Webthru SWC 306 User's Guide
This manual is for Webthru SWC 306 Firmware version 1.4.0. If you have later version of
※
firmware, please download the last updated user's guide from Samsung Web Camera's
homepage. (www.webthru.net)
System Requirements
For Webthru SWC 306
10 Base-T LAN
(Leased line, xDSL, Cable Modem, ISDN)
For a PC to access Webthru SWC 306
Processor: Pentium II and above
RAM: 64MB and more
OS: Windows 98/NT/2000
Web browser: Internet Explorer 5.0 and above
Screen Resolution: 1024 X 768 pixels and above
SAMSUNG TECHWIN CO., LTD.
http://www.webthru.net
Version 1.0
Advertisement
Table of Contents
Related Manuals for Samsung Webthru SWC 306
Summary of Contents for Samsung Webthru SWC 306
-
Page 1: System Requirements
Webthru SWC 306 User’s Guide This manual is for Webthru SWC 306 Firmware version 1.4.0. If you have later version of ※ firmware, please download the last updated user’s guide from Samsung Web Camera’s homepage. (www.webthru.net) System Requirements For Webthru SWC 306... - Page 2 3. Be cautious in handling Webthru SWC 306 Physical shock such as dropping the unit may damage the Webthru SWC 306 and void warranty. 4 The Webthru SWC 306 is made of metal. Be sure that it is fastened tightly during installation to avoid any human injuries. Make sure to place away from the reach of children.
-
Page 3: Table Of Contents
3. RS232/RS422/RS485 Descriptions ..................... 7 4. Description on LED of Ethernet Port ..................8 5. Descriptions on DIP Switches ..................... 8 III. Webthru SWC 306 Installation Summary, Connection & Placing ..........9 1. Installation Summary........................9 2. Connecting........................... 9 IV. Installing Webthru SWC 306 Setup Program................9 V. - Page 4 11) Digital I/O Configuration....................30 12) Alarm Configuration......................30 13) User Custom Configuration..................... 30 14) Goto Viewer Page ......................31 Detailed Specifications of Webthru SWC 306 .................. 32 1. General............................32 2. Network ............................. 32 3. Mechanical..........................33 4. Compatible external devices and software ................33 5.
-
Page 5: Introduction
No other hardware is necessary for use. The Webthru SWC 306 relays video source from a CCTV camera to network and provides real time images over networks and the Internet. Simply provide power and connect LAN cable and video cable to the Webthru SWC 306. -
Page 6: Product Description
DC 12V, 1.0A brackets for 19-inch rack Accessories bracket for connecting two SWC 306 Screw for bracket CD ROM title Setup program and manual 2. Webthru SWC 306 View and Descriptions RS232/RS422/RS48 Sensor In Alarm DC 12V Network Link DIP Switch... -
Page 7: Rs232/Rs422/Rs485 Descriptions
To supply power to external devices Ground To ground cables of power, communication, etc. To communicate between Webthru SWC 306 and external devices such a RS-232 CCTV camera or an external modem. These pins are for devices that satisfy RS-232C protocol, and they are consisted in RX and TX. -
Page 8: Description On Led Of Ethernet Port
75ohm O F F To configure the function of the six coaxial cable ports at the rear of Webthru SWC 306. You can configure the relevant channels with each switch. If you connect two CCTV cameras(1Vp-p /75ohm) to Video Inputs and monitor real time video through 1 and 2 channels, place the two DIP switches (marked with No. -
Page 9: Webthru Swc 306 Installation Summary, Connection & Placing
III. Webthru SWC 306 Installation Summary, Connection & Placing 1. Installation Summary Connect Ethernet and Power to Webthru on local network for configuration. Install Webthru Setup Program into a PC on local network. Assign an IP address to Webthru and configure administrator’s condition. -
Page 10: Assigning Ip Address And Configuring Administrator's Condition
Connect Webthru to a PC through a HUB. 2) Connecting Webthru SWC 306 to a PC Use the crossover cable (red colored one) to directly connect Webthru SWC 306 to a PC. This connection is to be used to configure Webthru. Crossover cable Connect Webthru directly to a PC through LAN ports. -
Page 11: Assigning Ip Address And Configuring Administrator's Condition With Setup Program
2. Assigning IP address and Configuring administrator’s condition with Setup program 1) Starting Setup Program for Webthru SWC 306 Click the “WebthruSetup.exe” file on your PC. When the Setup Program is executed, the setup program detects and shows every Webthru connected on the local network. -
Page 12: Verifying Installation
C grade network means that first 3 sets of numbers are the same but the fourth set is different. For example 192.168.1.2 and 192.168.1.3 are in the same local network. (If there is a ‘Network Mask’ on the network, this can be an exception. For detailed information on IP, refer to appendix 3) Webthru SWC 306 User’s Guide... -
Page 13: Accessing Webthru Swc 306 Homepage & Monitoring Real-Time Image
VI. Accessing Webthru SWC 306 Homepage & Monitoring Real-time Image After assigning Webthru an IP address, the Webthru can be configured within its self- contained homepage through any standard Web browser on a local network. However access to its Homepage by a remote network is not possible until gateway address, subnet mask, and broadcast address have been properly assigned. -
Page 14: Various Viewers In Webthru Homepage
Frame rate To control image transmission speed. “Fastest,” will receive images at the fastest speed possible within the network environment. The transmission speed is dependent on the network line’s capacity and user PC’s Webthru SWC 306 User’s Guide... - Page 15 Internet browsers such as Explorer. Another method to capture a still image is: Place the mouse on the image; Click the right mouse button; Select the “Save As File” option from the pop-up menu. Server-Push Viewer To go to the server-push viewer. It lists frequently asked questions and answers. Webthru SWC 306 User’s Guide...
- Page 16 Wavelet format file (*.eye). Wavelet formatted image file is to be reproduced on Internet Explorer as long as the PC is installed Active-X program. The very image that is shown at the moment when you click the menu is saved. Webthru SWC 306 User’s Guide...
-
Page 17: Real Time Monitoring Through Default Multi Viewer
(1) Image Control Extension menu is not supported. Image Size Select the level of resolution from 5 levels (720x486, 720x243, 360x243, 180x121, 90x60). Higher- resolution images are larger file sizes and are transmitted at slower speed. Webthru SWC 306 User’s Guide... - Page 18 This button is to save a frame of still image transmitted from Webthru. This function is the same with ‘Save As File’ menu. (8) Admin It is to access administration page. (Refer to Chapter VII ‘Configuring Administrator’s Configuration at Homepage’) (9) FAQ User may refer FAQ for trouble-shooting in installing or running Webthru. Webthru SWC 306 User’s Guide...
-
Page 19: Configuring Administrator's Condition At Webthru Swc 306 Homepage
VII. Configuring Administrator’s Condition at Webthru SWC 306 Homepage This page is for administrator. Administrator may control operating status remotely. This page can be accessed through Setup program by clicking ‘Start Configuration’ button. 1. Administrator Login 1) Accessing through setup program Select Webthru by clicking on the MAC address or IP address. -
Page 20: User Configuration
LAN may share limited official IP address for Internet access. In other words, every host on a LAN may lease official IP address from DHCP server temporarily. (2) Select Network Interface This is to select proper network interface with which Webthru is connected. Webthru SWC 306 User’s Guide... -
Page 21: Dynamic Ip Registration Service For Isdn And Xdsl Users
If not, no one can access the Webthru through Web browser. It is because that no one knows IP address which one can access the Webthru with. Webthru SWC 306 User’s Guide... -
Page 22: How To Find A Registered Webthru In Webthru Internet Homepage
To solve the problem, Samsung Techwin runs a server making a list of Webthrus that have dynamic IP addresses. On the server, Webthru registers its information such as name, location, and description, so those common users may detect a certain Webthru. Name, location and description are assigned at ‘System Configuration’... -
Page 23: Security Configuration
(0-255: 1 byte): X4 128 64 32 16 8 4 2 1 128 64 32 16 8 4 2 1 128 64 32 16 8 4 2 1 128 64 32 16 8 4 2 1 Webthru SWC 306 User’s Guide... - Page 24 Class Decimal number of X1 byte Network ID Host ID 0 to 127 X2, X3, X4 128 to 191 X1, X2 X3, X4 192 to 223 X1, X2, X3 224 to 239 For Multicasting utilization Webthru SWC 306 User’s Guide...
- Page 25 From the first bit to the second bit 192.0.0.0 From the first bit to the third bit 224.0.0.0 From the first bit to the 8 255.0.0.0 From the first bit to the 9 255.128.0.0 From the first bit to the 16 255.255.0.0 Webthru SWC 306 User’s Guide...
-
Page 26: Video Configuration
However, if a channel without an external source is enabled, the overall transmission speed will go down and no image will appear. To view an image from an external source, the channel with the source must be enabled. Webthru SWC 306 User’s Guide... -
Page 27: Application Configuration
This is to put a person’s e-mail address that is considered as the e-mail sender. The e-mail sender can be a person who should take care of the situation when events occur. E-mail will be Webthru SWC 306 User’s Guide... -
Page 28: Pan/Tilt/Zoom Configuration
This page is to decide whether to use pan/tilt/zoom control function or not and select which serial port to use. (1) Video Channel Selection Administrator selects a video channel for the pan/tilt/zoom mechanism. The four channels shown in the panel Webthru SWC 306 User’s Guide... -
Page 29: Serial Port Configuration
This menu identifies the base address for a video channel and a pan/tilt/zoom (P/T/Z) control receiver. Webthru SWC 306 can support up to six P/T/Z devices for six separate channels when Serial #2 (RS485 Half- Duplex) is enabled. The “Serial Port Base Address” identifies each P/T/Z device to each channel. Select a channel to configure and change the “Serial Port Base Address”... -
Page 30: Digital I/O Configuration
Webthru detects events through motion detection function (MD Event) or external devices (SID1, SID2, SID3, SID4, SID5 and SID6). 13) User Custom Configuration This page is to customize TCP ports of data transmission and default viewer composition. Webthru SWC 306 User’s Guide... -
Page 31: Goto Viewer Page
Background Color & Foreground Color: Ground color of default viewer can be changed. Administrator may set the color with RGB value. 14) Goto Viewer Page This menu is to return to real time image viewer page from administration page. Webthru SWC 306 User’s Guide... -
Page 32: Detailed Specifications Of Webthru Swc 306
(Appendix 1) Detailed Specifications of Webthru SWC 306 1. General Hardware 32bit RISC Embedded processor Flash memory 16MB 64KB Embedded Linux Video Channel NTSC or PAL video format are supported 6Ch. External Video Inputs Image Resolution 720X486, 720X243, 360X243, 180X121, 90X60... -
Page 33: Mechanical
-20 to 60 ℃(-4 to 104 ℉) Relative Humidity 10 to 75%(There should be no condensation) Storage Humidity 10 to 95%(There should be no condensation) Power Source D C 1 2 V ±10% (External) Environment Indoor Webthru SWC 306 User’s Guide...
