MAIN MENU
PICTURE QUALITY
AUDIO
SCREEN
FUNCTION
OPTIONS
SETUP
AUTOTUNING SETUP
SEL.
OK
This is the main menu with the PICTURE QUALITY option
highlighted. Press OK to bring up the highlighted menu.

The Picture Quality Menu

Setting the Picture Mode with the PRESETS Option
The monitor has preset viewing modes that can be selected depending on your viewing environment. Each
preset mode has the contrast, brightness and sharpness adjusted for a specific viewing situation.
• MEMORY – This mode allows you to set and save your own picture adjustments.
• SOFT – Use this mode when watching your Monitor in a dark room. Soft mode provides a darker, finer
picture, like the screen in movie theaters. These settings are preset for you and can't be changed.
• BRIGHT – Use this mode when watching your monitor in a bright room. This mode provides a picture
with distinct differences between light and dark areas. These settings are preset for you and can't be
changed.
• NORMAL – The factory default.
To change the picture mode:
1. From the main menu, select PICTURE QUALITY. The PICTURE QUALITY Menu will appear.
2. Highlight the PRESETS option and press the
appears.
3. Use the button on the remote to select the desired mode. The mode switches as follows when the
button is pressed:
Note: If you don't push the
Once you've selected the desired mode, press OK or MENU. The picture mode is now set and you are
returned to the PICTURE QUALITY screen. If you are using MEMORY mode, you can manually adjust the
picture settings (contrast, black level, and sharpness). You can continue adjusting settings in the PICTURE
QUALITY menu, return to the main menu, or exit the menu system.
To return to the main menu, press the GO BACK button on the remote. To exit the menu system, press
CLEAR.
Chapter 2

On-Screen Menu Operation

To access the main menu, press the MENU button on the remote. The MAIN MENU
is displayed on the screen. The main menu contains a list of all the menus that
control your monitor. To select a menu, use the up/down arrow buttons on the
remote to highlight the desired menu. When the desired menu is highlighted, press
the OK or MENU button to select.
EXIT
key on the remote to select it. The PRESETS window
button within 5 seconds, the current selection is set and the previous screen reappears.
Note: Different components use different types of input (RGB, video, etc). Some menu options
apply to only one type of input, so they only appear when they apply to the currently active
input. For example, the COLOR and TINT options in the PICTURE QUALITY menu only appear
when you are adjusting standard video input (VIDEO1, VIDEO2, VIDEO3).
The Menu System
19
