- Page 1 200 New Highway Amityville, NY 11701 631-957-8700 www.specotech.com Intensifier Series Camera HT-INTD3 HT-INTD4 Please read this manual thoroughly before operation and keep it handy for further reference.
-
Page 3: Table Of Contents
Contents Package Contents Precautions Camera Installation Internal Components Features Operating Your Camera * SET UP --------------------------------------------------------------11~12 * SET UP LENS-------------------------------------------------------13~14 * SHUTTER SPEED CONTROL ----------------------------------15~18 * BACK LIGHT--------------------------------------------------------------19 * AUTO GAIN (AGC) -----------------------------------------------------20 * WHITE BALANCE --------------------------------------------------21~22 * REDUCE NOISE---------------------------------------------------------23... -
Page 4: Package Contents
OR 12 VOLT DC POWER SUPPLY PLEASE USE APPROPRIATE LOW VOLTAGE POWER CABLE TO PREVENT FIRE OR ELECTRICAL SHOCK. PLEASE INSURE THAT YOUR INSTALLATION AREA CAN SUPPORT THE WEIGHT OF THE CAMERA. PLEASE HANDLE THIS CAMERA CAREFULLY: - DON’T EXPOSE THE CAMERA TO DIRECT SUN... -
Page 5: Camera Installation
CAMERA INSTALLATION Connections: 1. When using 12-Volts DC (constant voltage 600mA) -CONNECT POWER TO THE POWER JACK. POWER INPUT:RED connect CENTER:(+) 2. When using 24-Volts AC (40 VA) -CONNECT ACCESSORY CABLE TO THE POWER JACK AND CONNECT AC 24V TO THE LEAD. - Page 6 ♣ ELECTRONIC DAY / NIGHT The Intensifier camera can show color pictures in all lighting conditions, or you can have it automatically switch to a B/W picture in low light conditions ♣...
-
Page 7: Operating Your Camera
●DC ●MANUAL SHUTTER ●OFF ●F/L ●MANUAL WHITE BALANCE ●ATW ●AWC MANUAL● LEFT RIGHT SLC – ( Speco Light Compensation ) ●OFF ●LOW ●MIDDLE ●HIGH LEFT DOWN DOWN Auto Gain ●OFF ●LOW ●MIDDLE ●HIGH REDUCE NOISE ●OFF ●LOW ●MIDDLE ●HIGH INTENSIFIER ●AUTO... - Page 8 Baud Rate Setting (DC12V in) C. System Integration RS485 Baud rate Set ② CCD Camera D. IR Remote Controller -Can call and control each camera on the monitor by the following. LEFT button Buzzer On/Off •Please Observe Polarity! 485(+) 485(-) Receiver...
- Page 9 ●You can access the submenu by using SET button. • ●For the mode with ’---’, you may not access submenu. • Operating your camera - LENS 1) Setting up the LENS Select the lens by pressing the RIGHT button. ① On the SETUP menu screen, move the arrow indicator to the lens using the UP or DOWN button.
- Page 10 Operating your camera – SHUTTER SPEED CONTROL① ▶When the DC LENS is selected, press the SET button to control the BRIGHTNESS. Notes ●AUOT IRIS LENS (DC TYPE) is recommended 2) Shutter status and speed control You can control brightness of the screen by the shutter speed.
-
Page 11: Shutter Speed Control
▶ELC : You can control the BRIGHTNESS. You can select speed from ‘1/60’ to ‘1/200,000’sec ③ When completed, press ‘SET’ Notes ●Avoid pointing the camera directly at a fluorescent lamp. ●When the SHUTTER menu is set to FLK mode, the INTENSIFIER will not work. -
Page 12: Backlight
Operating your camera - BACKLIGHT 3) SLC (Speco Light Compensation) - BACKLIGHT A built-in SR chip provides intelligent light level control to overcome severe Backlight conditions. ① Press the SET button to display the SETUP menu and move the arrow indicator to ‘SLC’ using the UP or DOWN button. -
Page 13: White Balance
▶AWC (Auto White Balance Control) : The white balance is automatically adjusted in a specific environment. In order to obtain the best result, press the set button while the camera focuses on white paper. If the environment including the light source is changed, you have to adjust the white balance again. -
Page 14: Reduce Noise
‘INTENSIFIER’ using the UP or DOWN button. ② SET ‘INTENSIFIER’ to the desired mode using the LEFT or RIGHT button. ▶AUTO : When your camera is under night or low-light ▶OFF : Deactivation Notes ● If you press “auto” button in the Intensifier mode, you can Control the amount of intensification from 2X ~ X128. -
Page 15: Camera Title
‘CAMERA TITLE’ using the UP or DOWN button. ② SET ‘ON’ using the LEFT or RIGHT button. Notes ● If the CAMERA TITLE feature is set to ‘OFF’, the name will not displayed in the monitor. Operating your camera - CAMERA TITLE①... - Page 16 ‘COLOR’ using the UP and DOWN button. ② SET ‘COLOR’ to the desired mode using the LEFT or RIGHT button. ▶COLOR : The camera will always display a color picture ▶AUTO : The camera will switch into the B/W mode under low light conditions. Notes ●OSD Key may not work for 3 seconds when the...
-
Page 17: Motion Detection
Operating your camera – MOTION DETECTION (4) Whenever your camera detects motion, THE WORDS “motion detected’ will appear on the screen. ① Press the SET button to display the setup menu and move the arrow indicator to ‘MOTION’ using the UP and DOWN button. -
Page 18: Privacy
Operating your camera - PRIVACY (5) PRIVACY : To mask an area that you want to be private. ① Press the SET button to display the setup menu and move the arrow to ‘PRIVACY’ using the UP and DOWN button. -
Page 19: Detail
If the level is too high, you can get an unnatural image with video noise. Operating your camera - RESET/RETURN (8) DEFAULT : Use to reset your camera to FACTORY DEFAULT SETTING. (9) PAGE 1 : Save the setting of NEXT PAGE function, and then move to SET UP menu. -
Page 20: Troubleshooting
Troubleshooting If you have trouble operating your camera, refer to the following. Problem Solution Nothing appears on ●Check that the power cord and line connection the screen. between the camera and monitor are attached. ●Check that you have properly connected your video cables. -
Page 21: Specifications Dimensions
SPECIFICATIONS HT - INTD3 ITEM HT - INTD4 Power Source DC 12V & AC 24v ( Dual Voltage ) Power Consumption 280mA(DC) / 3.8W(AC) Image Sensor 1/3”, SONY SUPER HAD CCD, Total Pixels 811(H) x 508(V) , 1/3” CCD Effective Pixels 768(H) x 494(V) , 1/3”... -
Page 22: Warranty
WARRANTY...
