- Page 1 R-IN1300 MID HF – multi read QUICK START GUIDE Version 3.0 Corporate Headquarters - Textile ID business division: Via Industria 16 6814 Lamone Switzerland Phone: +41 91 935 73 80 Fax: +41 91 945 03 30 textile-id@datamars.com www.textile.datamars.com...
- Page 2 1. For operation with terminal use any kind of terminal, e.g. Windows HyperTerminal with the following settings: • Bits per second 115200 • Data bits 8 • Parity None • Stop bits 1 • Flow control None R-IN1300 MID – UM001061 – v.3.0 – January 2019 1 (5)
- Page 3 The “Start Monitoring” button permits to display the UIDs of the chips found by the reader. The “Clear Result” button clears the UIDs display. The “Stop Monitoring” button stops the display. The led “D” (detection) is green if the reader sends UIDs, red otherwise R-IN1300 MID – UM001061 – v.3.0 – January 2019 2 (5)
- Page 4 4. Do not plug/unplug any connectors while the reader is turned ON. Need help? For more product information refer to the user manual of the R-IN1300 MID on the CD-Rom. R-IN1300 MID – UM001061 – v.3.0 – January 2019 3 (5)
- Page 5 The following picture shows how to assemble the connector on the 3 wire cable. The 3 wire terminals must be soldered on the connector terminals as described in chapter 1.1. R-IN1300 MID – UM001061 – v.3.0– January 2019 4 (5)
- Page 6 Note: for optimum performance the earth must be connected. Corporate Headquarters - Textile ID business division: Via Industria 16 6814 Lamone Switzerland Phone: +41 91 935 73 80 Fax: +41 91 945 03 30 textile-id@datamars.com www.textile.datamars.com R-IN1300 MID – UM001061 – v.3.0 – January 2019 5 (5)
