5 T
S
ECHNICAL
5.1
O
PERATIONAL CHARACTERISTICS
The DATAMARS SA RFID reader R-IN1300 MID is an integrated analog system for RFID-
Applications (RFID=radio frequency identification) which works at 13.56MHz. It allows reading data
stored into ISO-RFID transponders or ISO-Labels at 13.56 MHz. Single and Multiread operation are
supported. The communication between the reader and the transponder is based on the ISO 15693
(Part 1-3) protocol.
All transponders (contact less memories) are powered by a transmitted carrier radio wave at
13.56MHz and are compliant with the ISO 14443-B recommendation for the transfer of power and
signals via radio transmission. For this purpose the reader R-IN1300 MID amplitude, modulates the
data on the carrier using amplitude shift keying (ASK) and the tag replies by load modulating the data
on the carrier.
Once the reader is connected to an appropriate client-network (via dedicated computer) it works
based on the installed software like a server providing the received data from the transponders to the
final client-application.
The service software helps to control and update the reader in user-friendly way.
R-IN1300 MID supports different antennae as well as multiple configurations.
5.2
E
LECTRICAL CHARACTERISTICS
Electrical characteristics (without antenna)
POWER SUPPLY
POWER CONSUMPTION
ANTENNA OUTPUT POWER
Technical characteristics
OPERATING FREQUENCY
OPERATING TEMPERATURE
DIMENSIONS
WEIGHT
T
T
RANSPONDER
YPE
ANTI COLLISION
COMMUNICATION PROTOCOL
AUTO TUNING
S
READING
PEED
R-IN1300 MID Manual – v. 1.2 – August '08
PECIFICATIONS FOR
AC 100-240V
35 W
4 W
13.56 MHz
0°C - 40°C / 32°F - 104°F
222 x 152 x 59 (mm) / 8.7 x 6.0 x 2.3 (inches)
1.5 kg
ISO15693 (T-BT 1320 or T-BT1315)
Yes
RS-232, USB (upon request), TCP/IP (Ethernet)
No
Depend on number of transponder and technology (up to
40/s)
R-IN1300 MID
1A
50-60 Hz
24 (29)
