Connecting Your VCR Or Laserdisc Player

Use common RCA cables (not provided) to connect your VCR or laserdisc player to your monitor. To connect your VCR or Laserdisc
player:
1. Turn off the power to the monitor and VCR or laserdisc player.
2. Connect one end of your RCA cable to the video output connector on the back of your VCR or laser disc player. Connect the
other end to the video input on the monitor.
3. Use standard RCA cables to connect the audio from your VCR or laserdisc player to AUDIO2 input jacks on the monitor (if your
VCR or laserdisc player has this capability). Be careful to keep your right and left channel connections correct for stereo sound.
4. Turn on the monitor and the VCR or laserdisc player.
NOTE: Refer to your VCR or laserdisc player user's manual for more information about your equipment's video output requirements.

Connecting Your DVD Player

To connect your monitor to a DVD player:
1. Turn off the power to the monitor and DVD player.
2. Use component video cables to connect your DVD player to the CMPNT1 input on the monitor, or use the DVD player's S-Video
output. (Use a standard S-Video cable to connect to the S-Video input on the monitor.)
3. Turn on the monitor and the DVD player.

Connecting a Personal Computer

If you have a computer with digital RGB output, connect it to the RGB3 jack on the monitor.
For IBM VGA (or compatible) or Macintosh (or compatible) connect to the RGB1 jack on the monitor.
Chapter 1
Connections and Setup
9
