Summary of Contents for Advantech PCM-9575F

  • Page 1 Advantech PCM-9575F Low Power VIA Eden SBC 1395 In Stock Qty Available: 1 Used and in Excellent Condition Open Web Page https://www.artisantg.com/98440-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 PCM-9575 EBX VIA Eden/Ezra SBC with CPU,LCD, Ethernet, Audio, PCI and PC/104-Plus Users Manual...
  • Page 3 SMI is a trademark of Silicon Motion, Inc. Creative is a trademark of Creative Technology LTD. All other product names or trademarks are properties of their respective owners. For more information on this and other Advantech products, please visit our websites at: http://www.advantech.com http://www.advantech.com/epc For technical support and service, please visit our support website at: http://support.advantech.com...
  • Page 4 PCM-9575F-M0A1 W/ Eden-667 CPU and heat sink Additional Information and Assistance 1. Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. 2. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
  • Page 5 PCM-9575 User’s Manual...
  • Page 6 Table of Contents Contents Chapter 1 General Information ........1 Introduction ............... 2 Features ................3 Specifications ..............4 1.3.1 Standard EBX SBC Functions ..........4 1.3.2 VGA/LCD Interface ..............4 1.3.3 LVDS: Supports 2 Channel (2 x 18 bit) LVDS interface..5 1.3.4 Audio function................
  • Page 7 2.14.2Main power connector, +5 V, +12 V (CN5) ......17 2.14.3CPU Fan power supply connector (FAN1) ......17 2.15 ATX power control connector (CN3, CN23)....17 2.15.1ATX feature (CN3), soft power switch conn (CN23) ..... 17 Figure 2.3: Wiring for ATX soft power switch function ..18 2.16 IR connector (CN24)............
  • Page 8 Table of Contents Chapter 4 Award BIOS Setup.........33 System test and initialization........... 34 4.1.1 System configuration verification ........... 34 Award BIOS setup ............35 4.2.1 Entering setup................. 35 Figure 4.1: BIOS setup program initial screen....35 4.2.2 Standard CMOS Features setup ..........36 Figure 4.2: CMOS Features setup........
  • Page 9 Chapter 6 Audio Setup.............75 Introduction ..............76 DOS utilities..............76 6.2.1 VIA Sound Blaster Pro compatible set up program ....76 6.2.2 VIA Sound Blaster Installation ..........77 Driver installation............77 6.3.1 Before you begin ..............77 6.3.2 Windows 95/98 drivers ............78 6.3.3 Windows NT drivers ...............
  • Page 10 Table of Contents C.17 TV (video) Out Connector (CN1) ......... 132 C.18 Flat Panel Connector (CN11) ........133 C.19 Extended Flat Panel Display Connector (CN10) ..134 C.20 LCD Signal Mapping ............ 135 C.21 LVDS Connector (CN9)..........136 C.22 Peripheral Power Connector (CN27) ......136 C.23 COM Port Connector (CN19) ........
  • Page 12 General Information This chapter gives background information on the PCM-9575. Sections include: • Introduction • Features • Specifications • Board layout and dimensions Chapter 1 General Information...
  • Page 13 Chapter 1 Introduction 1.1 Introduction The PCM-9575 is a VIA low-power Eden/Ezra processor single board computer (SBC) with audio controller, a 4X AGP SVGA controller, a PCI 10/100Base-T Ethernet interface, one PCI slot, and one PC/104-Plus expansion connector. The PCM-9575’s design is based on the EBX form factor that provides support for PC/104 and PC/104-Plus module expan- sion.
  • Page 14 • 2 IDE channels for HDD and CD-ROM 1.3 Specifications 1.3.1 Standard EBX SBC Functions • CPU: Onboard VIA Ezra 800MHz (PCM-9575F-Q0A1) or VIA Eden 400 MHz (PCM-9575F-J0A1) or VIA Eden 667Mhz processor (PCM-9575F-M0A1) • BIOS: Award 256 KB Flash memory •...
  • Page 15 • Enhanced IDE interface: Two channels supports up to four EIDE devices. BIOS auto-detect, PIO Mode 3 or Mode 4, UDMA 33 transfer. Primary IDE support up to UDMA 66/100 mode • FDD interface: Supports up to two FDDs • Serial ports: Four serial RS-232 ports, COM1, 3, 4: RS-232, COM2: RS-232/422/485 •...
  • Page 16 Provides Composite video and S-video outputs via RCA (composite) connector and S-video connector Supports 640 x 480 and 800 x 600 input resolutions Supports Windows© 95/98/NT and Windows XP drivers Over-scan, under-scan and position adjustable Auto-detection of TV presence met Interface 1.3.6 PCI bus Ethernet interface •...
  • Page 17 1.4 Board layout: dimensions Figure 1.1: Board layout: dimensions PCM-9575 User’s Manual...
  • Page 18 Installation This chapter explains the setup procedures of PCM-9575 hardware, including instruc- tions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the installation procedure. Chapter 2 Installation...
  • Page 19 Chapter 2 Installation 2.1 Jumpers The PCM-9575 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 2.1: Jumpers Label Function PCI VIO select LAN controller power select (Rev A101only) DOC2000 address select CMOS clear...
  • Page 20 Table 2.2: Connectors CRT display connector LVDS connector CN10 Ext. flat panel connector CN11 Flat panel connector CN12 Ethernet connector CN13 Power & HDD LED connector CN14 IDE hard drive connector (secondary) CN15 Parallel port connector CN16 IDE hard drive connector (primary) CN17 PC/104 plus (ISA + PCI) expansion CN18...
  • Page 21 2.3 Locating jumpers Figure 2.1: Jumper locations PCM-9575 User’s Manual...
  • Page 22 2.4 Locating Connectors Figure 2.2: Connectors (component side) Chapter 2 Installation...
  • Page 23 2.5 Setting Jumpers You may configure your card to match the needs of your application by setting jumpers. A jumper is a metal bridge used to close an electric cir- cuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.
  • Page 24 2.6 Clear CMOS (JP4) Warning! To avoid damaging the computer, always turn off the power supply before setting “Clear CMOS.” Before turning on the power supply, set the jumper back to “3.0 V Battery On.” This jumper is used to erase CMOS data and reset system BIOS informa- tion.
  • Page 25 2.7 Installing DIMMs The procedure for installing DIMMs is described below. Please follow these steps carefully. The number of pins are different on either side of the breaks, so the module can only fit in one way. DIMM modules have different pin contacts on each side, and therefore have a higher pin den- sity.
  • Page 26 (See your hard drive’s documentation for the location of the con- nector.) If desired, connect a second drive as described above. Unlike floppy drives, IDE hard drives can connect to either end of the cable. If you install two drives, you will need to set one as the master and one as the slave by using jumpers on the drives.
  • Page 27 If you are connecting a 3.5” floppy drive, you may have trouble determin- ing which pin is number one. Look for a number printed on the circuit board indicating pin number one. In addition, the connector on the floppy drive may have a slot. When the slot is up, pin number one should be on the right.
  • Page 28 them. The front panel connector (CN13) is an 8-pin male, dual in-line header. It provides connections for a speaker, hard disk access indicator, watchdog output, and an input switch for resetting the card. 2.13.1 Power & HDD LED (CN13) The HDD LED indicator for hard disk access is an active low signal (24 mA sink rate).
  • Page 29 Important Make sure that the ATX power supply can take at least a 10 mA load on the 5 V standby lead (5VSB). If not, you may have difficulty power- ing on your system. to CN3 ATX features connector power supply to main power connector CN5 20-pin...
  • Page 30 2.17.1 Audio connector (CN4) The PCM-9575 provides all major audio signals on a 16-pin flat-cable connector, CN4. These audio signals include Microphone in (mono), Line in (stereo), Line out (stereo), and Speaker out (stereo). If you use tradi- tional telephone jack connectors for these audio signals, you will need an adapter cable.
  • Page 31 2.19 VGA/LCD/LVDS interface connections The PCM-9575’s PCI SVGA interface can drive conventional CRT dis- plays and is capable of driving a wide range of flat panel displays, includ- ing passive LCD and active LCD displays. The board has three connectors to support these displays: one for standard CRT VGA moni- tors, one for flat panel displays, and one for LVDS type LCD panels.
  • Page 32 S1 is an 8 segment DIP switch for DSTN/TFT panel type and resolution functions. Table 2.4: S1 Panel Type select Panel Type & Resolution 640x480** 18bit (H. V. Freq) 648x480 18bit (Synthetic) OFF ON 648x480** OFF OFF 648x480** LVDS OFF ON DSTN 648x480** 18bit...
  • Page 33 2.21 Ethernet configuration The PCM-9575 is equipped with a high performance 32-bit PCI-bus Ethernet interface which is fully compliant with IEEE 802.3U 10/ 100Mbps CSMA/CD standards. It is supported by all major network operating systems. The medium type can be configured via the RSET8139.EXE program included on the utility disk.
  • Page 34 involves one jumper and running the control software (refer to Appendix 2.22.1 Watchdog timer action (JP5) When the watchdog timer activates (CPU processing has come to a halt), it can reset the system or generate an interrupt on IRQ11. This can be set via setting JP5 as shown below: Table 2.6: Watchdog timer action (JP5) *System reset...
  • Page 35 PCM-9575 User’s Manual...
  • Page 36 Software Configuration This chapter details the software configura- tion information. It shows you how to config- ure the card to match your application requirements. The AWARD System BIOS is covered in Chapter 4. Sections include: • Introduction • Connections for standard LCDs •...
  • Page 37 Chapter 3 Software Configuration 3.1 Introduction The PCM-9575 system BIOS and custom drivers are located in a 256 Kbyte, Flash ROM device, designated U18. A single Flash chip holds the system BIOS, VGA BIOS and network Boot ROM image. The display can be configured via CMOS settings.
  • Page 38 3.2 Connections to Three Standard LCDs The following tables illustrate typical LCD connection pinouts for the PCM-9575. 3.2.1 Connections to Toshiba LTM10C209A (640 x 480 TFT color LCD) Table 3.1: Connections to Toshiba LTM10C209A LTM10C209A PCM-9575 CN11 Name Name SHFCLK ENAB M/DE Chapter 3 Software Configuration...
  • Page 39 Table 3.1: Connections to Toshiba LTM10C209A +5 V +5 V 3.2.2 Connections to Toshiba LTM15C151A (1024 x 768 TFT color LCD) LTM15C151A Table 3.2: Connections to Toshiba LTM15C151A PCM-9575 CN11 Name Name CN1-1 CN 11-33 CN1-2 NCLK CN 11-35 LDSCLK1 CN1-3 CN1-4 CN1-5...
  • Page 40 LTM15C151A Table 3.2: Connections to Toshiba CN1-25 CN 10-13 PD34 CN1-26 ENAB CN 11-37 M/DE CN1-27 CN 11-34 CN1-28 CN 11-1 CN1-29 CN 11-2 CN1-30 CN 11-8 3.2.3 Connections to Toshiba LTM12C275A (800 x 600 TFT color LCD) Table 3.3: Connections to Toshiba LTM12C275A LTM12C275A PCM-9575 CN11 Name...
  • Page 41 Table 3.3: Connections to Toshiba LTM12C275A ENAB M/DE +5 V +5 V 3.3 Ethernet software configuration The PCM-9575’s on-board Ethernet interface supports all major network operating systems. To configure the medium type, to view the current configuration, or to run diagnostics, do the following: Power the PCM-9575 on.
  • Page 42 Note For Ethernet installation, please see Chapter 7 Chapter 3 Software Configuration...
  • Page 43 PCM-9575 User’s Manual...
  • Page 44 Chapter 4 Ducks that Need Love! Award BIOS Setup This chapter describes how to set BIOS configuration data. Chapter 4 Award BIOS Setup...
  • Page 45 Chapter 4 Award BIOS Setup 4.1 System test and initialization These routines test and initialize board hardware. If the routines encoun- ter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal.
  • Page 46 4.2 Award BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. 4.2.1 Entering setup Power on the computer and press <Del>...
  • Page 47 4.2.2 Standard CMOS Features setup When you choose the Standard CMOS Features option from the Initial Setup Screen menu, the screen shown below is displayed. This standard Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Once a field is high- lighted, on-line help information is displayed in the left bottom of the Menu screen.
  • Page 48 4.2.3 Advanced BIOS Features setup By choosing the Advanced BIOS Features Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9575 Series. Figure 4.3: Advanced BIOS Features setup Chapter 4 Award BIOS Setup...
  • Page 49 4.2.4 Advanced Chipset Features setup By choosing the Advanced Chipset Features option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9575 Series. Figure 4.4: Advanced Chipset Features setup PCM-9575 User’s Manual...
  • Page 50 4.2.5 Integrated Peripherals Choosing the Integrated Peripherals option from the Initial Setup Screen menu should produce the screen below. Here we see the manufacturer’s default values for the PCM-9575 Series. Figure 4.5: Integrated Peripherals 4.2.6 Power Management Setup By choosing the Power Management Setup option from the Initial Setup Screen menu, the screen below is displayed.
  • Page 51 4.2.7 PnP/PCI Configurations By choosing the PnP/PCI Configurations option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9575 Series. Figure 4.7: PnP/PCI Configurations 4.2.8 PC Health Status The PC Health Status option displays information such as CPU and moth- erboard temperatures, fan speeds, and core voltage.
  • Page 52 4.2.9 Frequency/Voltage Control By choosing the Frequency/Voltage Control option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9575 Figure 4.9: Frequency/Voltage Control Caution Incorrect settings in Frequency/Voltage Control may damage the system CPU, video adapter, or other hardware.
  • Page 53 4.2.10 Load Optimized Defaults Load Optimized Defaults loads the default system values directly from ROM. If the stored record created by the Setup program should ever become corrupted (and therefore unusable), these defaults will load auto- matically when you turn the PCM-9575 Series system on. Figure 4.10: Load BIOS defaults screen 4.2.11 Set Password Note...
  • Page 54 At the “Confirm Password” prompt, retype the desired password, then press <Enter>. Select Save to CMOS and EXIT, type <Y>, then <Enter>. To Change Password Choose the Set Password option from the CMOS Setup Utility main menu and press <Enter>. When you see “Enter Password,”...
  • Page 55 4.2.13 Exit Without Saving Selecting this option and pressing <Enter> lets you exit the Setup pro- gram without recording any new values or changing old ones. PCM-9575 User’s Manual...
  • Page 56 PCI SVGA Setup • Introduction • Installation of SVGA drivers -for Windows 95/98/Me -for Windows NT/2000/XP • Further information Chapter 5 PCI SVGA Setup...
  • Page 57 Chapter 5 PCI SVGA Setup 5.1 Introduction The PCM-9575 has an onboard AGP flat panel/VGA interface. The spec- ifications and features are described as follows: 5.1.1 Chipset The PCM-9575 uses a VIA Twister 8606T chipset from VIA Technology Inc. for its AGP/SVGA controller. It supports many popular LCD, and LVDS LCD displays and conventional analog CRT monitors.
  • Page 58 5.1.4 Dual/Simultaneous Display The PCM-9575 uses a VIA Twister VT8606T LCD controller that is capable of providing simultaneous dual view display of the same content on a flat panel and CRT. To set up dual view (simultaneus mode) under Windows 9x, Windows ME, Windows NT/2000/XP, follow these steps: Step 1.
  • Page 59 5.2 Installation of the SVGA Driver Complete the following steps to install the SVGA driver. Follow the pro- cedures in the flow chart that apply to the operating system that you are using within your PCM-9575. Notes: 1. The windows illustrations in this chapter are intended as examples only.
  • Page 60 Step 2. Choose the "Adapter" tab, then press the "Change..." button. Step 3. Press the "Have Disk" button. Chapter 5 PCI SVGA Setup...
  • Page 61 Step 4. Type in the path: D:\Biscuit\9575\VGA\Win9x_Me Step 5. Select the highlighted item, and click the "OK" button. PCM-9575 User’s Manual...
  • Page 62 Step 6. "S3 GraphicsTwister" appears under the adapter tab. Click the "Apply" button, then the "OK" button. Step 7. Press “Yes” to reboot. Chapter 5 PCI SVGA Setup...
  • Page 63 5.2.2 Installation for Windows 98/Me Step 1. Select "Start", "Settings", "Control Panel", "Display", and "Set- tings," then press the "Advanced..." button. PCM-9575 User’s Manual...
  • Page 64 Step 2. Select “Adapter,” then “Change.” Chapter 5 PCI SVGA Setup...
  • Page 65 Step 3. Press “Next,” then “Display a list..” Step 4. Press the “Have disk...” button. PCM-9575 User’s Manual...
  • Page 66 Step 5. Insert the CD into the CD-ROM drive. Type in the path D:\Biscuit\9575\VGA\Win9x_Me Then press “OK” Step 6. Select the highlighted item, then click “OK.” Chapter 5 PCI SVGA Setup...
  • Page 67 Step 7. "S3 Graphics Twister"appears under the adapter tab. Click the "Apply" button. Step 8. Press “Yes” to reboot. PCM-9575 User’s Manual...
  • Page 68 5.2.3 Installation for Windows NT Note: Service Pack X (X = 3, 4, 5, 6,...) must be installed first, before you install the Windows NT VGA driver. Step 1. Select "Start", "Settings", "Control Panel" and double click the "Display" icon. Chapter 5 PCI SVGA Setup...
  • Page 69 Step 2. Choose the "Settings" tab, and press the "Display Type" button. PCM-9575 User’s Manual...
  • Page 70 Step 3. Press the "Change..." button. Chapter 5 PCI SVGA Setup...
  • Page 71 Step 4. Click the "Have Disk..." button. Step 5. Type the path: D:\Biscuit\VGA\WinNT Press the "OK" button. PCM-9575 User’s Manual...
  • Page 72 Step 6. Select the highlighted item, and click the "OK" button. Step 7. Press "Yes" to proceed. Step 8. Press "OK" to reboot. Chapter 5 PCI SVGA Setup...
  • Page 73 5.2.4 Installation for Windows 2000 Step 1. Select "System", "Settings", "Control Panel" and double click the "system" icon. PCM-9575 User’s Manual...
  • Page 74 Step 2. Choose the "Video Controller (VGA Compatible)” button. Chapter 5 PCI SVGA Setup...
  • Page 75 Step 3. Choose the "Drive" button, press “Update Driver...” button. PCM-9575 User’s Manual...
  • Page 76 Step 4. Choose "Display a list of..." , then press “Next” button. Step 5. Choose “Display adapters”, press “Next” button. Chapter 5 PCI SVGA Setup...
  • Page 77 Step 6. Click the “Have Disk” button. Step 7. Type the path D:\Biscuit\9575\VGA\Win2000 press the “OK” button. PCM-9575 User’s Manual...
  • Page 78 Step 8. Press “Finish" to reboot. 5.2.5 Installation for Windows XP Step 1. Select "System", "Settings", "Control Panel" and double click the "system" icon. Chapter 5 PCI SVGA Setup...
  • Page 79 Step 2. Choose “Hardware” and “Device Manager”, press “OK” button. PCM-9575 User’s Manual...
  • Page 80 Step 3. Choose “Video Controller (VGA Compatible), press “OK” but- ton. Chapter 5 PCI SVGA Setup...
  • Page 81 Step 4. Choose "Driver”, “Update Driver”, press “OK” button. Step 5. Choose “Install from a list..” , press “Next”. PCM-9575 User’s Manual...
  • Page 82 Step 6. Choose “Don’t search. I will..”, press “Next” button. Step 7. Choose “Display adapters”, press “Next” button. Chapter 5 PCI SVGA Setup...
  • Page 83 Step 8. Type the path D:\Biscuit\9575\VGA\WinXP then press “OK” button. Step 9. Choose “S3 Graphics Twister + S3 Hotkey” then press “Next” button. PCM-9575 User’s Manual...
  • Page 84 Step 10. Press “Finish" to reboot. 5.3 Further Information For further information about the AGP/VGA installation in your PCM- 9575, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: VIA website: www.via.com.tw Advantech websites: www.advantech.com www.advantech.com.tw Chapter 5 PCI SVGA Setup...
  • Page 85 PCM-9575 User’s Manual...
  • Page 86 Audio Setup The PCM-9575 is equipped with an audio interface that records and plays back CD-quality audio. This chapter provides instructions for installing the software drivers included on the audio driver diskettes. Chapter 6 Audio Setup...
  • Page 87 Chapter 6 Audio Setup 6.1 Introduction The PCM-9575's on-board audio interface provides high-quality stereo sound and FM music synthesis (ESFM) by using the VIA VT82C686 audio controller from VIA. The audio interface can record, compress, and play back voice, sound, and music with built-in mixer control. The PCM-9575 on board audio interface also supports the Plug and Play (PnP) standard and provides PnP configuration for the audio, FM, and MPU-104 logical devices.
  • Page 88 6.2.2 VIA Sound Blaster Installation Follow these steps to enable the Sound Blaster Pro compatible functions. Step 1. Enable the Sound Blaster first on the BIOS setting of the "Onboard Legacy Audio" and "On-Chip Sound". Step 2. Run the "Install.exe". A:>...
  • Page 89 6.3.2 Windows 95/98 drivers Step 1. Click "Start" and select "Settings". Click "Control Panel" and double-click "Add New Hardware". Step 2. In the Add New Hardware Wizard window, click "Next". PCM-9575 User’s Manual...
  • Page 90 Step 3. In the following Add New Hardware Wizard window, click "Next" for Windows to search for Plug and Play devices. Step 4. In the following Add New Hardware Wizard window, select "No, the device isn't in the list."and click "Next". Chapter 6 Audio Setup...
  • Page 91 Step 5. In the following Add New Hardware Wizard window, select "No, I want to select..." and click "Next". Step 6. In the following Add New Hardware Wizard window, select "Sound, video and game controllers" and click "Next". PCM-9575 User’s Manual...
  • Page 92 Step 7. In the following Add New Hardware Wizard window, click "Have Disk...". Step 8. In the Install From Disk window, click "Browse". Chapter 6 Audio Setup...
  • Page 93 Step 9. In the Open window, select "D:\Biscuit\9575\Audio\98se_Me_2k_xp\WIN95_98. Step 10. In the Install From Disk window, click" OK". PCM-9575 User’s Manual...
  • Page 94 Step 11. In the Select Device window, select "VIA PCI Audio Controller (WDM)" and click "OK". Step 12. In the Add New Hardware Wizard window, click "Next". Chapter 6 Audio Setup...
  • Page 95 Step 13. The Copying Files... window will appear. Step 14. In the Add New Hardware Wizard window, click "Finish". Then reboot the system. PCM-9575 User’s Manual...
  • Page 96 6.3.3 Windows NT drivers Step 1. Click "Start" and select "Settings". Click "Control Panel" and double-click "Multimedia". Step 2. In the Multimedia Properties window, select the "Devices" tab. Then select the "Audio Devices" item, and click "Add...". Chapter 6 Audio Setup...
  • Page 97 Step 3. In the Add window, select the "Unlisted..." item and click "OK". Step 4. When the Install Driver window appears, insert the utility disc into the CD-ROM drive. Type: D:\Biscuit\9575\Audio\WinNT\ Then click "OK". PCM-9575 User’s Manual...
  • Page 98 Step 5. In the Add Unlisted or Updated Driver window, select the "VIA PCI Audio controller" item. Then click "OK". Step 6. In the System Setting Change window, click "Restart Now". Chapter 6 Audio Setup...
  • Page 99 6.3.4 Windows 2000 Drivers Step 1. Select “System”, “Setting”, “Control Panel” and double click “system” icon. Step 2. Choose “Multimedia Audio Controller” button. PCM-9575 User’s Manual...
  • Page 100 Step 3. Choose “Driver button, press “Update Driver” button. Step 4. Choose “Sound, video and game controllers”, press “Next” Chapter 6 Audio Setup...
  • Page 101 Step 5. Click the “Have Disk...” button Step 6. Type the path D:\Biscuit\9575\Audio\98se_Me_2k_xp\Win2000 press the “ok” button. Step 7. Click “Have Disk” button PCM-9575 User’s Manual...
  • Page 102 Step 8. Press “Next” button Step 9. Press “Finish” to reboot Chapter 6 Audio Setup...
  • Page 103 PCM-9575 User’s Manual...
  • Page 104 PCI Bus Ethernet Interface This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet drivers for Windows 98/2000/NT • Further information Chapter 7 PCI Bus Ethernet Interface...
  • Page 105 Chapter 7 PCI Bus Ethernet Interface 7.1 Introduction The PCM-9575 is equipped with a high performance 32-bit Ethernet chipset which is fully compliant with IEEE 802.3 100 Mbps CSMA/CD standards. It is supported by major network operating systems. It is also both 100Base-T and 10Base-T compatible.
  • Page 106 7.2.2 Installation for Windows 98 Step 1. a. Select "Start", "Settings". "Control Panel". b. Double click "Network". Step 2. a. Click "Add" and prepare to install network functions. Chapter 7 PCI Bus Ethernet Interface...
  • Page 107 Step 3. a. Select the "Adapter" item to add the Ethernet card. Step 4. a. Click "Have Disk" to install the driver. Step 5. a. Insert the CD into the D: drive b. Fill in "D:\Biscuit\9575\LAN\” c. Click "OK" PCM-9575 User’s Manual...
  • Page 108 Step 6. a. Choose the "Realtek RTL8139(A/B/C/8130) PCI Fast Ethernet" item. b. Click "OK". Step 7. a. Make sure the configurations of relative items are set correctly. b. Click "OK" to reboot. Chapter 7 PCI Bus Ethernet Interface...
  • Page 109 7.2.3 Installation for Windows 2000 Step 1. Open Device Manager, PCM-9575 User’s Manual...
  • Page 110 Step 2. Chapter 7 PCI Bus Ethernet Interface...
  • Page 111 Step 3. Step 4. PCM-9575 User’s Manual...
  • Page 112 Step 5. Step 6. Chapter 7 PCI Bus Ethernet Interface...
  • Page 113 Step 7. Step 8. PCM-9575 User’s Manual...
  • Page 114 Step 9. 7.2.4 Installation for Windows NT Step 1. a. Select "Start", "Settings", "Control Panel" b. Double click "Network" Step 2. a. Choose type of network. Chapter 7 PCI Bus Ethernet Interface...
  • Page 115 b. Click "Next" Step 3. a. Click "Select from list..." PCM-9575 User’s Manual...
  • Page 116 Step 4. Click “Have Disk.” Step 5. a. Insert the Utility CD ROM b. Fill in the correct path: D:\Biscuit\9575\LAN\8139C\winnt4 c. Click "OK". Chapter 7 PCI Bus Ethernet Interface...
  • Page 117 Step 6. Check the highlighted item, and click “OK.” PCM-9575 User’s Manual...
  • Page 118 Click “Next” to continue setup. Step 8. Choose the networking protocols, then click "Next" Chapter 7 PCI Bus Ethernet Interface...
  • Page 119 Step 9. Select the correct Network Services then click "Next" Step 10. Click “Next” to continue setup. PCM-9575 User’s Manual...
  • Page 120 Click “Next” to start the network. 7.3 Further information Realtek website: www.realtek.com.tw Intel website: www.intel.com Advantech websites: www.advantech.com www.advantech.com.tw Chapter 7 PCI Bus Ethernet Interface...
  • Page 121 PCM-9575 User’s Manual...
  • Page 122 Programming the Watchdog Timer The PCM-9575 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned envi- ronments.
  • Page 123 Appendix A Programming the Watchdog Timer A.1 Supported Input Timing Modes In order to program the watchdog timer, you must write a program which writes I/O port address 443 (hex). The output data is a value of time inter- val. The value range is from 01 (hex) to 3E (hex), and the related time interval is 1 sec.
  • Page 124 The following example shows how you might program the watchdog timer in BASIC: REM Watchdog timer example program OUT &H443, data REM Start and restart the watchdog REM Your application task #1 GOSUB 1000 OUT &H443, data REM Reset the timer GOSUB 2000 REM Your application task #2 OUT &H443, data...
  • Page 125 TPC-642 User’s Manual...
  • Page 126 Installing PC/104-Plus Modules This appendix gives instructions for installing PC/104- Plus modules. Appx. B...
  • Page 127 Appendix B Installing PC/104-Plus Modules B.1 Installing PC/104-Plus Modules The PCM-9575's PC/104 connectors give you the flexibility to attach PC/ 104+ modules. Installing these modules on the PCM-9575 is quick and simple. The fol- lowing steps show to mount the PC/104+ modules: Remove the PCM-9575 from your system, paying particular atten- tion to the safety instructions already mentioned above.
  • Page 128 Figure B.1: PC/104+ module mounting diagram Appx. B...
  • Page 129 Figure B.2: PC/104+ module dimensions (mm) (±0.1) TPC-642 User’s Manual...
  • Page 130 Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • CPU Fan Power Connector • Ethernet 10/100Base-T Connector • Audio Connector • CD Drive Connector • Main Power Connector • Keyboard and PS/2 Mouse Connector •...
  • Page 131 Appendix C Pin Assignments C.1 CPU Fan Power Connector (FAN 1) Table C.1: IR connector (FAN 1) Signal Fan speed signal input C.2 Ethernet 10/100Base-T Connector (CN12) Table C.2: Ethernet 10/100Base-T connector (CN12) Signal CRS LED RCV+ RCV- BNC LED XMT+ XMT- PCA-6183 User’s Manual...
  • Page 132 C.3 Audio Connector (CN4) Table C.3: Audio connector (CN4) Signal Signal SPEAKER OUT R+ SPEAKER OUT R- SPEAKER OUT L+ SPEAKER OUT L- LINE OUT R LINE OUT L LINE IN R LINE IN L MIC IN C.4 Audio In Connector (CN2) Table C.4: Audio line-in connector (CN2) Signal CD Audio R...
  • Page 133 C.5 Main Power Connector (CN5) Table C.5: Main Power Connector (CN5) Signal +5 V +12 V N.C. +5 V PCA-6183 User’s Manual...
  • Page 134 C.6 Keyboard and PS/2 Mouse Connector (CN25) Table C.6: Keyboard and mouse connector (CN25) Signal KB CLOCK KB DATA MS CLOCK +5V (KB VCC) MS DATA Appx. C...
  • Page 135 C.7 Floppy Disk Drive Connector (CN18) Table C.7: Floppy Disk Drive Connector (CN18) Signal Signal DENSITY SELECT* DRIVE TYPE INDEX* MOTOR O* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE*...
  • Page 136 C.8 PC/104 plus Connectors (CN17) Table C.8: PC/104+ connectors (CN17) Number Row A Row B Row C Row D IOCHCHK* RESET SBHE* MEMCS16* +5 V LA23 IOCS16* IRQ9 LA22 IRQ10 LA21 IRQ11 DRQ2 LA20 IRQ12 -12V LA19 IRQ15 ENDXFR* LA18 IRQ14 +12V LA17...
  • Page 137 Table C.8: PC/104+ connectors (CN17) Number Row A Row B Row C Row D IRQ5 ---- ---- IRQ4 ---- ---- IRQ3 ---- ---- DACK2* ---- ---- ---- ---- BALE ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- * low active PCA-6183 User’s Manual...
  • Page 138 C.9 IDE Hard Drive Connector (CN14, CN16) Table C.9: IDE HDD connector (CN14, CN16) Signal Signal IDE RESET* DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14...
  • Page 139 C.10 Parallel Port Connector (CN15) Table C.10: Parallel Port Connector (CN15) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active PCA-6183 User’s Manual...
  • Page 140 C.11 Power & HDD LED Connector(CN13) Table C.11: Power & HDD LED Connector (CN13) Signal power LED+ (+5V) HDD LED + power LED - (GND) HDD LED - C.12 Reset Button Connector (CN22) Table C.12: Reset Button Connector (CN22) Signal Reset signal input Appx.
  • Page 141 C.13 USB Connector (CN20, CN28) Table C.13: USB Connector (CN20, CN28) Signal Signal +5 V +5 V Chassis GND C.14 LCD Inverter Backlight Connector (CN6) Table C.14: LCD Inverter Backlight Connector (CN6) Signal +12 V ENABKL +5 V PCA-6183 User’s Manual...
  • Page 142 C.15 IR Connector (CN24) Table C.15: IR Connector (CN24) Signal VCC (5 V) N.C. IR receive IR transmit C.16 CRT Display Connector (CN8) Table C.16: CRT Display Connector (CN8) Signal Signal VGA G +5 V H-sync signal GREEN VGA G VGA G V-sync signal BLUE...
  • Page 143 C.17 TV (video) Out Connector (CN1) Table C.17: TV (video) Out Connector (CN1) Signal Luminance out (S-Video Y output, brightness) Chrominance out (S-Video C output, color) Composite video out PCA-6183 User’s Manual...
  • Page 144 C.18 Flat Panel Connector (CN11) Table C.18: Flat Panel Connector (CN11) Signal Signal VDDSAFE5 (+5v output) VDDSAFE5 (+5v output) VDDSAFE3 (+3.3 v VDDSAFE3 (+3.3 v output) output) SHFCLK M/DE ENAVEE Note: The model number of the CN11 socket is DF13A-40DP-1.25V (Hirose Electric Co., Ltd.) Appx.
  • Page 145 C.19 Extended Flat Panel Display Connector (CN10) Table C.19: Extended Flat Panel Display Connector (CN10) Signal Signal Note: The model number of the CN10 socket is DF13A-20DP-1.25V (Hirose Electric Co., Ltd.) PCA-6183 User’s Manual...
  • Page 146 C.20 LCD Signal Mapping Table C.20: LCD Signal Mapping 16-bit 24-bit 18-bit 24-bit 36-bit Name DSTN DSTN PD10 PD11 PD12 PD13 PD14 PD15 PD16 PD17 PD18 PD19 PD20 PD21 PD22 PD23 PD24 PD25 PD26 PD27 PD28 PD29 PD30 PD31 PD32 PD33 PD34 PD35...
  • Page 147 C.21 LVDS Connector (CN9) Table C.21: LVDS Connector (CN9) Signal Signal TX0+(Channel 1) TX0+(Channel 2) TX0-(Channel 1) TX0-(Channel 2) TX1+(Channel 1) TX1+(Channel 2) TX1-(Channel 1) TX1-(Channel 2) TX2+(Channel 1) TX2+(Channel 2) TX2-(Channel 1) TX2-(Channel 2) TX3+(Channel 1) TX3+(Channel 2) TX3-(Channel 1) TX3-(Channel 2) VDD (+3.3V) VDD (+3.3V)
  • Page 148 C.23 COM Port Connector (CN19) Table C.23: COM Port Connector (CN19) Signal Signal RLSD1 (DCD1) DSR1 RTS1 CTS1 DTR1 RLSD2 (DCD2) DSR2 RTS2 CTS2 DTR2 RLSD3 (DCD3) DSR3 RTS3 CTS3 DTR3 RLSD4 (DCD4) DSR4 RTS4 CTS4 DTR4 Appx. C...
  • Page 149 C.24 CompactFlash Card Connector (CN26) Table C.24: CompactFlash Card Connector (CN26) Signal Signal *CS0 *ATA SEL +5 V -IOCS16 *CD2 -CD1 -CS1 *VS1 -IORD *IOWR INTRQ +5 V *CSEL -VS2 *RESER IORDY *INPACK -REG *DASP -PDIAG * low active PCA-6183 User’s Manual...
  • Page 150 C.25 ATX Power Feature Connector (CN3) Table C.25: ATX Power Feature Connector (CN3) Signal 5VSB (Stand by voltage) PS. ON# Appx. C...
  • Page 151 PCA-6183 User’s Manual...
  • Page 152 System Assignments This appendix contains information of a detailed nature. It includes: • System I/O ports • 1st MB memory map • DMA channel assignments • Interrupt assignments Appx. D...
  • Page 153 Appendix D System Assignments D.1 System I/O Ports Table D.1: System I/O ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, master 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 080-09F DMA page register 0A0-0BF Interrupt controller 2...
  • Page 154 D.2 1st MB memory map Table D.2: 1st MB memory map Addr. range (Hex) Device F0000h - FFFFFh System ROM *CC000h - EFFFFh Unused (reserved for Ethernet ROM) C0000h - CBFFFh Expansion ROM (for VGA BIOS) B8000h - BFFFFh CGA/EGA/VGA text B0000h - B7FFFh Unused A0000h - AFFFFh...
  • Page 155 D.4 Interrupt assignments Table D.4: Interrupt assignments Interrupt# Interrupt source IRQ 0 Interval timer IRQ 1 Keyboard IRQ 2 Interrupt from controller 2 (cascade) IRQ 3 COM2 IRQ 4 COM1 IRQ 5 COM4 IRQ 6 IRQ 7 LPT1 IRQ 8 IRQ 9 Reserved (audio) IRQ 10...
  • Page 156 Optional Extras for the PCM-9575 Appx. E...
  • Page 157 E.1 PCM-10586-5A00 cable kit for PCM-9575 The PCM-9575 requires several cables for normal operation. You can make them yourself or purchase an optional cable kit assembly, which includes the following: PCM-10586-5V00 cable kit for PCM-9575 PCM- Cable Part No. 9575 Terminating Connector Description Connector...
  • Page 158 E.2 Optional LCD cables 10.4" TFT LCD panel (CN14) Table E.1: Optional LCD cables 10.4" TFT LCD panel Part no. Cable description Panel type 1700090501 Cable DF9 (2 mm) 50 cm Toshiba LTM10C042 1703440151 Wire 30P/44P 15 cm Toshiba LTM12C275A Note: The above LCD cables have links via 24-bit LCD cable adaptor (E.6) to connect to PCM-9575 E.3 Optional USB cable (CN20)
  • Page 159 PCM-9575 User’s Manual...
  • Page 160 Mechanical Drawings Appx. F...
  • Page 161 F.1 Mechanical Drawings Figure F.1: PCM-9575 Mechanical Drawing (Side view for PCM-9575F-Q0A1 (w/ fan) and PCM-9575F-M0A1(w/o fan) only) PCM-9575 User’s Manual...
  • Page 162 Figure F.2: PCM-9575 Mechanical Drawing (component side) Appx. F...
  • Page 163 Figure F.3: PCM-9575 Mechanical Drawing (solder side) PCM-9575 User’s Manual...

This manual is also suitable for:

Pcm-9575
