- Page 1 HTSD10X 10X Pan-Tilt Speed Dome Camera 200 New Highway, Amityville, NY 11701 www.specotech.com 800-645-5516...
-
Page 2: Table Of Contents
CONTENTS Warning & Caution What s in the Box? General Features Names of Each Part Installation A. Connection Methods B. Ceiling Mount Type C. Embedded Mount Type Quick Operating Keys Diagnostic OSD Menu Setting A. OSD Menu Table B. DOME SET C. -
Page 3: Warning & Caution
WARNING & CAUTION If you fail to read this information and handle the product incorrectly, serious injury may occur. Never install the product in area exposed to oil or gas. Never install the product on a ceiling that cannot hold its weight. Never touch the power cord with wet hands. -
Page 4: General Features
GENERAL FEATURES 100X Zoom Mini Speed Dome 10X Optical Zoom with 10X digital zoom ±0.02° dome system accuracy With 0.1° technical accuracy, camera provides excellent sensitive and delicate controlling on preset mode by adapting 1/4 micro step and twin gear system 360°... -
Page 5: Names Of Each Part
NA MES OF EA CH PA RT 1. Surface Mount Adaptor 2. Cap Screw ( PT3/4 , 2EA ) 3. Dip Switch 4. Terminal Block 5. Main body... -
Page 6: Installation
INSTALLATION A. CONNECTION METHOD Loosen the screws on the domes cover and remove it from the base. (Screws will not come out) Loosen the screws which connect the mount cover and Main base and separate the dome cover from the main base. (Screws will not come out) Connect power (12 VDC 1.5 A ) to Power and GND. -
Page 7: Ceiling Mount Type
INSTALLATION B. MOUNT 1. Attach the surface mount adaptor with 4 screws at the installation site. (FIG.4) 2. When you use pipe, please note the standard size of pipe. (FIG.5) 3. Re-assemble the domes. -
Page 8: Quick Operating Keys
QUICK OPERATING KEYS 1-64 + preset and 101~200 + preset are used for preset and 65-100 + preset used f or functions. For example, to enter OSD MENU, press the button 95 +PRESET. <Quick Operation Key Table 1, Pelco - D, P> Number 1 ~ 64, 100~200 +Preset PRESET... -
Page 9: Diagnostic
QUICK OPERATING KEYS DIAGNOSTIC When the Power is turned on a DIAGONOSTIC is operated. The following messages are displayed on the monitor. CAMERA ID : 001 BAUD RATE : 2400 BPS WAITING PAN ORIGIN TILT ORIGIN TX CONNECTION CAMERA COMM Pan Origin Test Zero point of Pan is founded after Panning test. -
Page 10: Osd Menu Setting
OSD MENU SETTING If all the above Tests are OK, EEPROM CHECKING and EEPROM OK is displayed and the camera is ready to operate. A. OSD MENU TABLE... -
Page 11: Dome Set
OSD MENU SETTING To enter the OSD Menu, press the button 95 + PRESET. MAIN MENU DOME SETUP CAMERA SET AUTO SCAN TOUR PRAVACY PATTERN ALARM SECTOR EXIT * Use the joystick up - down to move the position and left - right to make selection B. - Page 12 OSD MENU SETTING B-2. DOME SET - RECOVER This feature allows the dome to work from the last setting before you use the dome manually (Auto scan, group tour, pattern or sectors) , after the set time, even power shut down and it turns on again.
- Page 13 correct password. In order to enter [PASSWORD] page, system lock status is must set as ON. OSD MENU SETTING Move joystick to right or left direction to select ON. The default setting is OFF. B-8-2. DOME SET [NEXT PAGE] To enter this page to set a password, move the joystick to the right direction. The password must be set by preset number from 001 to 255 (Default 99) A.
- Page 14 OFF/ON when the cursor is located each item. OSD MENU SETTING OSD DISPLAY CAMERA ID : OFF PRESET ID : OFF SECTOR ID : OFF COORDINATE : ON [PREVIOUS PAGE] B-8-4. DOME SET [NEXT PAGE] This page shows the information of this camera. SYSTEM STATUS PROTOCOL : PELCO D, P...
- Page 15 OSD MENU SETTING To clear memorized data, move joystick to the right direction when cursor is on each item. TOUR CLEAR ARE YOU SURE? YES NO Press FOCUS NEAR button when the cursor is at YES in order to clear memorized data. Then each item such as tour, preset, sector and so on is displayed on the monitor about 2~3 seconds.
-
Page 16: Camera Set
OSD MENU SETTING C. CAMERA SET C-1. CAMERA SET - FLICKERLESS Flickerless feature is selected between 50Hz and 60Hz. The default setting is OFF (NTSC: 60Hz / PAL: 50Hz). Set flicker mode ON when power source is in discord with frequency. The default setting is OFF C-2. - Page 17 AWB Mode 3,200°K to 6, 000°K OSD MENU SETTING Indoor up to 3,200°K Outdoor up to 5,800°K ATW Mode - 2,000°K to 10, 000°K C-6. CAMERA SET PIC FLIP Picture flip feature turns ths picture upside down. Move the joystick to the right or left direction to select OFF/ON.
-
Page 18: Preset
OSD MENU SETTING D. PRESET SET To enter PRESET SET, move the joystick to the right direction. PRESET SET PRESET NO :001 PRESET ID :PRESET001------- PAN :XXX.XX TILT : XXX.XX SAVE EXIT D-1. PRESET PRESET NO. Up to 164 numbers of preset positions are available. Move joystick to the right or left direction to select a preset no. -
Page 19: Auto Scan
OSD MENU SETTING E. AUTO SCAN SET * 66 + preset button is working as AUTO SCAN after setting. AUTO SCAN SET START ANGLE : XXX.X.XX.X END ANGLE : XXX.X.XX.X DIRECTION : CW ENDLES : OFF SPEED : 10°/S DWELL TIME : 03 SAVE AND EXIT EXIT... -
Page 20: Tour Set
E-8. AUTO SCAN EXIT OSD MENU SETTING To escape this page, move the joystick to the right . F. TOUR SET 8 Programmable tours can be set and each tour is available to set up to 64 preset steps. After setting the data to each tour group, 71~78 + preset buttons are working as group tour # 1~8 TOUR SET TOUR NO... -
Page 21: Privacy Set
F-8. TOUR SET EXIT OSD MENU SETTING To escape this page, move the joystick to the right G. PRIVACY SET 4 Privacy masking zones are available to block out areas of the scene. PRIVACY SET PRIVACY NOMBER : 01 DISPLAY : OFF ACTION : MOVE... -
Page 22: Pattern Set
G-5. PRIVACY SET EXIT To escape this page, move the joystick to the right OSD MENU SETTING H. PATTERN SET 8 programmable patterns are available with 16 characters of title. After setting the data to each pattern # 1~8, 81~88+ preset buttons are working as Pattern # 1~8. PATTERN SET PATT NO : 01... -
Page 23: Alarm Set
OSD MENU SETTING I. ALARM SET 4 Alarm inputs are available and each alarm can activate presets, group tours or patterns. ALARM SET ALARM NO : 01 ALARM INPUT: OFF ALARM ACT : 001 SAVE EXIT I-1. ALARM SET ALARM NO. Up to 4 alarms are selectable by using the joystick to the right when the cursor is on ALARM NO. -
Page 24: Sector Set
OSD MENU SETTING J. SECTOR SET Up to 8 programmable sectors are available with 16 characters. This feature is useful to memorize certain locations such as a parking zone, etc. When a camera goes through this area, it shows the letter you memorized. SECTOR SET SECTOR NO : 01... -
Page 25: Dip Switch Setting
K. EXIT To escape the OSD Main Menu, move the joystick to the right or left direction then this DIP SWITCH SETTING camera is ready to operate. A-1. DIP SW SETTING This Speed Dome camera provides up to 63 camera ID s, adjustable using the 1 Open the camera case to set ID using DIP SW1. -
Page 26: Protocol/ Baud Rate Setting (Dip Sw1-9~10)
DIP SWITCH SETTING A-3. PROTOCOL dip switches are used for Protocol Setting. Factory Default: Pelco-D or Pelco-P ( Auto detection) DIP SW 1- 7 DIP SW 1- 8 A-4. BAUD RATE SETTING The 9 Dip Switch is used for BAUD RATE setting. DIP SW can be changeable to 2400bps, 9600bps. -
Page 27: Trouble Shooting
TROUBLE SHOOTING If you have trouble operating in your camera, refer to the following. PROBLEM Check if the power supply is 12 VDC. Check if RS-485 communication cable is connected correctly. Not operating Check camera ID setting. Check the termination. Check if all the cables are connected correctly. -
Page 28: Specification
SPECIFICATIONS MODEL Pan Rotation Angle Manual Pan Speed Preset PAN /TILT Tilt Rotation Angle Manual Tilt Speed Preset System Accuracy Presets Group Tour Auto scan Pattern Privacy Zone FUNCTIONS Sector Password Protection Alarm Input Alarm Actions Auto Flip OSD Menu Communication Protocol Power Consumption... -
Page 29: Dimension
NTSC Flickerless W HITE BALANCE DIMENSIONS ON / OFF (1/100) ON / OFF (1/120) AW B/ATW/INDOOR/ OUTDOOR...
