Freescale Semiconductor, Inc.
User's Guide
TWR-K65F180M User's Guide
1 Introduction
The K65F180M Tower MCU Module
(TWR-K65F180M) is a low-cost evaluation,
demonstration, and development board, which features
the Kinetis 180 MHz K65 low-power MCU. The
TWR-K65F180M microcontroller module can operate in
stand-alone mode or as part of the Freescale Tower
System, a modular development platform that enables
rapid prototyping and tool re-use through reconfigurable
hardware. Take your design to the next level and begin
constructing your Tower System today by visiting
freescale.com/tower
for additional Tower System
microcontroller modules and compatible peripherals.
© 2015 Freescale Semiconductor, Inc. All rights reserved.
Document Number: TWRK65F180MUG
Contents
1
..................................................................... 2
1.2
........................................................... 3
2
3
.................................................................... 5
............................................................ 5
.................................................................... 8
........................................................... 8
.......................................................... 9
.......................................................... 10
.................................................... 11
4
5
6
7
8
Rev. 0 , 05/2015
1
3
4
........................................ 4
6
..... 6
............................................. 7
FlexBus................................ 7
.............................. 8
........ 9
............................................. 10
11
13
14
16
17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Freescale Semiconductor TWR-K65F180M
Summary of Contents for Freescale Semiconductor TWR-K65F180M
-
Page 1: Table Of Contents
............9 3.13 USB interface ............10 3.14 Secure digital card slot ..........10 3.15 Ethernet and 1588 ............ 11 Jumper table Input/output connectors and pin usage table Elevator connections References Revision history © 2015 Freescale Semiconductor, Inc. All rights reserved. -
Page 2: Features
Board power select with 3.3 V or 1.8 V MCU operation MicroSD card slot OpenSDA USB OpenSDA Touch Pad K20 JTAG Reset SD card slot K65 JTAG SDRAM K65FN2M0VMI18 Figure 1. Front side of the TWR-K65F180M module TWR-K65F180M User's Guide, Rev. 0, 05/2015 Freescale Semiconductor, Inc. -
Page 3: Getting Started
VBAT Figure 2. Back side of the TWR-K65F180M module Getting started You can find a printed version of the Quick Start Guide in the TWR-K65F180M box that contains the list of recommended steps for getting started. 2 Contents The TWR-K65F180M includes: ... -
Page 4: Hardware Description
3 Hardware description ® The TWR-K65F180M is a Tower MCU Module featuring the K65FN2M0VMI18 – an ARM ® Cortex -M4F based MCU with 2 MB on-chip flash, 256 KB on-chip SRAM, SDRAM controller and dual USB controllers in a 169 pin MAPBGA package. It has a maximum core operating frequency of 180 MHz. -
Page 5: Clocking
EXTAL0 and XTAL0 pins. System power In standalone operation, the main power source for the TWR-K65F180M is derived from the 5.0 V input from either the USB mini-B connector, J7, or the debugger header, J18, when a shunt is placed on jumper J21. -
Page 6: Tamper Module (Dryice) And Real-Time Clock Supply
J9. See sheet 5 of the TWR-K65F180M Schematics (document TWR-K65F180M-SCH) for further details. When installed into a Tower System, the TWR-K65F180M can be powered from either an on-board power source or from another power source in the assembled Tower System. If both the on-board and off-board power sources are available, the TWR-K65F180M will default to the off-board power source. -
Page 7: Cortex Debug Connector
The K65 device features a multi-function external bus interface called the FlexBus interface controller. This is capable of interfacing with slave-only devices. The FlexBus interface is not used directly on the TWR-K65F180M. Instead, a subset of the FlexBus is connected to the Primary Connector so that the “Error! Reference source external bus can access devices on Tower peripheral modules. -
Page 8: Sdram
SDRAM The TWR-K65F180M board contains 64 Mb SDRAM (32-bit width) which is connected to the K65 SDRAM controller. The SDRAM signals are multiplexed with Flexbus signals. See the K65 Family Reference Manual (document K65P169M180SF5RMV2) “Flexbus signal multiplexing” section and “SDRAM SDR signal multiplexing” section on how to use the Flexbus and SDRAM in multiplexed mode. -
Page 9: General Purpose Tower Plug-In (Twrpi) Socket
3.11 General Purpose Tower Plug-in (TWRPI) socket The TWR-K65F180M features two sockets (J11 and J12) that can accept a variety of different Tower Plug-in modules featuring sensors, RF transceivers, and more. The General Purpose TWRPI socket provides access to I C, SPI, IRQs, GPIOs, timers, analog conversion signals, TWRPI ID signals, reset, and voltage supplies. -
Page 10: Usb Interface
Figure 7. USB signal routing 3.14 Secure digital card slot A Micro SD card slot is available on the TWR-K65F180M connected to the SD host controller (SDHC) “Error! signals of the MCU. This slot will accept standard format SD memory cards. See Table 5 Reference source not found.”... -
Page 11: Ethernet And 1588
The K65FN2M0VMI18 features a 10/100 Mbps Ethernet MAC with MII and RMII interfaces. The TWR-K65F180M routes RMII interface signals from the K65 MCU to the primary elevator connector which enables a connection to an external Ethernet PHY that can be found on some Tower peripheral modules. - Page 12 Table 4. TWR-K65F180M jumper table (continued) Default Jumper Option Setting Description setting Connect PTD8 to USB power enable for MIC2005 USB power enable connection Disconnect PTD8 to USB power enable for MIC2005 Connect PTD9 to USB over-current flag for MIC2005...
-
Page 13: Input/Output Connectors And Pin Usage Table
5 Input/output connectors and pin usage table The table below provides details on which K65F180M pins are used to communicate with the TWR-K65F180M sensors, LEDs, switches, and other I/O interfaces. NOTE Some port pins are used in multiple interfaces on-board and many are potentially connected to off-board resources via the primary and secondary Connectors. -
Page 14: Elevator Connections
PTC19 6 Elevator connections The TWR-K65F180M features two expansion card-edge connectors that interface to Elevator boards in a Tower System: the primary and secondary Elevator connectors. The pinout for the primary Elevator Connector is provided in this table. The values in bold are either power or ground. - Page 15 Table 6. TWR-K65F180M Primary Connector Pinout (continued) Ground Ground SDHC_CLK / PTE2 SCL0 PTE19 SPI1_CLK SDHC_D3 / — SDA0 PTE18 SPI1_CS1_b SDHC_D3 / PTE4 SPI1_CS0_b GPIO9 / CTS1 PTD1 SDHC_CMD / PTE3 SPI1_MOSI GPIO8 / SDHC_D2 PTE5 SDHC_D0 / GPIO7 /...
-
Page 16: References
Table 6. TWR-K65F180M Primary Connector Pinout (continued) — USB0_DP_PDOWN GPIO17 PTA27 — USB0_DM_PDOWN USB0_DM ELEV_USB_DN IRQ_H PTE27 USB0_DP ELEV_USB_DP — IRQ_G PTE27 USB0_ID IRQ_F PTC11 USB0_VBUS ELEV_USB_VBUS IRQ_E PTC11 I2S0_DIN_BCLK PTE9 IRQ_D PTC3 I2S0_DIN_FS PTE8 IRQ_C PTC3 I2S0_RXD1 PTE8 IRQ_B... -
Page 17: Revision History
8 Revision history Table 7. Revision history Revision number Date Substantive changes 05/2015 Initial release TWR-K65F180M User's Guide, Rev. 0, 05/2015 Freescale Semiconductor, Inc. - Page 18 Freescale, the Freescale logo, and Kinetis are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. Tower is a trademark of Freescale Semiconductor, Inc. All other product or service names are the property of their respective owners.
