SY3000/5000/7000
Valve piping direction variations
Piping is possible from 3 directions.
Side ported
Valves can be freely connected up to
S0700
Series
7
mm width valves
can be connected.

Applicable Valve Series
Series
Series
Bottom ported
Mixed mounting of top ported and side ported is possible.
24
It is possible to connect only
the number of valves required,
from 1 to 24 stations, to suit
the application.
(Maximum number of
solenoids connected: 32)
Flow rate characteristics (4/2→5/3)
C [dm /(s·bar)]
3
SY3000 1.6
SY5000 3.6
SY7000 5.9
S0700 0.37
SV1000 1.1
SV2000 2.4
SV3000 4.3
VQC1000 1.0
VQC2000 3.2
VQC4000 7.3
VQC5000 17
Top ported
Side ported
stations.
Mixed valve sizes manifold
Valves with different sizes,
SY3000 and SY5000 or SY5000
and SY7000, can be mounted
on the same
manifold.
It is possible to connect only the number of 7 mm
width valves required, from 1 to 24 stations.
(Maximum number of solenoids connected: 32)
Maximum
number of
b
solenoids
0.19
32
0.17
0.20
32
0.39
0.35
32
0.18
0.21
0.30
0.30
24
0.38
0.31
Note) For units with D-sub communication connector, it is IP40.
Pressure switch
<Example of Use>
By mounting top ported valves on side
ported and bottom ported type manifolds,
it is possible to detect the output of the
A/B port with a pressure switch.
Power
consumption Enclosure
(W)
0.35 (standard)
0.1 (with power-
IP67
saving circuit)
[Starting 0.4,
Holding 0.1]
IP40
0.35
IP67
0.6
0.4 (standard)
IP67
0.95 (standard)
0.4 (Low wattage type)
EX12
EX140
EX180
EX260 EX260
EX250
EX600
EX500
EX510
PCA
EX
Standards
®
