The Datamars R-IN1300 MID High Frequency (HF) RFID-reader, designed to work in industrial
environments, is resistant to vibrations, electromagnetic interference and able to detect the following
transponder technologies:
The reader is able to find simultaneously more than one High Frequency (HF - multi read)
transponder
Tag found
HF field indicator
Power indicator
LEDs
Power
Tag
HF
Antenna
Antenna
Interfaces
Host
USB
Ethernet (Web Server)
1
the quantity of transponders detected and the accuracy can change depending on the used transponder, the environment, the size of the antenna, etc.
R-IN1300 MID Manual – v. 1.2 – August '08
T-BT 1320 & T-BT1315 (ISO 15693), HF
1
.
Light on when the reader is switched on
Light on when one or more transponder are detected
High Frequency reading is ON
TX/RX antenna: for example A-ST1330TT / TTL
Connect to any serial port (COM) on your PC with RS-232 cable or to
any other RS232 Terminal.
USB device port
Connect to LAN with a standard Ethernet cable.
For more info in Ethernet communication please request the
"R-IN1300 TCP/IP Dedicated Protocol" manual to
support@datamars.com
Host Interface
USB interface
Ethernet interface
Antenna
2 (29)
