PCM-9575
EBX VIA Eden/Ezra SBC with
CPU,LCD, Ethernet, Audio, PCI
and PC/104-Plus

Users Manual

i

Advertisement

Table of Contents
loading

Related Manuals for Advantech PCM-9575

Summary of Contents for Advantech PCM-9575

  • Page 1: Users Manual

    PCM-9575 EBX VIA Eden/Ezra SBC with CPU,LCD, Ethernet, Audio, PCI and PC/104-Plus Users Manual...
  • Page 2 SMI is a trademark of Silicon Motion, Inc. Creative is a trademark of Creative Technology LTD. All other product names or trademarks are properties of their respective owners. For more information on this and other Advantech products, please visit our websites at: http://www.advantech.com http://www.advantech.com/epc For technical support and service, please visit our support website at: http://support.advantech.com...

  • Page 3: Packing List

    PCM-9575F-M0A1 W/ Eden-667 CPU and heat sink Additional Information and Assistance 1. Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. 2. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
  • Page 4 PCM-9575 User’s Manual...

  • Page 5: Table Of Contents

    Table of Contents Contents Chapter 1 General Information ........1 Introduction ............... 2 Features ................3 Specifications ..............4 1.3.1 Standard EBX SBC Functions ..........4 1.3.2 VGA/LCD Interface ..............4 1.3.3 LVDS: Supports 2 Channel (2 x 18 bit) LVDS interface..5 1.3.4 Audio function................
  • Page 6 2.14.2Main power connector, +5 V, +12 V (CN5) ......17 2.14.3CPU Fan power supply connector (FAN1) ......17 2.15 ATX power control connector (CN3, CN23)....17 2.15.1ATX feature (CN3), soft power switch conn (CN23) ..... 17 Figure 2.3: Wiring for ATX soft power switch function ..18 2.16 IR connector (CN24)............
  • Page 7 Table of Contents Chapter 4 Award BIOS Setup.........33 System test and initialization........... 34 4.1.1 System configuration verification ........... 34 Award BIOS setup ............35 4.2.1 Entering setup................. 35 Figure 4.1: BIOS setup program initial screen....35 4.2.2 Standard CMOS Features setup ..........36 Figure 4.2: CMOS Features setup........
  • Page 8 Chapter 6 Audio Setup.............75 Introduction ..............76 DOS utilities..............76 6.2.1 VIA Sound Blaster Pro compatible set up program ....76 6.2.2 VIA Sound Blaster Installation ..........77 Driver installation............77 6.3.1 Before you begin ..............77 6.3.2 Windows 95/98 drivers ............78 6.3.3 Windows NT drivers ...............
  • Page 9 1st MB memory map............. 143 DMA channel assignments..........143 Interrupt assignments ............ 144 Appendix E Optional Extras for the PCM-9575 ....145 PCM-10586-5A00 cable kit for PCM-9575....146 Optional LCD cables 10.4" TFT LCD panel (CN14) ... 147 Optional USB cable (CN20) ......... 147 ATX Power Control Cable (CN3).........

  • Page 11: Chapter 1 General Information

    General Information This chapter gives background information on the PCM-9575. Sections include: • Introduction • Features • Specifications • Board layout and dimensions Chapter 1 General Information...

  • Page 12: Introduction

    (SBC) with audio controller, a 4X AGP SVGA controller, a PCI 10/100Base-T Ethernet interface, one PCI slot, and one PC/104-Plus expansion connector. The PCM-9575’s design is based on the EBX form factor that provides support for PC/104 and PC/104-Plus module expan- sion.

  • Page 13: Features

    1.2 Features • Embedded VIA low-power Eden/Ezra processor • EBX form factor which supports both PC/104-Plus and PCI slot • Supports one 36 bit TFT LCD panel, with up to 1024 x 768 resolu- tion • Supports 2 channel LVDS interface •...

  • Page 14: Vga/Lcd Interface

    • Audio interface: Microphone in, Line in, CD audio in; Line out, Speaker L, Speaker R • Power: Accepts +12 V source for improved audio quality 1.3.5 TV-out (optional) • Chipset: VIA VT 1621 Supports NTSC, NTSC=EIA (Japan) and PAL TV formats PCM-9575 User’s Manual...

  • Page 15: Pci Bus Ethernet Interface

    1.3.7 Mechanical and Environmental • Dimensions (L x W): EBX form factor, 203 x 146 mm (8" x 5.75") • Power supply voltage: +5 V ±5%, +12V ±5% (PCM-9575 rev A101, A102) +5 V ±5% (PCM-9575 rev A103) • Power requirements: Max: 4.5A @ +5V, 0.55A @ +12V (within 5ms after power on) (rev A101,...

  • Page 16: Board Layout: Dimensions

    1.4 Board layout: dimensions Figure 1.1: Board layout: dimensions PCM-9575 User’s Manual...

  • Page 17: Chapter 2 Installation

    Installation This chapter explains the setup procedures of PCM-9575 hardware, including instruc- tions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the installation procedure. Chapter 2 Installation...

  • Page 18: Jumpers

    Chapter 2 Installation 2.1 Jumpers The PCM-9575 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 2.1: Jumpers Label Function PCI VIO select...
  • Page 19 Table 2.2: Connectors CRT display connector LVDS connector CN10 Ext. flat panel connector CN11 Flat panel connector CN12 Ethernet connector CN13 Power & HDD LED connector CN14 IDE hard drive connector (secondary) CN15 Parallel port connector CN16 IDE hard drive connector (primary) CN17 PC/104 plus (ISA + PCI) expansion CN18...

  • Page 20: Locating Jumpers

    2.3 Locating jumpers Figure 2.1: Jumper locations PCM-9575 User’s Manual...

  • Page 21: Locating Connectors

    2.4 Locating Connectors Figure 2.2: Connectors (component side) Chapter 2 Installation...

  • Page 22: Setting Jumpers

    A pair of needle-nose pliers may be helpful when working with jumpers. If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes. Generally, you simply need a standard cable to make most connections. PCM-9575 User’s Manual...

  • Page 23: Clear Cmos (Jp4)

    2.6 Clear CMOS (JP4) Warning! To avoid damaging the computer, always turn off the power supply before setting “Clear CMOS.” Before turning on the power supply, set the jumper back to “3.0 V Battery On.” This jumper is used to erase CMOS data and reset system BIOS informa- tion.

  • Page 24: Installing Dimms

    2.8 IDE, CDROM hard drive connector (CN14, CN16) The PCM-9575 provides 2 IDE channels which you can attach up to four Enhanced Integrated Device Electronics hard disk drives or CDROM to the PCM-9575’s internal controller. The PCM-9575's IDE controller uses a PCI interface.

  • Page 25: Solid State Disk

    BIOS settings. 2.10 Floppy drive connector (CN18) You can attach up to two floppy drives to the PCM-9575’s on-board con- troller. You can use any combination of 5.25” (360 KB and 1.2 MB) and/ or 3.5” (720 KB, 1.44 MB, and 2.88 MB) drives.

  • Page 26: Parallel Port Connector (Cn15)

    You can select ECP/EPP DMA channel via BIOS setup. 2.12 Keyboard and PS/2 mouse connector (CN25) The PCM-9575 board provides a keyboard connector that supports both a keyboard and a PS/2 style mouse. In most cases, especially in embedded applications, a keyboard is not used. If the keyboard is not present, the standard PC/AT BIOS will report an error or fail during power-on self- test (POST) after a reset.

  • Page 27: 1Power & Hdd Led (Cn13)

    Supplies secondary power to devices that require -5 V and -12 V. 2.14.2 Main power connector, +5 V, +12 V (CN5) Supplies main power to the PCM-9575 (+5 V), and to devices that require +12 V. 2.14.3 CPU Fan power supply connector (FAN1) Provides power supply to CPU cooling fan.

  • Page 28: Ir Connector (Cn24)

    BIOS setup. 2.17 Audio interfaces (CN4, CN2) The PCM-9575 is equipped with a high-quality audio interface, which provides 16-bit CD-quality recording and playback as well as OPL3 com- patible FM music. It is supported by all major operating systems.

  • Page 29: 1Audio Connector (Cn4)

    2.17.2 CD audio input connector (CN2) Any CD-ROM drive can provide analog audio signal output when used as a music CD player. The CN2 on PCM-9575 is a connector to input CD audio signals into the audio controller. The audio cable of your CD-ROM drive will be used to connect to CN2.

  • Page 30: Vga/Lcd/Lvds Interface Connections

    CN11 consists of a 40-pin connector which can support a 24-bit LCD panel. It is Hirose’s product no. DF13A-40DP-1.25 V The PCM-9575 provides a bias control signal on CN11 that can be used to control the LCD bias voltage. It is recommended that the LCD bias voltage not be applied to the panel until the logic supply voltage (+5 V or +3.3 V) and panel video signals are stable.

  • Page 31: Table 2.4: S1 Panel Type Select

    ** will support in the future 2.20 TV-out interface (optional) (CN1) The PCM-9575 board provides optional TV-out via CN1. This consists of a 5-pin wafer box header. Output supports composite video and S-video connectors via an optional cable kit (p/n: 1103050306). TV-out genera- tors use both NTSC and PAL formats.

  • Page 32: Ethernet Configuration

    The medium type can be configured via the RSET8139.EXE program included on the utility disk. (See Chapter 3 for detailed information.) 2.21.1 100Base-T connector (CN12) 10/100Base-T connects to the PCM-9575 via an adapter cable to a 10-pin polarized header (CN12). 2.21.2 Network boot The Network Boot feature can be utilized by incorporating the Boot ROM image files for the appropriate network operating system.

  • Page 33: 1Watchdog Timer Action (Jp5)

    * default setting 2.23 USB connectors (CN20, CN28) The PCM-9575 board provides up to four USB (Universal Serial Bus) ports, with USB3 and USB4 optional. This gives complete Plug and Play, and hot attach/detach for up to 127 external devices. The USB interfaces comply with USB specification Rev.
  • Page 34 PCM-9575 User’s Manual...

  • Page 35: Chapter 3 Software Configuration

    Software Configuration This chapter details the software configura- tion information. It shows you how to config- ure the card to match your application requirements. The AWARD System BIOS is covered in Chapter 4. Sections include: • Introduction • Connections for standard LCDs •...

  • Page 36: Introduction

    Chapter 3 Software Configuration 3.1 Introduction The PCM-9575 system BIOS and custom drivers are located in a 256 Kbyte, Flash ROM device, designated U18. A single Flash chip holds the system BIOS, VGA BIOS and network Boot ROM image. The display can be configured via CMOS settings.

  • Page 37: Connections To Three Standard Lcds

    The following tables illustrate typical LCD connection pinouts for the PCM-9575. 3.2.1 Connections to Toshiba LTM10C209A (640 x 480 TFT color LCD) Table 3.1: Connections to Toshiba LTM10C209A LTM10C209A PCM-9575 CN11 Name Name SHFCLK ENAB M/DE Chapter 3 Software Configuration...

  • Page 38: Connections (1024 X 768 Tft Color Lcd)

    CN 11-25 PD16 CN1-16 CN 11-27 PD18 CN1-17 CN 11-29 PD20 CN1-18 CN 11-31 PD22 CN1-19 CN 10-1 CN1-20 CN 10-3 PD24 CN1-21 CN 10-5 PD26 CN1-22 CN 10-7 PD28 CN1-23 CN 10-9 PD30 CN1-24 CN 10-11 PD32 PCM-9575 User’s Manual...

  • Page 39: Connections (800 X 600 Tft Color Lcd)

    CN1-27 CN 11-34 CN1-28 CN 11-1 CN1-29 CN 11-2 CN1-30 CN 11-8 3.2.3 Connections to Toshiba LTM12C275A (800 x 600 TFT color LCD) Table 3.3: Connections to Toshiba LTM12C275A LTM12C275A PCM-9575 CN11 Name Name NCLK SHFCLK Chapter 3 Software Configuration...

  • Page 40: Ethernet Software Configuration

    To configure the medium type, to view the current configuration, or to run diagnostics, do the following: Power the PCM-9575 on. Make sure that the RSET8139.EXE file is located in the working drive. At the prompt, type RSET8139.EXE and press <Enter>. The Ether- net configuration program will then be displayed.
  • Page 41 Note For Ethernet installation, please see Chapter 7 Chapter 3 Software Configuration...
  • Page 42 PCM-9575 User’s Manual...

  • Page 43: Chapter 4 Award Bios Setup

    Chapter 4 Ducks that Need Love! Award BIOS Setup This chapter describes how to set BIOS configuration data. Chapter 4 Award BIOS Setup...

  • Page 44: System Test And Initialization

    The CMOS memory has lost power and the configuration informa- tion has been erased. The PCM-9575 Series' CMOS memory has an integral lithium battery backup. The battery backup should last ten years in normal service, but when it finally runs down, you will need to replace the complete unit.

  • Page 45: Award Bios Setup

    4.2 Award BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. 4.2.1 Entering setup Power on the computer and press <Del>...

  • Page 46: Standard Cmos Features Setup

    Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Once a field is high- lighted, on-line help information is displayed in the left bottom of the Menu screen. Figure 4.2: CMOS Features setup PCM-9575 User’s Manual...

  • Page 47: Advanced Bios Features Setup

    By choosing the Advanced BIOS Features Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9575 Series. Figure 4.3: Advanced BIOS Features setup Chapter 4 Award BIOS Setup...

  • Page 48: Advanced Chipset Features Setup

    4.2.4 Advanced Chipset Features setup By choosing the Advanced Chipset Features option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9575 Series. Figure 4.4: Advanced Chipset Features setup PCM-9575 User’s Manual...

  • Page 49: Integrated Peripherals

    By choosing the Power Management Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9575 Series. Figure 4.6: Power Management Setup Chapter 4 Award BIOS Setup...

  • Page 50: Pnp/Pci Configurations

    4.2.7 PnP/PCI Configurations By choosing the PnP/PCI Configurations option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9575 Series. Figure 4.7: PnP/PCI Configurations 4.2.8 PC Health Status The PC Health Status option displays information such as CPU and moth- erboard temperatures, fan speeds, and core voltage.

  • Page 51: Frequency/Voltage Control

    4.2.9 Frequency/Voltage Control By choosing the Frequency/Voltage Control option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9575 Figure 4.9: Frequency/Voltage Control Caution Incorrect settings in Frequency/Voltage Control may damage the system CPU, video adapter, or other hardware.

  • Page 52: 10Load Optimized Defaults

    ROM. If the stored record created by the Setup program should ever become corrupted (and therefore unusable), these defaults will load auto- matically when you turn the PCM-9575 Series system on. Figure 4.10: Load BIOS defaults screen 4.2.11 Set Password...

  • Page 53: 12Save & Exit Setup

    At the “Confirm Password” prompt, retype the desired password, then press <Enter>. Select Save to CMOS and EXIT, type <Y>, then <Enter>. To Change Password Choose the Set Password option from the CMOS Setup Utility main menu and press <Enter>. When you see “Enter Password,”...

  • Page 54: 13Exit Without Saving

    4.2.13 Exit Without Saving Selecting this option and pressing <Enter> lets you exit the Setup pro- gram without recording any new values or changing old ones. PCM-9575 User’s Manual...

  • Page 55: Chapter 5 Pci Svga Setup

    PCI SVGA Setup • Introduction • Installation of SVGA drivers -for Windows 95/98/Me -for Windows NT/2000/XP • Further information Chapter 5 PCI SVGA Setup...

  • Page 56: Introduction

    Chapter 5 PCI SVGA Setup 5.1 Introduction The PCM-9575 has an onboard AGP flat panel/VGA interface. The spec- ifications and features are described as follows: 5.1.1 Chipset The PCM-9575 uses a VIA Twister 8606T chipset from VIA Technology Inc. for its AGP/SVGA controller. It supports many popular LCD, and LVDS LCD displays and conventional analog CRT monitors.

  • Page 57: Dual/Simultaneous Display

    5.1.4 Dual/Simultaneous Display The PCM-9575 uses a VIA Twister VT8606T LCD controller that is capable of providing simultaneous dual view display of the same content on a flat panel and CRT. To set up dual view (simultaneus mode) under Windows 9x, Windows ME, Windows NT/2000/XP, follow these steps: Step 1.

  • Page 58: Installation Of The Svga Driver

    5.2 Installation of the SVGA Driver Complete the following steps to install the SVGA driver. Follow the pro- cedures in the flow chart that apply to the operating system that you are using within your PCM-9575. Notes: 1. The windows illustrations in this chapter are intended as examples only.
  • Page 59 Step 2. Choose the "Adapter" tab, then press the "Change..." button. Step 3. Press the "Have Disk" button. Chapter 5 PCI SVGA Setup...
  • Page 60 Step 4. Type in the path: D:\Biscuit\9575\VGA\Win9x_Me Step 5. Select the highlighted item, and click the "OK" button. PCM-9575 User’s Manual...
  • Page 61 Step 6. "S3 GraphicsTwister" appears under the adapter tab. Click the "Apply" button, then the "OK" button. Step 7. Press “Yes” to reboot. Chapter 5 PCI SVGA Setup...

  • Page 62: Installation For Windows 98/Me

    5.2.2 Installation for Windows 98/Me Step 1. Select "Start", "Settings", "Control Panel", "Display", and "Set- tings," then press the "Advanced..." button. PCM-9575 User’s Manual...
  • Page 63 Step 2. Select “Adapter,” then “Change.” Chapter 5 PCI SVGA Setup...
  • Page 64 Step 3. Press “Next,” then “Display a list..” Step 4. Press the “Have disk...” button. PCM-9575 User’s Manual...
  • Page 65 Step 5. Insert the CD into the CD-ROM drive. Type in the path D:\Biscuit\9575\VGA\Win9x_Me Then press “OK” Step 6. Select the highlighted item, then click “OK.” Chapter 5 PCI SVGA Setup...
  • Page 66 Step 7. "S3 Graphics Twister"appears under the adapter tab. Click the "Apply" button. Step 8. Press “Yes” to reboot. PCM-9575 User’s Manual...

  • Page 67: Installation For Windows Nt

    5.2.3 Installation for Windows NT Note: Service Pack X (X = 3, 4, 5, 6,...) must be installed first, before you install the Windows NT VGA driver. Step 1. Select "Start", "Settings", "Control Panel" and double click the "Display" icon. Chapter 5 PCI SVGA Setup...
  • Page 68 Step 2. Choose the "Settings" tab, and press the "Display Type" button. PCM-9575 User’s Manual...
  • Page 69 Step 3. Press the "Change..." button. Chapter 5 PCI SVGA Setup...
  • Page 70 Step 4. Click the "Have Disk..." button. Step 5. Type the path: D:\Biscuit\VGA\WinNT Press the "OK" button. PCM-9575 User’s Manual...
  • Page 71 Step 6. Select the highlighted item, and click the "OK" button. Step 7. Press "Yes" to proceed. Step 8. Press "OK" to reboot. Chapter 5 PCI SVGA Setup...

  • Page 72: Installation For Windows 2000

    5.2.4 Installation for Windows 2000 Step 1. Select "System", "Settings", "Control Panel" and double click the "system" icon. PCM-9575 User’s Manual...
  • Page 73 Step 2. Choose the "Video Controller (VGA Compatible)” button. Chapter 5 PCI SVGA Setup...
  • Page 74 Step 3. Choose the "Drive" button, press “Update Driver...” button. PCM-9575 User’s Manual...
  • Page 75 Step 4. Choose "Display a list of..." , then press “Next” button. Step 5. Choose “Display adapters”, press “Next” button. Chapter 5 PCI SVGA Setup...
  • Page 76 Step 6. Click the “Have Disk” button. Step 7. Type the path D:\Biscuit\9575\VGA\Win2000 press the “OK” button. PCM-9575 User’s Manual...

  • Page 77: Installation For Windows Xp

    Step 8. Press “Finish" to reboot. 5.2.5 Installation for Windows XP Step 1. Select "System", "Settings", "Control Panel" and double click the "system" icon. Chapter 5 PCI SVGA Setup...
  • Page 78 Step 2. Choose “Hardware” and “Device Manager”, press “OK” button. PCM-9575 User’s Manual...
  • Page 79 Step 3. Choose “Video Controller (VGA Compatible), press “OK” but- ton. Chapter 5 PCI SVGA Setup...
  • Page 80 Step 4. Choose "Driver”, “Update Driver”, press “OK” button. Step 5. Choose “Install from a list..” , press “Next”. PCM-9575 User’s Manual...
  • Page 81 Step 6. Choose “Don’t search. I will..”, press “Next” button. Step 7. Choose “Display adapters”, press “Next” button. Chapter 5 PCI SVGA Setup...
  • Page 82 Step 8. Type the path D:\Biscuit\9575\VGA\WinXP then press “OK” button. Step 9. Choose “S3 Graphics Twister + S3 Hotkey” then press “Next” button. PCM-9575 User’s Manual...

  • Page 83: Further Information

    Step 10. Press “Finish" to reboot. 5.3 Further Information For further information about the AGP/VGA installation in your PCM- 9575, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: VIA website: www.via.com.tw Advantech websites: www.advantech.com www.advantech.com.tw Chapter 5 PCI SVGA Setup...
  • Page 84 PCM-9575 User’s Manual...

  • Page 85: Chapter 6 Audio Setup

    Audio Setup The PCM-9575 is equipped with an audio interface that records and plays back CD-quality audio. This chapter provides instructions for installing the software drivers included on the audio driver diskettes. Chapter 6 Audio Setup...

  • Page 86: Introduction

    VIA. The audio interface can record, compress, and play back voice, sound, and music with built-in mixer control. The PCM-9575 on board audio interface also supports the Plug and Play (PnP) standard and provides PnP configuration for the audio, FM, and MPU-104 logical devices.

  • Page 87: Via Sound Blaster Installation

    6.3.1 Before you begin Please read the instructions in this chapter carefully before you attempt installation. The audio drivers for the PCM-9575 board are located on the audio driver CD. Run the supplied SETUP program to install the drivers; don’t copy the files manually.

  • Page 88: Windows 95/98 Drivers

    6.3.2 Windows 95/98 drivers Step 1. Click "Start" and select "Settings". Click "Control Panel" and double-click "Add New Hardware". Step 2. In the Add New Hardware Wizard window, click "Next". PCM-9575 User’s Manual...
  • Page 89 Step 3. In the following Add New Hardware Wizard window, click "Next" for Windows to search for Plug and Play devices. Step 4. In the following Add New Hardware Wizard window, select "No, the device isn't in the list."and click "Next". Chapter 6 Audio Setup...
  • Page 90 Step 5. In the following Add New Hardware Wizard window, select "No, I want to select..." and click "Next". Step 6. In the following Add New Hardware Wizard window, select "Sound, video and game controllers" and click "Next". PCM-9575 User’s Manual...
  • Page 91 Step 7. In the following Add New Hardware Wizard window, click "Have Disk...". Step 8. In the Install From Disk window, click "Browse". Chapter 6 Audio Setup...
  • Page 92 Step 9. In the Open window, select "D:\Biscuit\9575\Audio\98se_Me_2k_xp\WIN95_98. Step 10. In the Install From Disk window, click" OK". PCM-9575 User’s Manual...
  • Page 93 Step 11. In the Select Device window, select "VIA PCI Audio Controller (WDM)" and click "OK". Step 12. In the Add New Hardware Wizard window, click "Next". Chapter 6 Audio Setup...
  • Page 94 Step 13. The Copying Files... window will appear. Step 14. In the Add New Hardware Wizard window, click "Finish". Then reboot the system. PCM-9575 User’s Manual...

  • Page 95: Windows Nt Drivers

    6.3.3 Windows NT drivers Step 1. Click "Start" and select "Settings". Click "Control Panel" and double-click "Multimedia". Step 2. In the Multimedia Properties window, select the "Devices" tab. Then select the "Audio Devices" item, and click "Add...". Chapter 6 Audio Setup...
  • Page 96 Step 3. In the Add window, select the "Unlisted..." item and click "OK". Step 4. When the Install Driver window appears, insert the utility disc into the CD-ROM drive. Type: D:\Biscuit\9575\Audio\WinNT\ Then click "OK". PCM-9575 User’s Manual...
  • Page 97 Step 5. In the Add Unlisted or Updated Driver window, select the "VIA PCI Audio controller" item. Then click "OK". Step 6. In the System Setting Change window, click "Restart Now". Chapter 6 Audio Setup...

  • Page 98: Windows 2000 Drivers

    6.3.4 Windows 2000 Drivers Step 1. Select “System”, “Setting”, “Control Panel” and double click “system” icon. Step 2. Choose “Multimedia Audio Controller” button. PCM-9575 User’s Manual...
  • Page 99 Step 3. Choose “Driver button, press “Update Driver” button. Step 4. Choose “Sound, video and game controllers”, press “Next” Chapter 6 Audio Setup...
  • Page 100 Step 5. Click the “Have Disk...” button Step 6. Type the path D:\Biscuit\9575\Audio\98se_Me_2k_xp\Win2000 press the “ok” button. Step 7. Click “Have Disk” button PCM-9575 User’s Manual...
  • Page 101 Step 8. Press “Next” button Step 9. Press “Finish” to reboot Chapter 6 Audio Setup...
  • Page 102 PCM-9575 User’s Manual...

  • Page 103: Chapter 7 Pci Bus Ethernet Interface

    PCI Bus Ethernet Interface This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet drivers for Windows 98/2000/NT • Further information Chapter 7 PCI Bus Ethernet Interface...

  • Page 104: Introduction

    7.2 Installation of Ethernet driver Before installing the Ethernet driver, note the procedures below. You must know which operating system you are using in your PCM-9575 Series, and then refer to the corresponding installation flow chart. Then just follow the steps described in the flow chart. You will quickly and successfully complete the installation, even if you are not familiar with instructions for MS-DOS or Windows.

  • Page 105: Installation For Windows 98

    7.2.2 Installation for Windows 98 Step 1. a. Select "Start", "Settings". "Control Panel". b. Double click "Network". Step 2. a. Click "Add" and prepare to install network functions. Chapter 7 PCI Bus Ethernet Interface...
  • Page 106 Step 3. a. Select the "Adapter" item to add the Ethernet card. Step 4. a. Click "Have Disk" to install the driver. Step 5. a. Insert the CD into the D: drive b. Fill in "D:\Biscuit\9575\LAN\” c. Click "OK" PCM-9575 User’s Manual...
  • Page 107 Step 6. a. Choose the "Realtek RTL8139(A/B/C/8130) PCI Fast Ethernet" item. b. Click "OK". Step 7. a. Make sure the configurations of relative items are set correctly. b. Click "OK" to reboot. Chapter 7 PCI Bus Ethernet Interface...

  • Page 108: Installation For Windows 2000

    7.2.3 Installation for Windows 2000 Step 1. Open Device Manager, PCM-9575 User’s Manual...
  • Page 109 Step 2. Chapter 7 PCI Bus Ethernet Interface...
  • Page 110 Step 3. Step 4. PCM-9575 User’s Manual...
  • Page 111 Step 5. Step 6. Chapter 7 PCI Bus Ethernet Interface...
  • Page 112 Step 7. Step 8. PCM-9575 User’s Manual...

  • Page 113: Installation For Windows Nt

    Step 9. 7.2.4 Installation for Windows NT Step 1. a. Select "Start", "Settings", "Control Panel" b. Double click "Network" Step 2. a. Choose type of network. Chapter 7 PCI Bus Ethernet Interface...
  • Page 114 Click "Next" Step 3. a. Click "Select from list..." PCM-9575 User’s Manual...
  • Page 115 Step 4. Click “Have Disk.” Step 5. a. Insert the Utility CD ROM b. Fill in the correct path: D:\Biscuit\9575\LAN\8139C\winnt4 c. Click "OK". Chapter 7 PCI Bus Ethernet Interface...
  • Page 116 Step 6. Check the highlighted item, and click “OK.” PCM-9575 User’s Manual...
  • Page 117 Click “Next” to continue setup. Step 8. Choose the networking protocols, then click "Next" Chapter 7 PCI Bus Ethernet Interface...
  • Page 118 Step 9. Select the correct Network Services then click "Next" Step 10. Click “Next” to continue setup. PCM-9575 User’s Manual...

  • Page 119: Further Information

    Click “Next” to start the network. 7.3 Further information Realtek website: www.realtek.com.tw Intel website: www.intel.com Advantech websites: www.advantech.com www.advantech.com.tw Chapter 7 PCI Bus Ethernet Interface...
  • Page 120 PCM-9575 User’s Manual...

  • Page 121: Appendix A Programming The Watchdog Timer

    Programming the Watchdog Timer The PCM-9575 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned envi- ronments.

  • Page 122: Supported Input Timing Modes

    Appendix A Programming the Watchdog Timer A.1 Supported Input Timing Modes In order to program the watchdog timer, you must write a program which writes I/O port address 443 (hex). The output data is a value of time inter- val. The value range is from 01 (hex) to 3E (hex), and the related time interval is 1 sec.
  • Page 123 The following example shows how you might program the watchdog timer in BASIC: REM Watchdog timer example program OUT &H443, data REM Start and restart the watchdog REM Your application task #1 GOSUB 1000 OUT &H443, data REM Reset the timer GOSUB 2000 REM Your application task #2 OUT &H443, data...
  • Page 124 TPC-642 User’s Manual...

  • Page 125: Appendix B Installing Pc/104-Plus Modules

    Installing PC/104-Plus Modules This appendix gives instructions for installing PC/104- Plus modules. Appx. B...

  • Page 126: Installing Pc/104-Plus Modules

    The PCM-9575's PC/104 connectors give you the flexibility to attach PC/ 104+ modules. Installing these modules on the PCM-9575 is quick and simple. The fol- lowing steps show to mount the PC/104+ modules: Remove the PCM-9575 from your system, paying particular atten- tion to the safety instructions already mentioned above.

  • Page 127: Figure B.1: Pc/104+ Module Mounting Diagram

    Figure B.1: PC/104+ module mounting diagram Appx. B...

  • Page 128: Figure B.2: Pc/104+ Module Dimensions (Mm) (±0.1)

    Figure B.2: PC/104+ module dimensions (mm) (±0.1) TPC-642 User’s Manual...

  • Page 129: Appendix C Pin Assignments

    Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • CPU Fan Power Connector • Ethernet 10/100Base-T Connector • Audio Connector • CD Drive Connector • Main Power Connector • Keyboard and PS/2 Mouse Connector •...

  • Page 130: Cpu Fan Power Connector (Fan 1)

    Appendix C Pin Assignments C.1 CPU Fan Power Connector (FAN 1) Table C.1: IR connector (FAN 1) Signal Fan speed signal input C.2 Ethernet 10/100Base-T Connector (CN12) Table C.2: Ethernet 10/100Base-T connector (CN12) Signal CRS LED RCV+ RCV- BNC LED XMT+ XMT- PCA-6183 User’s Manual...

  • Page 131: Audio Connector (Cn4)

    C.3 Audio Connector (CN4) Table C.3: Audio connector (CN4) Signal Signal SPEAKER OUT R+ SPEAKER OUT R- SPEAKER OUT L+ SPEAKER OUT L- LINE OUT R LINE OUT L LINE IN R LINE IN L MIC IN C.4 Audio In Connector (CN2) Table C.4: Audio line-in connector (CN2) Signal CD Audio R...

  • Page 132: Main Power Connector (Cn5)

    C.5 Main Power Connector (CN5) Table C.5: Main Power Connector (CN5) Signal +5 V +12 V N.C. +5 V PCA-6183 User’s Manual...

  • Page 133: Keyboard And Ps/2 Mouse Connector (Cn25)

    C.6 Keyboard and PS/2 Mouse Connector (CN25) Table C.6: Keyboard and mouse connector (CN25) Signal KB CLOCK KB DATA MS CLOCK +5V (KB VCC) MS DATA Appx. C...

  • Page 134: Floppy Disk Drive Connector (Cn18)

    C.7 Floppy Disk Drive Connector (CN18) Table C.7: Floppy Disk Drive Connector (CN18) Signal Signal DENSITY SELECT* DRIVE TYPE INDEX* MOTOR O* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE*...

  • Page 135: Pc/104 Plus Connectors (Cn17)

    C.8 PC/104 plus Connectors (CN17) Table C.8: PC/104+ connectors (CN17) Number Row A Row B Row C Row D IOCHCHK* RESET SBHE* MEMCS16* +5 V LA23 IOCS16* IRQ9 LA22 IRQ10 LA21 IRQ11 DRQ2 LA20 IRQ12 -12V LA19 IRQ15 ENDXFR* LA18 IRQ14 +12V LA17...
  • Page 136 Table C.8: PC/104+ connectors (CN17) Number Row A Row B Row C Row D IRQ5 ---- ---- IRQ4 ---- ---- IRQ3 ---- ---- DACK2* ---- ---- ---- ---- BALE ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- * low active PCA-6183 User’s Manual...

  • Page 137: Ide Hard Drive Connector (Cn14, Cn16)

    C.9 IDE Hard Drive Connector (CN14, CN16) Table C.9: IDE HDD connector (CN14, CN16) Signal Signal IDE RESET* DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14...

  • Page 138: Parallel Port Connector (Cn15)

    C.10 Parallel Port Connector (CN15) Table C.10: Parallel Port Connector (CN15) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active PCA-6183 User’s Manual...

  • Page 139: Power & Hdd Led Connector(Cn13)

    C.11 Power & HDD LED Connector(CN13) Table C.11: Power & HDD LED Connector (CN13) Signal power LED+ (+5V) HDD LED + power LED - (GND) HDD LED - C.12 Reset Button Connector (CN22) Table C.12: Reset Button Connector (CN22) Signal Reset signal input Appx.

  • Page 140: Usb Connector (Cn20, Cn28)

    C.13 USB Connector (CN20, CN28) Table C.13: USB Connector (CN20, CN28) Signal Signal +5 V +5 V Chassis GND C.14 LCD Inverter Backlight Connector (CN6) Table C.14: LCD Inverter Backlight Connector (CN6) Signal +12 V ENABKL +5 V PCA-6183 User’s Manual...

  • Page 141: Ir Connector (Cn24)

    C.15 IR Connector (CN24) Table C.15: IR Connector (CN24) Signal VCC (5 V) N.C. IR receive IR transmit C.16 CRT Display Connector (CN8) Table C.16: CRT Display Connector (CN8) Signal Signal VGA G +5 V H-sync signal GREEN VGA G VGA G V-sync signal BLUE...

  • Page 142: Tv (Video) Out Connector (Cn1)

    C.17 TV (video) Out Connector (CN1) Table C.17: TV (video) Out Connector (CN1) Signal Luminance out (S-Video Y output, brightness) Chrominance out (S-Video C output, color) Composite video out PCA-6183 User’s Manual...

  • Page 143: Flat Panel Connector (Cn11)

    C.18 Flat Panel Connector (CN11) Table C.18: Flat Panel Connector (CN11) Signal Signal VDDSAFE5 (+5v output) VDDSAFE5 (+5v output) VDDSAFE3 (+3.3 v VDDSAFE3 (+3.3 v output) output) SHFCLK M/DE ENAVEE Note: The model number of the CN11 socket is DF13A-40DP-1.25V (Hirose Electric Co., Ltd.) Appx.

  • Page 144: Extended Flat Panel Display Connector (Cn10)

    C.19 Extended Flat Panel Display Connector (CN10) Table C.19: Extended Flat Panel Display Connector (CN10) Signal Signal Note: The model number of the CN10 socket is DF13A-20DP-1.25V (Hirose Electric Co., Ltd.) PCA-6183 User’s Manual...

  • Page 145: Lcd Signal Mapping

    C.20 LCD Signal Mapping Table C.20: LCD Signal Mapping 16-bit 24-bit 18-bit 24-bit 36-bit Name DSTN DSTN PD10 PD11 PD12 PD13 PD14 PD15 PD16 PD17 PD18 PD19 PD20 PD21 PD22 PD23 PD24 PD25 PD26 PD27 PD28 PD29 PD30 PD31 PD32 PD33 PD34 PD35...

  • Page 146: Lvds Connector (Cn9)

    C.21 LVDS Connector (CN9) Table C.21: LVDS Connector (CN9) Signal Signal TX0+(Channel 1) TX0+(Channel 2) TX0-(Channel 1) TX0-(Channel 2) TX1+(Channel 1) TX1+(Channel 2) TX1-(Channel 1) TX1-(Channel 2) TX2+(Channel 1) TX2+(Channel 2) TX2-(Channel 1) TX2-(Channel 2) TX3+(Channel 1) TX3+(Channel 2) TX3-(Channel 1) TX3-(Channel 2) VDD (+3.3V) VDD (+3.3V)

  • Page 147: Com Port Connector (Cn19)

    C.23 COM Port Connector (CN19) Table C.23: COM Port Connector (CN19) Signal Signal RLSD1 (DCD1) DSR1 RTS1 CTS1 DTR1 RLSD2 (DCD2) DSR2 RTS2 CTS2 DTR2 RLSD3 (DCD3) DSR3 RTS3 CTS3 DTR3 RLSD4 (DCD4) DSR4 RTS4 CTS4 DTR4 Appx. C...

  • Page 148: Compactflash Card Connector (Cn26)

    C.24 CompactFlash Card Connector (CN26) Table C.24: CompactFlash Card Connector (CN26) Signal Signal *CS0 *ATA SEL +5 V -IOCS16 *CD2 -CD1 -CS1 *VS1 -IORD *IOWR INTRQ +5 V *CSEL -VS2 *RESER IORDY *INPACK -REG *DASP -PDIAG * low active PCA-6183 User’s Manual...

  • Page 149: Atx Power Feature Connector (Cn3)

    C.25 ATX Power Feature Connector (CN3) Table C.25: ATX Power Feature Connector (CN3) Signal 5VSB (Stand by voltage) PS. ON# Appx. C...
  • Page 150 PCA-6183 User’s Manual...

  • Page 151: Appendix D System Assignments

    System Assignments This appendix contains information of a detailed nature. It includes: • System I/O ports • 1st MB memory map • DMA channel assignments • Interrupt assignments Appx. D...

  • Page 152: System I/O Ports

    Appendix D System Assignments D.1 System I/O Ports Table D.1: System I/O ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, master 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 080-09F DMA page register 0A0-0BF Interrupt controller 2...

  • Page 153: 1St Mb Memory Map

    D.2 1st MB memory map Table D.2: 1st MB memory map Addr. range (Hex) Device F0000h - FFFFFh System ROM *CC000h - EFFFFh Unused (reserved for Ethernet ROM) C0000h - CBFFFh Expansion ROM (for VGA BIOS) B8000h - BFFFFh CGA/EGA/VGA text B0000h - B7FFFh Unused A0000h - AFFFFh...

  • Page 154: Interrupt Assignments

    D.4 Interrupt assignments Table D.4: Interrupt assignments Interrupt# Interrupt source IRQ 0 Interval timer IRQ 1 Keyboard IRQ 2 Interrupt from controller 2 (cascade) IRQ 3 COM2 IRQ 4 COM1 IRQ 5 COM4 IRQ 6 IRQ 7 LPT1 IRQ 8 IRQ 9 Reserved (audio) IRQ 10...

  • Page 155: Appendix E Optional Extras For The Pcm-9575

    Optional Extras for the PCM-9575 Appx. E...

  • Page 156: Pcm-10586-5A00 Cable Kit For Pcm-9575

    E.1 PCM-10586-5A00 cable kit for PCM-9575 The PCM-9575 requires several cables for normal operation. You can make them yourself or purchase an optional cable kit assembly, which includes the following: PCM-10586-5V00 cable kit for PCM-9575 PCM- Cable Part No. 9575...

  • Page 157: Optional Lcd Cables 10.4" Tft Lcd Panel (Cn14)

    1703440151 Wire 30P/44P 15 cm Toshiba LTM12C275A Note: The above LCD cables have links via 24-bit LCD cable adaptor (E.6) to connect to PCM-9575 E.3 Optional USB cable (CN20) Optional USB cable (2-channel) Part no: 1703100261 Optional USB Cable for MBPC-300 Part no.
  • Page 158 PCM-9575 User’s Manual...

  • Page 159: Appendix F Mechanical Drawings

    Mechanical Drawings Appx. F...

  • Page 160: Mechanical Drawings

    F.1 Mechanical Drawings Figure F.1: PCM-9575 Mechanical Drawing (Side view for PCM-9575F-Q0A1 (w/ fan) and PCM-9575F-M0A1(w/o fan) only) PCM-9575 User’s Manual...
  • Page 161 Figure F.2: PCM-9575 Mechanical Drawing (component side) Appx. F...
  • Page 162 Figure F.3: PCM-9575 Mechanical Drawing (solder side) PCM-9575 User’s Manual...

Table of Contents
