Connections and Setup
AUX Operates the component you've
programmed to work with the AUX button.
VCR1, VCR2, DVD, HD RCVR The
component buttons used to put the
remote into the correct mode to operate
that particular component. The correct
video source must first be selected or
Autotuning must be set up.
MUTE Makes sound inaudible.
VOL</VOL> Adjusts the volume.
SLEEP Brings up the sleep timer, which
turns the monitor off automatically after
a set amount of time.
GUIDE In HD receiver mode, brings
up the on-screen program guide.
OK/ZOOM In Monitor mode (using
on-screen menus), press OK to select a
highlighted item. When no menus are
displayed, press OK to bring up the
zoom pointer. Use the CH+/- buttons
to zoom in/out.
Arrows Use to navigate through the
menu screens and move the Zoom
pointer in Zoom mode.
MENU Brings up the on-screen menu.
Numbers Use to make numerical entries.
INPUT Press to toggle through all
inputs (RGB, Component, Video).
CINEMA Select screen sizes to suit the
type of input you're watching.
12

The Remote Control

ON•OFF Toggles power on and
off for the components that you
have programmed.
ON•OFF
VCR MONITOR
1
DVD VCR AUX HD RCVR
2
MUTE
WHO•MULTI
SLEEP
GO BACK
GUIDE INFO
OK
CLEAR
MENU
3
1 2
4 5 6
7 9
8
INPUT
ANTENNA
0
REVERSE PLAY FORWARD
STOP PAUSE
RECORD
CINEMA RGB CMPNT VIDEO
SOURCE
u n i v e r s a l
RGB Depending on how you set up the monitor,
toggles between RGB1, RGB2*, and RGB3.
*Note: You can set up CMPNT2 OR RGB2, but not
both. If CMPNT2 is set up, RGB2 will not appear
when you use the RGB button.
MONITOR Turns the monitor on and puts the
remote in Monitor mode.
WHO•MULTI When in Monitor mode,
activates the multi-screen feature. The Multi-
screen feature allows you to select a screen
mode for viewing a single picture, side-by-side
pictures, or picture-in-picture (PIP). Brings up
personal viewer profiles for some components.
ZOOM IN In zoom mode enlarges the picture.
Use the arrow buttons to pan and scan the
entire picture.
CH+/CH– Changes channels on the HD
receiver when the remote is in HD receiver
mode. When the Zoom mode is active, zooms
in (CH+) or out (CH-).
GO BACK In HD receiver mode, returns you to
the previous channel. When in the menu
system, returns you to the previous menu.
CLEAR Clears on-screen displays.
ANTENNA In HD RCVR mode, switches the
HD receiver between Antenna A and Antenna
B.
INFO Brings up channel information.
REVERSE, PLAY, FORWARD, STOP,
PAUSE, RECORD (transport keys) Use
with components programmed to work
with your remote control.
VIDEO Toggles through video inputs.
CMPNT Toggles between CMPNT1 and
CMPNT2 inputs.
