Frame Rate
Control image transmission speed from 5 levels (fastest, 10fps, 5fps, 3fps, 1fps). "Fastest," will receive
images at the fastest speed possible within the network environment. The transmission speed is dependent on
the network line's capacity and user PC's performance.
(2) Camera
Select cameras to monitor. User may select one specific camera to monitor real-time image.
(3) Transmission Control
On this viewer, "Channel Rotate Mode On" menu is not available.
Gray Mode
Images are displayed in black and white. Images can be transmitted at a higher speed under gray mode.
Single Shot Mode
When this button is clicked, one frame of image is reproduced. Therefore, no other images may be viewed.
(4) Play Control
Pan/Tilt: To move the direction of external camera to where to want to see.
Zoom: To zoom the image in and out.
Focus: To control and optimize the image's focus.
Accel. Rate: To control the moving speed of the Pan / Tilt mechanism.
(5) Convenient pop-up menu
'Quality Box', 'Focus Sensitivity', and 'Image Quality' menus are not supported.
Image Info
You may decide the color (black or white) of the information that is shown on the left top of the image. And
you may leave out the information.
Save As File
It is to save a frame of still image as an electric file. A still image can be saved as bitmap (*.bmp) file or
Wavelet format file (*.eye). Wavelet formatted image file is to be reproduced on Internet Explorer as long as
the PC is installed Active-X program. The very image that is shown at the moment when you click the save
button is saved.
(6) To Home
This button returns to the default viewer.
(7) Capture
This button is to save a frame of still image transmitted from Webthru. This function is the same with 'Save
As File' menu.
(8) Admin
It is to access administration page. (Refer to Chapter VII 'Configuring Administrator's Configuration at
Homepage')
(9) FAQ
User may refer FAQ for trouble-shooting in installing or running Webthru.
