PCE-5120
PICMG 1.3 Full-sized Intel® LGA775 processor
Card with PCI Express / IPMI / VGA /Dual Gigabit
LAN

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCE-5120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech PCE-5120

Summary of Contents for Advantech PCE-5120

  • Page 1: User Manual

    PCE-5120 PICMG 1.3 Full-sized Intel® LGA775 processor Card with PCI Express / IPMI / VGA /Dual Gigabit User Manual...
  • Page 2 Copyright This document is copyrighted, 2007, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improve- ments to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmit- ted in any form or by any means without the prior written permission of Advantech Co., Ltd.
  • Page 3 A Message to the Customer Advantech Customer Services Each and every Advantech product is built to the most exacting specifica- tions to ensure reliable performance in the harsh and demanding condi- tions typical of industrial environments. Whether your new Advantech...
  • Page 4 Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the manufac- turer. Discard used batteries according to the manufacturer’s instructions. PCE-5120 User Manual...

  • Page 5: Type Memory

    Memory Compatibility Brand Size Apacer 512MB Transcend 256MB 512MB 512MB Apacer 512MB (RoHS) 512MB Transcend 256MB (RoHS) 512MB 512MB 512MB 512MB Speed Type DDR2 533 DDR2 DDR2 400 DDR2 DDR2 400 DDR2 DDR2 533 DDR2 DDR2 533 DDR2 DDR2 533 DDR2 DDR2 533 DDR2...
  • Page 6 PCE-5120-00A2E (Conroe/Conroe-L) Intel Core™ 2 Duo Desktop Processor (E6000/E4000) Intel Pentium® Dual-Core Desktop Proces- sor (E2000) Intel Celeron® Processor 400 PCE-5120-00A1E (Prescott / Cedar Mill) Intel Pentium D Processor Intel Pentium 4 Processor Intel Celeron D Processor PCE-5120 User Manual PCE-5120F...

  • Page 7: Product Warranty

    Advantech assumes no liability under the terms of this warranty as a consequence of such events. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.

  • Page 8: Initial Inspection

    5120 mechanically and electrically before shipment. It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the PCE-5120, check it for signs of shipping damage. (For exam- ple, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales repre- sentative immediately.

  • Page 9: Table Of Contents

    Table 1.1: Jumpers ... 6 Table 1.2: Connectors ... 6 Figure 1.1: Jumper and Connector locations ... 8 Figure 1.2: PCE-5120 Block Diagram ... 9 How to set jumpers ... 11 CMOS clear (CMOS1) ... 11 Table 1.3: CMOS (CMOS1) ... 11 Watchdog timer output (JWDT1) ...
  • Page 10 3.4.4 3.4.5 3.4.6 3.4.7 3.4.8 PCE-5120 User Manual PWR_LED&KEY LOCK) ... 24 Table 2.1: ATX power supply LED status (No support for AT power) ... 25 Table 2.2: Hardware Monitor Alarm setting ... 25 CMOS RAM Auto-backup and Restore ... 30 Figure 3.1: Award BIOS Setup initial screen ...
  • Page 11 3.4.9 Swap Floppy Drive ... 34 3.4.10 Boot Up Floppy Seek... 34 3.4.11 Boot Up NumLock Status... 34 3.4.12 Gate A20 Option... 34 3.4.13 Typematic Rate Setting... 35 3.4.14 Typematic Rate (Chars/Sec) ... 35 3.4.15 Typematic Delay (msec)... 35 3.4.16 Security Option ... 35 3.4.17 APIC Mode ...
  • Page 12 3.8.1 3.8.2 3.8.3 3.8.4 PC Health Status... 48 3.9.1 PCE-5120 User Manual Figure 3.8: Super I/O Device... 42 Figure 3.9: Power management setup screen (1)... 44 PCI express PM Function ... 44 Power Supply Type... 44 ACPI Function ... 44 Power Management ...
  • Page 13 3.9.2 3.9.3 3.9.4 3.9.5 3.9.6 3.9.7 3.9.8 3.10 Frequency / Voltage Control ... 49 3.10.1 CPU Clock Ratio ... 49 3.10.2 Spread Spectrum ... 49 3.11 Load Setup Defaults ... 50 3.12 Save & Exit Setup ... 50 3.13 Exit Without Saving ... 50 Chapter 4 Chipset Software Install Utility...52 Before you begin ...
  • Page 14 B.13 ATX Soft Power Switch (JFP1 / PWR_SW) ... 100 B.14 AC'97 Link connector (AC97) ... 101 PCE-5120 User Manual Watchdog timer overview... 82 Jumper selection ... 82 Programming the Watchdog Timer ... 82 Table A.1: Watchdog timer registers ... 84 Example Program ...
  • Page 15 B.15 SM Bus Connector (JFP2 / SNMP)... 101 Table B.15: SM bus connector (JFP2 / SNMP) ... 101 B.16 LAN1 and LAN2 LED connector (LANLED1) ... 102 Table B.16: LAN1 and LAN2 LED connector B.17 System I/O Ports... 103 Table B.17: System I/O ports... 103 B.18 DMA Channel Assignments...
  • Page 16 PCE-5120 User Manual...
  • Page 17 Hardware Configuration Chapter 1...

  • Page 18: Chapter 1 Hardware Configuration

    Chapter 1 Hardware Configuration 1.1 Introduction The PCE-5120 is designed with the Intel® 945G chipset and ICH7R (I/O controller) to support Core™ 2 Duo, Dual-Core Pentium® D / Pentium® 4 / Celeron® D processors (refer to “Processor Support” on page vi) with a 533/800/1066 MHz front side bus and DDR2 533/667 MHz memory up to 4 GB.

  • Page 19: Features

    The PCE-5120 retains a legacy PCI 32-bit /33 MHz bus from the CPU board to the Backplane. It does not require a PCI-Express to PCI bridge chip to lower the system cost. It is good for the application and only needs a few legacy PCI Buses.

  • Page 20: Specifications

    PIO mode 4 (16.67MB/s data transfer rate) and ATA 33/66/100 (33/66/ 100MB/s data transfer rate.) BIOS enabled/disabled. • CF Socket: PCE-5120 offer a alternative type II CF socket of IDE port. Note: CF socket and IDE port can't work at the same time •...

  • Page 21: Input/Output

    1.3.3 Input/Output • PCI Express links: 1 PCI-E x 16 Link and 4 PCIe x1 Link to the PICMG 1.3 backplane. • PCI Bus: 32bit / 33MHz to the backplane • Enhanced parallel port: Configured to LPT1, LPT2, LPT3, or dis- abled.

  • Page 22: Table 1.2: Connectors

    • Board weight: 0.5 kg (1.2 lb) 1.4 Jumpers and Connectors Connectors on the PCE-5120 single board computer link it to external devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure your system for your application.
  • Page 23 Table 1.2: Connectors Label Function JOBS1 HW Monitor Alarm Close: Enable OBS Alarm Open: Disable OBS Alarm LAN1 Giga LAN RJ45 connector LAN2 Giga LAN RJ45 connector AC97 AC'97 Link connector SATA1 Serial ATA1 SATA2 Serial ATA2 SATA3 Serial ATA3 SATA4 Serial ATA4 LANLED1...

  • Page 24: Figure 1.1: Jumper And Connector Locations

    1.5 Board Layout: Jumper and Connector Locations Figure 1.1: Jumper and Connector locations PCE-5120 User Manual SATA3 SATA1 SATA4 SATA2...

  • Page 25: Figure 1.2: Pce-5120 Block Diagram

    (Connector A & B ) 1 ATA 100 port 4 SATA II 300MB/s ports Connector C 4 USB Ports Audio Codec AC’97 Figure 1.2: PCE-5120 Block Diagram LGA775 Processor 945G GMCH ICH7R LPC Bus Super IO IPMI BIOS Winbond W83627HF...

  • Page 26: Safety Precautions

    Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the manufac- turer. Discard used batteries according to the manufacturer’s instructions. PCE-5120 User Manual...

  • Page 27: Table 1.3: Cmos (Cmos1)

    1.8.1 How to set jumpers You can configure your PCE-5120 to match the needs of your applica- tion by setting the jumpers. A jumper is a metal bridge that closes an elec- trical circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 28: Table 1.4: Watchdog Timer Output (Jwdt1)

    1.8.3 Watchdog timer output (JWDT1) The PCE-5120 contains a watchdog timer that will reset the CPU in the event the CPU stops processing. This feature means the PCE-5120 will recover from a software failure or an EMI problem. The JWDT1 jumper settings control the outcome of what the computer will do in the event the watchdog timer is tripped.

  • Page 29: System Memory

    1.11 Cache Memory The CPU that PCE-5120 supports built-in 4 MB (for Core™ 2 Duo), 2 x 1024KB/2 x 2048KB cache memory (for Pentium D CPU), and 1024KB/ 2048KB (for Pentium 4 CPU), and 256KB/512 KB (For Celeron D CPU) full-speed L2 cache.

  • Page 30: Processor Installation

    1.12 Processor Installation The PCE-5120 is designed for Intel® LGA 775 socket CPUs. Step 1: Pull the bar besides the CPU socket outward and lift it. Step 2: Align the triangular marking on the processor with the cut edge of the socket.
  • Page 31 Step 3: Put back the socket cap and press down the bar to fix it. Chapter 1...

  • Page 32: Cpu Cooler Installation

    1.13 CPU Cooler Installation Please ensure that the CPU cooler included with the PCE-5120 is installed as follows:...
  • Page 33 Connecting Peripherals Chapter 2...

  • Page 34: Chapter 2 Connecting Peripherals

    Check the documentation that came with the drive for more information. PCE-5120 offers an alternative type II CF socket of IDE port. The CF socket and IDE port can't work at the same time. It will cause the data conflict.

  • Page 35: Floppy Drive Connector (Fdd1)

    JFP1 JFP2 JFP3 You can attach up to two floppy disk drives to the PCE-5120's on board controller. You can use 3.5" (720 KB, 1.44 MB) drives. The single board computer comes with a 34-pin daisy-chain drive con- nector cable. On one end of the cable is a 34-pin flat-cable connector. On the other end are two sets of 34-pin flat-cable connector (usually used for 3.5"...

  • Page 36: Parallel Port (Lpt1)

    JFP3 The parallel port is normally used to connect the single board computer to a printer. The PCE-5120 includes an onboard parallel port, accessed through a 26-pin flat-cable connector, LPT1. The card comes with an adapter cable which lets you use a traditional DB-25 connector. The cable has a 26-pin connector on one end and a DB-25 connector on the other, mounted on a retaining bracket.

  • Page 37: Vga Connector (Vga1)

    2.5 VGA Connector (VGA1) The PCE-5120 includes a VGA interface that can drive conventional CRT displays. VGA1 is a standard 15-pin D-SUB connector commonly used for VGA. Pin assignments for CRT connector VGA1 are detailed in Appendix B. JFP1 JFP2 JFP3 2.6 Serial Ports (COM1, COM2, COM3, COM4)

  • Page 38: Ps/2 Keyboard And Mouse Connector (Kbms1)

    2.8 External Keyboard & Mouse (KBMS2) JFP1 JFP2 JFP3 In addition to the PS/2 mouse/keyboard connector on the PCE-5120's rear plate, there is also an extra onboard external keyboard and mouse connector. This gives system integrators greater flexibility in designing their systems. PCE-5120 User Manual...

  • Page 39: Cpu Fan Connector (Cpfan1)

    If a fan is used, this connector supports cooling fans of 12V/1A (12W) or less. 2.10 Front Panel Connectors (JFP1, JFP2, JFP3) JFP1 PWR_SW RESET JFP2 HDDLED SNMP SPEAKER JFP3 PWR_LED&KEY LOCK JFP1 JFP2 JFP3 There are several external switches to monitor and control the PCE-5120. LPT1 LPT1 Chapter 2...

  • Page 40: Atx Soft Power Switch (Jfp1 / Pwr_Sw)

    2.10.5External speaker (JFP2 / SPEAKER) (JFP2 / SPEAKER) is a 4-pin connector for an external speaker. If there is no external speaker, the PCE-5120 provides an onboard buzzer as an alternative. To enable the buzzer, set pins 3-4 as closed.

  • Page 41: Table 2.1: Atx Power Supply Led Status (No Support For At Power)

    Table 2.1: ATX power supply LED status (No support for AT power) Power mode PSON1(On Back plane) Jumper setting System On System Sus- pend System Off 2.11 H/W Monitor Alarm (JOBS1) JFP1 JFP2 JFP3 (JOBS1) is a 2-pin connector for setting enable/disable alarm while the On Board security event acts.

  • Page 42: Gigabit Lan Rj45 Connector (Lan1, Lan2)

    JFP1 JFP2 JFP3 PCE-5120 uses the Intel 82573V Gigabit LAN chip which is linked to PCIe x1 Link. With this chip PCE-5120 may provide high throughputs for heavy loading networking environment. It provides two or one RJ-45 connectors in the rear side and is convenient for most industrial applica- tions.

  • Page 43: Serial Ata2 Interface

    JFP2 JFP3 In addition to the EIDE interfaces (up to two devices), the PCE-5120 fea- tures a high performance serial ATA2 interface (up to 300MB/s) which eases cabling to hard drives with thin and long cables. These four port can be configured as RAID 0, 1, 5, 10 applications.

  • Page 44: Bmc Connector (Bmc1)

    2.16 BMC connector (BMC1) JFP1 JFP2 JFP3 PCE-5120 is designed for supporting IPMI 2.0. The BMC module is mounted on board through this connector. For more detail operating information, please refer to Chapter 9. 2.17 USB (USB12, USB34) JFP1 JFP2 JFP3 The PCE-5120 provides four on board USB 2.0 ports which support...
  • Page 45 Award BIOS Setup Chapter 3...

  • Page 46: Chapter 3 Award Bios Setup

    “CMOS checksum error...” display screen mes- sage appearing. Then enter the “Setup” screen to modify the data. If the “CMOS checksum error...” message appears again and again, please check to see if you need to replace the battery in your system. PCE-5120 User Manual...

  • Page 47: Figure 3.1: Award Bios Setup Initial Screen

    3.2 Entering Setup Turn on the computer and press <Del> to enter the BIOS setup. Figure 3.1: Award BIOS Setup initial screen 3.3 Standard CMOS Setup 3.3.1 Date The date format is <week>, <month>, <day>, <year>. 3.3.2 Time The time format is <hour> <minute> <second>, based on the 24-hour clock.

  • Page 48: Figure 3.2: Standard Cmos Features Screen

    The options are: No Errors/All Errors/All, But Keyboard/All, But Dis- kette/All, But Disk/Key 3.3.6 Memory This category displays base memory, extended memory, and total mem- ory detected during POST (Power On Self Test). Figure 3.2: Standard CMOS Features Screen PCE-5120 User Manual...

  • Page 49: Figure 3.3: Advanced Bios Features Screen

    The “Advanced BIOS Features” screen appears when choosing the “Advanced BIOS Features” item from the “Initial Setup Screen” menu. It allows the user to configure the PCE-5120 according to his particular requirements. Below are some major items that are provided in the Advanced BIOS Features screen.

  • Page 50: Hard Disk Boot Priority

    3.4.11 Boot Up NumLock Status Sets the boot up status Num Lock. The options are “On” and “Off”. 3.4.12 Gate A20 Option “Normal”: A pin in the keyboard controller controls GateA20. Fast (Default) lets chipset control GateA20. PCE-5120 User Manual...

  • Page 51: Typematic Rate Setting

    3.4.13 Typematic Rate Setting The typematic rate is the rate key strokes repeat as determined by the key- board controller. The commands are “Enabled” or “Disabled”. Enabling allows the typematic rate and delay to be selected. 3.4.14 Typematic Rate (Chars/Sec) The BIOS accepts the following input values (characters/second) for typematic rate: 6, 8, 10, 12, 15, 20, 24, and 30.

  • Page 52: Figure 3.4: Advanced Chipset Features Screen

    By choosing the “Advanced Chipset Features” option from the “Initial Setup Screen” menu, the screen below will be displayed. This sample screen contains the manufacturer’s default values for the PCE-5120, as shown in Figure 3-4: Figure 3.4: Advanced chipset features screen...

  • Page 53: Dram Ras# To Cas# Delay

    3.5.3 DRAM RAS# to CAS# Delay When DRAM Timing selectable is set to [Manual], this field is adjust- able. When DRAM is refreshed, the rows and columns are addressed sep- arately. This setup item allows user to determine the timing of the transition from RAS (row address strobe) to CAS (column address strobe).

  • Page 54: Pci-Express Root Port Func

    3.5.16 DVMT / FIXED Memory Size Specify the size of DVMT / FIXED system memory to allocate for video memory. 3.5.17 Init Display First Choose the first display interface to initiate while booting. The choice is “PCI Slot” or “Onboard”. PCE-5120 User Manual...

  • Page 55: Figure 3.5: Integrated Peripherals

    3.6 Integrated Peripherals Figure 3.5: Integrated peripherals Figure 3.6: On-Chip IDE Device 3.6.1 IDE HDD Block Mode If your IDE hard drive supports block mode select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support.

  • Page 56: On-Chip Primary / Secondary Ide Device

    If PATA IDE Mode is set to “Primary”, it will display “P1, P3 Secondary” which means that SATA1 and SATA3 are secondary. If PATA IDE Mode is set to “Secondary,” it will display “P0, P2 Second- ary” which means that SATA0 and SATA2 are secondary. PCE-5120 User Manual...

  • Page 57: Figure 3.7: Onboard Device

    Figure 3.7: Onboard Device 3.6.8 USB Controller Select Enabled if your system contains a Universal Serial Bus (USB) con- troller and you have USB peripherals. The choices are “Enabled” and “Disabled”. 3.6.9 USB 2.0 Controller This entry is to disable/enable the USB 2.0 controller only. The BIOS itself may/may not have high-speed USB support.

  • Page 58: Figure 3.8: Super I/O Device

    This item allows you to determine the active level of the RxD and TxD serial lines. The Choices: “Hi, Hi”, “Lo, Lo”, “Lo, Hi”, and “Hi, Lo”. 3.6.19 IR Transmission Delay This item allows you to enable/disable IR transmission delay. The choices are “Enabled” and “Disabled”. PCE-5120 User Manual...

  • Page 59: Ur2 Duplex Mode

    3.6.20 UR2 Duplex Mode This item allows you to select the IR half/full duplex function. The choices are “Half” and “Full”. 3.6.21 Use IR Pins The choices are “RxD2, TxD2” and “IR-Rx2Tx2”. 3.6.22 Onboard Parallel Port This field sets the address of the on-board parallel port connector. You can select “378/IRQ7”, “278/IRQ5”, “3BC/IRQ7”, or “Disabled”.

  • Page 60: Figure 3.9: Power Management Setup Screen (1)

    This is to setup PCI Express's PME function “Enable” or “Disable”. 3.7.2 Power Supply Type PCE-5120 can support both “ATX” and “AT” power supplies. Customers can choose the PSU type through this selection. The choices are “ATX” and “AT”. Selecting “AT” disables the ACPI function automatically.

  • Page 61: Table 3.1: Power Saving

    3.7.4 Power Management This category allows you to select the type (or degree) of power saving and is directly related to the following modes: • HDD Power Down • Suspend Mode There are three selections for Power Management, and they have fixed mode settings.

  • Page 62: Soft-Off By Pwr-Bttn

    Use this to set up the system after power failure. The “Off” setting keeps the system powered off after power failure, the “On” setting boots up the system after failure, and the “Former-Sts” returns the system to the status before power failure. PCE-5120 User Manual...

  • Page 63: Figure 3.10:Pnp/Pci Configurations Screen

    3.8 PnP/PCI Configurations Figure 3.10: PnP/PCI configurations screen 3.8.1 Reset Configuration Data The default is Disabled. Select Enabled to reset Extended System Config- uration Data (ESCD) if you have installed a new add-on card, and system configuration is in such a state that the OS cannot boot. 3.8.2 Resources Controlled By The commands here are “Auto (ESCD)”...

  • Page 64: Figure 3.11:Pc Health Status Screen

    This shows the voltage of VCORE, +1.5V, +3.3, +5V, +12V, -12V, -5V, VBAT(V), and 5VSB(V). 3.9.8 Shutdown Temperature The system will shut down automatically when the CPU temperature is over the selected setting. This function can prevent CPU damage caused by overheating. PCE-5120 User Manual...

  • Page 65: Figure 3.12:Spread Spectrum Control Screen

    3.10 Frequency / Voltage Control Figure 3.12: Spread Spectrum Control screen 3.10.1 CPU Clock Ratio Type a DEC number to set up the CPU Clock Ratio (Min=14; Max=17). This item only shows up in special situations. 3.10.2 Spread Spectrum This setting allows you to reduce EMI by modulating the signals the CPU generates so that the spikes are reduced to flatter curves.

  • Page 66: Figure 3.13: Load Setup Defaults Screen

    This record is required for the sys- tem to operate. 3.13 Exit Without Saving Selecting this option and pressing <Enter> lets you exit the setup program without recording any new values or changing old ones. PCE-5120 User Manual...

  • Page 67: Chipset Software Installation Utility

    Chipset Software Installation Utility Chapter 4...

  • Page 68: Chapter 4 Chipset Software Install Utility

    To facilitate the installation of the enhanced display drivers and utility software, read the instructions in this chapter carefully. The drivers for the PCE-5120 are located on the software installation CD. The auto-run function of the driver CD will guide and link you to the utilities and driv- ers under a Windows system.

  • Page 69: Windows Xp Driver Setup

    • IDE/ATA33/ATA66/ATA100 Storage Support • SATA Storage Support • USB Support • Identification of Intel (R) Chipset Components in the Device Manager Note: This utility is used for the following versions of Windows system, and it has to be installed before installing all the other drivers: •...
  • Page 70 Click “Next” when you see the following message. Click “Yes” when you see the following message. PCE-5120 User Manual...
  • Page 71 Click “Next” when you see the following message. When the following message appears, click “Finish” to complete the installation and restart Windows. Chapter 4...
  • Page 73 VGA Setup Chapter 5...

  • Page 74: Chapter 5 Vga Setup

    Insert the driver CD into your system's CD-ROM drive. In a few seconds, the software installation main menu appears, as shown in the following figure. The following installation procedure is for Windows XP. For other oper- ating systems, please do a manual installation. PCE-5120 User Manual...
  • Page 75 Click “Next” to continue the installation. You will see a welcome window. Please click “Yes” to continue the installation. Chapter 5...
  • Page 76 Click “Finish” to complete the installation and restart the computer now or later. PCE-5120 User Manual...
  • Page 77 Onboard Security Setup Chapter 6...

  • Page 78: Chapter 6 Onboard Security Setup

    Chapter 6 Onboard Security Setup 6.1 Introduction The PCE-5120's hardware monitor is based on the Winbond W83627HF chip. Onboard security (OBS) functions monitor key hardware to help you maintain system stability and durability. The PCE-5120 can monitor five sets of positive system voltages, two sets of system negative volt- ages, CPU cooling fan speed, and CPU temperature.
  • Page 79 Click “Next” when you see the following message. Click “Next” when you see the following message. Chapter 6...
  • Page 80 Click “Next” when you see the following message. Click “Next” to continue. PCE-5120 User Manual...

  • Page 81: Using The Obs Hardware Doctor Utility

    Click “Finish” when you see the following message. 6.3 Using the OBS Hardware Doctor Utility After completing the setup, all the OBS functions are permanently enabled. When a monitored reading exceeds safe limits, a warning mes- sage will be displayed and an error beep will sound to attract your atten- tion.
  • Page 82 PCE-5120 User Manual...
  • Page 83 LAN Configuration Chapter 7...

  • Page 84: Chapter 7 Lan Configuration

    Chapter 7 LAN Configuration 7.1 Introduction The PCE-5120 has a single/dual Gigabit Ethernet LAN via dedicated PCI Express x 1 bus (Intel® 82573), which offers bandwidth of up to 500 MB/sec, eliminating the bottleneck of network data flow and incorporat- ing Gigabit Ethernet to operate at 1000 Mbps.

  • Page 85: Win Xp Driver Setup (Intel 82573)

    7.4 Win XP Driver Setup (Intel 82573) Insert the driver CD into your system's CD-ROM drive. In a few seconds, the software installation main menu appears, as shown in the following figure. Under the “LAN Drivers” heading, click on the “Manual” to open file manager, then click “SETUP.EXE” to run the installation procedure.
  • Page 86 Click “Install Software” to start the installation procedure. PCE-5120 User Manual...
  • Page 87 The driver will be installed automatically and the LAN function will be enabled after the installation. Chapter 7...
  • Page 89 SATA RAID Setup Chapter 8...

  • Page 90: Chapter 8 Sata Raid Setup

    The driver is put in the CD's path: \\Drv_RAID\ICH7R\Driver\32bit for 32bits Windows OS and path: \\ Drv_RAID\ICH7R\Driver\64bitXP for 64bits Windows OS. You may go to the directory of the CD and follow Intel's installation guide for install the driver and Utility. PCE-5120 User Manual...
  • Page 91 IPMI Chapter 9...

  • Page 92: Table 9.1: Supported Ipmi Commands

    Get Device Id Cold Reset Get Self Test Results Manufacturing Test On Set ACPI Power State Get ACPI Power State Get Device GUID BMC Device and Messaging Commands PCE-5120 User Manual NetFn Mandatory / Optional 0x01 0x02 0x04 0x05 0x06...
  • Page 93 Set BMC Global Enables Get BMC Global Enables Clear Message Flags Get Message Flags Enable Message Channel Receive Get Message Send Message Read Event Message Buffer Get System GUID Get Channel Authentication Capabilities Get Session Challenge Activate Session Set Session Privilege Level Close Session Get Session Information Get AuthCode...
  • Page 94 Get SDR Repository Info Reserve SDR Repository Get SDR Get SDR Repository Time Set SDR Repository Time Run Initialization Agent FRU Device Commands Get FRU Inventory Area Info PCE-5120 User Manual Chassis 0x09 Chassis 0x0a Chassis 0x0b NetFn Mandatory /...
  • Page 95 Read FRU Inventory Data Write FRU Inventory Data Sensor Device Commands Set Sensor Hysteresis Get Sensor Hysteresis Set Sensor Threshold Get Sensor Threshold Set Sensor Event Enable Get Sensor Event Enable Re-arm Sensor Events Get Sensor Event Status Get Sensor Reading LAN Device Commands Set LAN Configuration Parame- ters...

  • Page 96: Ipmi Oem Command Lists

    Table 9.2: OEM Commands list Net Function = 0x2E, LUN = 0 Code Command Set System GUID Reset to Defaults PCE-5120 User Manual Request, Response Data Request: Byte 1:16 – System GUID Response: Byte 1 — Completion code. Request: Reset module ID...
  • Page 97 Programming the Watchdog Timer Appendix A...

  • Page 98: A.1.2 Jumper Selection

    Appendix A Watchdog Timer A.1 Programming the Watchdog Timer The PCE-5120's watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function within the programmed period. This section describes the operation of the watchdog timer and how to program it.
  • Page 99 Unlock W83627HF Select register of watchdog timer Enable the function of the watchdog timer Use the function of the watchdog timer Lock W83627HF Appendix A...

  • Page 100: Table A.1: Watchdog Timer Registers

    [default] Write 1 to bit 3: set minutes as count- ing unit F6 (hex) F7 (hex) AA (hex) PCE-5120 User Manual Attribute Value (2F) & description ----- Write this address to I/O address port 2E (hex) twice to unlock the...

  • Page 101: A.1.4 Example Program

    A.1.4 Example Program Enable watchdog timer and set 10 sec. as timeout interval ;----------------------------------------------------------- Mov dx,2eh ; Unlock W83627HF Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ;...
  • Page 102 Out dx,al Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx Mov al,0f5h Out dx,al PCE-5120 User Manual ; lock W83627HF ; unlock W83627HF ; Select registers of watchdog timer ; Enable the function of watchdog timer ; Set minute as counting unit...
  • Page 103 al,dx Or al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 5 minutes and start counting Mov al,0f6h Out dx,al Mov al,5 Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al Enable watchdog timer to be reset by mouse ;----------------------------------------------------------- Mov dx,2eh ;...
  • Page 104 Out dx,al ;----------------------------------------------------------- Dec dx Mov al,30h Out dx,al PCE-5120 User Manual ; Enable watchdog timer to be reset by mouse ; lock W83627HF ; unlock W83627HF ; Select registers of watchdog timer ; Enable the function of watchdog timer...
  • Page 105 Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable watchdog timer to be strobed reset by keyboard Mov al,0f7h Out dx,al al,dx Or al,40h Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al Generate a time-out signal without timer counting ;----------------------------------------------------------- Mov dx,2eh ;...
  • Page 106 Out dx,al ;----------------------------------------------------------- Dec dx Mov al,0f7h Out dx,al al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx Mov al,0aah Out dx,al PCE-5120 User Manual ; Generate a time-out signal ;Write 1 to bit 5 of F7 register ; lock W83627HF...
  • Page 107 I/O Pin Assignments Appendix B...

  • Page 108: Table B.1: Ide Hard Drive Connector (Ide1)

    IO READ IO CHANNEL READY HDACKO* IRQ14 ADDR 1 ADDR 0 HARD DISK SELECT 0* IDE ACTIVE* * low active PCE-5120 User Manual Signal DATA 8 DATA 9 DATA 10 DATA 11 DATA 12 DATA 13 DATA 14 DATA 15...

  • Page 109: Table B.2: Floppy Drive Connector (Fdd1)

    B.2 Floppy Drive Connector (FDD1) Table B.2: Floppy drive connector (FDD1) * low active Signal Signal FDHDIN* FDEDIN* INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* Appendix B...

  • Page 110: Table B.3: Parallel Port Connector (Lpt1)

    B.3 Parallel Port Connector (LPT1) Table B.3: Parallel port connector (LPT1) * low active PCE-5120 User Manual Signal STROBE* ACK* BUSY SLCT Signal AUTOFD* INIT* SLCTINI*...

  • Page 111: Table B.4: Vga Connector (Vga1)

    B.4 VGA Connector (VGA1) Table B.4: VGA connector (VGA1) Signal GREEN BLUE Signal H-SYNC V-SYNC Appendix B...

  • Page 112: Serial Port (Com1, Com2, Com3, Com4)

    B.5 RS-232 Serial Port (COM1, COM2, COM3, COM4) Table B.5: RS-232 serial port (COM1, COM2, COM3, COM4) PCE-5120 User Manual Signal...

  • Page 113: B.7 External Keyboard Connector (Kbms2)

    B.6 PS/2 Keyboard/Mouse Connector (KBMS1) Table B.6: PS/2 keyboard/mouse connector (KBMS1) B.7 External Keyboard Connector (KBMS2) Table B.7: External keyboard connector (KBMS2) Signal KB DATA MS DATA KB CLOCK MS CLOCK Signal KBCLK KBDAT MSDAT MSVCC MSCLK Appendix B...

  • Page 114: B.9 Power Led And Keyboard Lock Connector (Jfp3 Pwr_Led & Key Lock)

    Table B.8: CPU Fan Power Connector (CPUFAN1) B.9 Power LED and Keyboard Lock Connector (JFP3 / PWR_LED & KEY LOCK) Table B.9: Power LED and Keyboard Lock Connector (JFP3 / PWR_LED & KEY LOCK) PCE-5120 User Manual Signal +12V Detect FANPWM Signal...

  • Page 115: Table B.11: Reset Connector (Jfp1 / Reset)

    B.10 External Speaker Connector (JFP2 / SPEAKER) Table B.10:External Speaker Connector (JFP2 / SPEAKER) B.11 Reset Connector (JFP1 / RESET) Table B.11:Reset connector (JFP1 / RESET) Signal SPK+ SPK_IN SPK- Signal RESET # Appendix B...

  • Page 116: Table B.12: Hdd Led (Jfp2 / Hddled)

    B.12 HDD LED (JFP2 / HDDLED) Table B.12:HDD LED (JFP2 / HDDLED) B.13 ATX Soft Power Switch (JFP1 / PWR_SW) Table B.13:ATX soft power switch (JFP1 / PWR_SW) PCE-5120 User Manual Signal IDE LED+ IDE LED- Signal 5VSB PWR-BTN...

  • Page 117: Table B.15: Sm Bus Connector (Jfp2 / Snmp)

    B.14 AC'97 Link connector (AC97) Table B.14:AC'97 Link connector (AC97) B.15 SM Bus Connector (JFP2 / SNMP) Table B.15:SM bus connector (JFP2 / SNMP) Signal Sync SDOUT SDIN1 +12V Signal SMB_DATA SMB_CLK Signal BITCLK SDIN0 AC-RST Appendix B...

  • Page 118: Lan1 And Lan2 Led Connector (Lanled1)

    B.16 LAN1 and LAN2 LED connector (LANLED1) Table B.16:LAN1 and LAN2 LED connector (LANLED1) PCE-5120 User Manual Signal #LAN1_ACT V33_AUX #LAN1_LINK1000 #LAN1_LINK100 V33_AUX #LAN2_ACT V33_AUX #LAN2_LINK1000 #LAN2_LINK100...

  • Page 119: B.17 System I/O Ports

    B.17 System I/O Ports Table B.17:System I/O ports Addr. range (Hex) Device 000-01F 020-021 022-023 040-05F 060-06F 070-07F 080-09F 0A0-0BF 0C0-0DF 0F8-0FF 1F0-1F8 200-207 278-27F 290-297 2F8-2FF 300-31F 360-36F 378-37F 380-38F 3A0-3AF 3B0-3BF 3C0-3CF 3D0-3DF 3F0-3F7 3F8-3FF DMA controller Interrupt controller 1, master Chipset address 8254 timer 8042 (keyboard controller)

  • Page 120: Table B.18: Dma Channel Assignments

    B.18 DMA Channel Assignments Table B.18:DMA channel assignments Channel PCE-5120 User Manual Signal Available Available Floppy disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available...

  • Page 121: B.19 Interrupt Assignments

    B.19 Interrupt Assignments Table B.19:Interrupt assignments Priority Interrupt# IRQ0 IRQ1 IRQ2 IRQ8 IRQ9 IRQ10 IRQ11 IRQ12 IRQ13 IRQ14 IRQ15 IRQ3 IRQ4 IRQ5 IRQ6 IRQ7 B.20 1st MB Memory Map Table B.20:1st MB memory map Addr. range (Hex) E0000h - FFFFFh CC000h - DFFFFh C0000h - CBFFFh A0000h - BFFFFh...

  • Page 122: Table B.21: Pci Bus Map

    AD31 PCI slot 2 AD30 PCI slot 3 AD29 PCI slot 4 AD28 PCE-5120 User Manual INT# pin INT B,C GNT B INT D, A, B, C GNT A INT C, D, A, B GNT B INT B,C,D,A GNT C...

This manual is also suitable for:

Pce-5120fPce-5120g2Pce-5120vgPce-5120vg-00a2ePce-5120g2-00a2e

Table of Contents

Save PDF
