of each connector. - Page 21 PCL-730 User Manual...
-
Page 22: Ttl-Level I/O
TTL-level I/O The PCL-730 has 16 TTL-level digital inputs and 16 TTL-level digital outputs. The fol- lowing figure shows connections to exchange digital signals with other TTL devices: If you want to receive an OPEN/SHORT signal from a switch or relay, add a pull-up resistor to ensure that the input is held at a high level when the contacts are open. -
Page 23: Isolated Output
PCOM1. Channels 8~15 use PCOM2.) If the external voltage (5~40V) is connected to each isolated output channel (IDO) and its isolated digital output turns on (200mA per channel maximum), the card's cur- rent will sink from the external voltage. PCL-730 User Manual... - Page 24 PCL-730 User Manual...
-
Page 25: Appendix A Register Format
Appendix Register Format... -
Page 26: Register Format
Register Format Programming the PCL-730 is extremely simple. Each I/O channel corresponds to a bit in the card's registers. To turn on an output channel you write a ‘‘1” to the corre- sponding bit. To read an input port, you simply read from the register. -
Page 27: Appendix Bpc I/O Port Address Map
Appendix PC I/O Port Address... -
Page 28: Pc I/O Port Address Map
PC I/O Port Address Map Range (hex) Function 000-1FF Base System Reserved Came Control 202-277 Reserved 278-27F Second Printer Port 280-2F7 Reserved 2F8-2FF COM 2 300-377 Reserved 3713-37F First Printer Port 380-3AF Reserved 3B0-3BF Mono Display/Print Adapter 3C0-3CF Reserved 3D0-3DF Color/Graphics 3E0-3EF Reserved... - Page 29 PCI-1730/1733/1734 User Manual...
- Page 30 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2011...
